Configuring MP by using a VT interface

You can use either of the following methods to configure MP by using a VT interface:
• Bind physical interfaces to the VT interface by using the ppp mp virtual-template command.
If authentication is not configured, the system binds links according to the descriptor of the peer.
If authentication is configured, the system binds links according to the username, the descriptor
of the peer, or both.
Associate a username with the VT interface. After the user passes authentication, the system finds
•
the VT interface associated with the username and bundles links according to the username and the
descriptor of the peer. To ensure a successful link negotiation, configure the ppp mp command and
two-way authentication (PAP, CHAP, MS-CHAP, or MS-CHAP-V2) on the bundled interfaces.
When you configure MP by using a VT interface, follow these guidelines:
The ppp mp command and the ppp mp virtual-template command are mutually exclusive on an
•
interface.
You must use the same method to configure the interfaces to be bundled .
•
• To use one-way authentication, associate physical interfaces with a VT interface on one end and
associate a username with the VT interface on the other end.
Configure a VT interface to provide only one service, such as MP, L2TP, or PPPoE.
•
Configuring MP by using a VT interface
Step
1. Enter system view.
2. Create a VT interface and enter
its view.
3. (Optional.) Set the interface
description.
4. Set the keepalive interval.
5. Set the keepalive retry limit.
6. Set the MTU size of the
interface.
7. Set the expected bandwidth of
the VT interface.
8. (Optional.) Specify a primary
traffic processing unit for the VA
interfaces of the VT interface.
Command
system-view
interface virtual-template number
description text
timer-hold seconds
timer-hold retry retry
mtu size
bandwidth bandwidth-value
•
Distributed devices in standalone
mode/centralized devices in IRF
mode:
service slot slot-number
•
Distributed devices in IRF mode:
service chassis chassis-number slot
slot-number
21
Remarks
N/A
If the VT interface already
exists, you enter its view
directly.
By default, the description of
a VT interface is interface
name Interface, for example,
Virtual-Template1 Interface.
The default setting is 10
seconds.
The default setting is 5.
The default setting is 1500
bytes.
By default, the expected
bandwidth (in kbps) is the
interface baud rate divided
by 1000.
By default, no primary traffic
processing unit is specified.
