HP MSR Router Series Wan Access Configuration Manual page 20

Step
2. Enter interface view.
3. Enable IP address
negotiation.
Configure the server to assign an IP address to a client by using the following methods:
Method 1: Specify an IP address for the client on the server interface.
•
Method 2: Specify a PPP or DHCP address pool on the server interface.
•
Method 3: Associate a PPP or DHCP address pool with an ISP domain.
•
For clients requiring no authentication, you can use either method 1 or method 2, but not both.
For clients requiring authentication, you can use one or more of the three methods, but cannot use
method 1 and method 2 at the same time. When multiple methods are configured, method 3 takes
precedence over method 1 or method 2.
PPP supports IP address assignment from a PPP or DHCP address pool. If you use a pool name that
identifies both a PPP address pool and a DHCP address pool, the system uses the PPP address pool.
To configure the device as the server (Method 1):
Step
1. Enter system view.
2. Enter interface view.
3. Configure the interface to assign
an IP address to the peer.
4. Configure an IP address for the
interface.
To configure the device as the server (Method 2: Specify a PPP address pool):
Step
1. Enter system view.
2. Configure a PPP address pool.
3. (Optional.) Configure a
gateway address for the PPP
address pool.
Command
interface interface-type
interface-number
ip address ppp-negotiate
Command
system-view
interface interface-type
interface-number
remote address ip-address
ip address ip-address
Command
system-view
ip pool pool-name start-ip-address
[ end-ip-address ] [ group
group-name ]
ip pool pool-name gateway
ip-address [ vpn-instance
vpn-instance-name ]
11
Remarks
N/A
By default, IP address negotiation
is not enabled.
This command is mutually
exclusive with the ip address
command. For more information
about the ip address command,
see Layer 3—IP Services
Command Reference.
Remarks
N/A
N/A
By default, an interface does not
assign an IP address to the peer.
By default, no IP address is
configured on an interface.
Remarks
N/A
By default, no PPP address pool
is configured.
By default, the PPP address pool
is not configured with a gateway
address.
