▼ Install a Server (19-Inch, 2-Post Sliding Rail
Rackmount Kit)
Note – The 19-inch, 2-post sliding rail rackmount kit supports rack web thicknesses
(the width of the rack post) of 76.20 mm (3 in.), 101.6 mm (4 in.), and 127 mm (5 in.).
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 863.6 mm (34 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See "Rack Cautions" on page
2. Press in the green button on each slide assembly, and pull the right side and left
side inner glides completely out of the slides.
1 Glide
2 Button
3 Slide (in two parts)
3. Using eight of the M4 x 0.5 x 5 mm Phillips panhead screws from the rackmount
kit (four for each side), attach each glide to the side of the server chassis.
24.
Installing the Server 59
