Protocols and standards

RFC 1661, The Point-to-Point Protocol (PPP)
•
• RFC 1918, Address Allocation for Private Internets
RFC 2661, Layer Two Tunneling Protocol "L2TP"
•
RFC 2868, RADIUS Attributes for Tunnel Protocol Support
•

Command and hardware compatibility

Commands and descriptions for centralized devices apply to the following routers:
MSR1002-4/1003-8S.
•
• MSR2003.
MSR2004-24/2004-48.
•
MSR3012/3024/3044/3064.
•
Commands and descriptions for distributed devices apply to MSR4060 and MSR4080 routers.

L2TP configuration task list

When you configure L2TP, perform the following tasks:
Determine the network devices needed according to the networking environment.
1.
For NAS-initiated mode and LAC-auto-initiated mode, configure both the LAC and the LNS.
For client-initiated mode, you only need to configure the LNS.
2. Configure the devices based on the intended role (LAC or LNS) on the network.
To configure a device as an LAC in NAS-initiated or LAC-auto-initiated mode, complete the following
tasks:
Tasks at a glance
(Required.)
Configuring an
•
(Required.)
•
(Required.)
•
(Optional.)
•
(Optional.)
•
(Required.)
•
(Required.)
tunnel
Configuring basic L2TP capabilities
LAC:
Configuring an LAC to initiate tunneling requests for a user
Specifying LNS IP addresses
Configuring the source IP address of L2TP tunnel packets
Enabling transferring AVP data in hidden mode
Configuring AAA authentication on an LAC
Configuring an LAC to automatically establish an L2TP
77
Remarks
N/A
The first and fifth tasks are required
for NAS-initiated mode and
unnecessary for LAC-auto-initiated
mode.
The last task is required for
LAC-auto-initiated mode and
unnecessary for NAS-initiated
mode.
