Tasks at a glance
Configure DCE-side Frame Relay:
•
(Required.)
•
(Required.)
•
(Required.)
•
(Optional.)
•
(Optional.) Perfrom one of the following tasks:
Configuring Frame Relay IPHC
Configuring Frame Relay STAC compression
•
(Optional.) Configuring Frame Relay FRF.12 fragmentation
NNI interfaces are both DTE interfaces and DCE interfaces. You can configure an NNI interface in the
same way a DCE or DTE interface is configured.
If one endpoint of a link is an NNI interface, the peer endpoint must also be an NNI interface.

Configuring basic DTE-side Frame Relay

Step
1. Enter system view.
2. Enter the view of the interface
connecting to the Frame Relay
network.
3. Enable Frame Relay
encapsulation on the
interface.
4. (Optional.) Configure the
encapsulation type for the
Frame Relay interface.
5. (Optional.) Set the Frame
Relay interface type to DTE or
NNI.
6. (Optional.) Configure the
Frame Relay LMI protocol
type.
7. (Optional.) Set the DTE-side
N391 counter.
8. (Optional.) Set the DTE-side
N392 counter.
9. (Optional.) Set the DTE-side
N393 counter.
10. (Optional.) Set the DTE-side
T391 timer.
Configuring basic DCE-side Frame Relay
Configuring local Frame Relay virtual circuits
Configuring Frame Relay address mapping
Configuring Frame Relay subinterfaces
Command
system-view
interface interface-type
interface-number
link-protocol fr
fr encapsulation { ietf |
nonstandard }
fr interface-type { dte | nni }
fr lmi type { ansi | nonstandard |
q933a }
fr lmi n391dte n391-value
fr lmi n392dte n392-value
fr lmi n393dte n393-value
timer-hold seconds
236
Remarks
N/A
N/A
By default, PPP encapsulation is
enabled on interfaces except
Ethernet interfaces, VLAN
interfaces, and ATM interfaces.
The default setting is IETF.
The default setting is DTE.
The default setting is q933a.
The default setting is 6.
The default setting is 3.
The default setting is 4.
The default setting is 10 seconds.
