# Enable the DHCPv6 server feature.
[RouterB-Virtual-Template10] ipv6 dhcp select server
[RouterB-Virtual-Template10] quit
# Enable the PPPoE sever on GigabitEthernet 1/0/1, and bind the interface to interface Virtual-Template
10.
[RouterB] interface gigabitethernet 1/0/1
[RouterB-GigabitEthernet1/0/1] pppoe-server bind virtual-template 10
[RouterB-GigabitEthernet1/0/1] quit
# Create prefix pool 6, and specify prefix 4001::/32 with assigned prefix length 42.
[RouterB] ipv6 dhcp prefix-pool 6 prefix 4001::/32 assign-len 42
# Create address pool 1, and apply prefix pool 6 to address pool 1.
[RouterB] ipv6 dhcp pool pool1
[RouterB-dhcp6-pool-pool1] prefix-pool 6
[Router-dhcp6-pool-pool1] quit
# Configure a PPPoE user.
[RouterB] local-user user1 class network
[RouterB-luser-network-user1] password simple pass1
[RouterB-luser-network-user1] service-type ppp
[RouterB-luser-network-user1] quit
# Configure an IPv6 pool attribute authorized to the user in the ISP domain.
[RouterB] domain system
[RouterB-isp-system] authorization-attribute ipv6-pool pool1
Verifying the configuration
# Verify that Router B has assigned a prefix to Router A.
[RouterB] display ipv6 dhcp server pd-in-use
Pool: 1
IPv6 prefix
4001::1/42
Then, Router A can assign the prefix 4001::1/42 to the host who uses the prefix to generate an IPv6
global unicast address.

PPPoE client in permanent mode configuration example

Network requirements
As shown in
in permanent mode.
Figure 18 Network diagram
Figure 18, Router A serves as a PPPoE server. Configure Router B as a PPPoE client operating
Type Lease expiration
Auto(O) Jul 10 19:45:01 2013
62
