[Router-dhcp-pool-pool1] quit
# Create a PPPoE user.
[Router] local-user user1 class network
[Router-luser-network-user1] password simple pass1
[Router-luser-network-user1] service-type ppp
[Router-luser-network-user1] quit
Verifying the configuration
# Log in to the router by using username user1 and password pass1.
# Display information about IP addresses assigned by the DHCP server.
[Router] display dhcp server ip-in-use
IP address
1.1.1.2
The output shows that the router has assigned an IP address to the host.
PPPoE server IP address assignment through a remote DHCP
server configuration example
Network requirements
As shown in
DHCP server to the host.
Figure 14 Network diagram
Configuration procedure
1. Configure Router A as the PPPoE server:
# Configure interface Virtual-Template 10 to use PAP for authentication and use a DHCP address
pool for IP address assignment.
<RouterA> system-view
[RouterA] interface virtual-template 10
[RouterA-Virtual-Template10] ppp authentication-mode pap
[RouterA-Virtual-Template10] remote address pool pool1
# Specify an IP address for Virtual-Template 10.
[RouterA-Virtual-Template10] ip address 1.1.1.1 24
[RouterA-Virtual-Template10] quit
# Enable the PPPoE server on GigabitEthernet 1/0/1, and bind the interface to Virtual-Template
10.
[RouterA] interface gigabitethernet 1/0/1
Client identifier/
Hardware address
3030-3030-2e30-3030-
662e-3030-3033-2d45-
7468-6572-6e65-74
Figure 14, configure the PPPoE server as a DHCP relay agent to relay an IP address from the
Lease expiration
Unlimited Auto(C)
57
Type
