Sun Oracle NETRA SPARC T4-1 Installation Manual page 15

No. Description
4 Expansion slot 0 (PCIe 2.0 x8 or XAUI)
5 Expansion slot 3 (PCIe 2.0 x8)
6 Expansion slot 1 (PCIe 2.0 x8 or XAUI)
7 Expansion slot 4 (PCIe 2.0 x8)
8 Expansion slot 2 (PCIe 2.0 x8)
9 Service LEDs:
- Locator LED/Locator button (white)
- Service Action Required LED (amber)
- Main Power/OK LED (green)
10 SER MGT RJ-45 serial port
11 NET MGT RJ-45 network port
12 Network 10/100/1000 ports (NET0 to
NET3) for host
13 Physical Presence button access hole
14 USB 2.0 ports (USB 0, USB 1)
15 Video connector (HD-15)
16 Grounding studs
Related Information
"Front Panel Components" on page 5
■
Link
"Optional Components" on page 23
"Optional Components" on page 23
"Optional Components" on page 23
"Optional Components" on page 23
"Optional Components" on page 23
Server Service, interpreting
diagnostic LEDs
"SER MGT Port" on page 70
"NET MGT Port" on page 70
"Gigabit Ethernet Ports" on page 71
"USB Ports" on page 72
"Video Port" on page 73
Understanding the Server 7
