Mib Browser Example - Lucom lr77 v2 Configuration Manual

In order to access a particular device enter the IP address of the SNMP agent which is
the router, in the Remote SNMP agent field. The dialog displayed the internal variables in the
MIB tree after entering the IP address. Furthermore, you can find the status of the internal
variables by entering their OID.
The path to the objects is:
iso
The path to information about the router is:
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Figure 52: MIB Browser Example
org dod internet
iso org dod internet
3. CONFIGURATION
private enterprises
mgmt mib-2
80
conel protocols
system
