Electrical Specifications - Sun Oracle NETRA SPARC T4-1 Installation Manual

Dimension
Depth
Weight (server only)
Minimum service access clearance (front)
Minimum service access clearance (rear)
Related Information
"Electrical Specifications" on page 10
■
"Input Power Information" on page 11
■
"Overcurrent Protection Requirements" on page 12
■
"DC Power Source, Power Connection, and Grounding Requirements" on page 13
■
"Environmental Requirements" on page 14
■
"Acoustic Noise Emissions" on page 15
■
"Airflow Clearance" on page 16
■

Electrical Specifications

Note – The values in this table are the power supply specifications.
Parameter
Voltage (nominal)
Input current (maximum)
Frequency (nominal)
DC input treatment
Caution – The ports of this equipment or subassembly are suitable for connection to
intra-building or unexposed wiring or cabling only. The intra-building port(s) of the
equipment or subassembly must not be metallically connected to interfaces that
10 Netra SPARC T4-1 Server Installation Guide • January 2013
AC
100 to 127 or 200 to 240 VAC
(90 to 140 or 180 to 264 VAC ranges)
9.4 A @ 100 VAC or 4.7 A @ 200 VAC
(940 VA)
50/60 Hz (47 to 63 Hz range)
N/A
Value
526 mm (20.71 in.) max to PSU handles.
501 mm (19.72 in.) max to rear I/O.
18.6 kg (41 lb.) fully configured without PCI
cards
91 cm (36 in.)
91 cm (36 in.)
DC
-48 or -60 VDC (-40 to -75 VDC range)
19.58 A -48 VDC (940 VA)
N/A
Isolated DC Return (DC-I)
