  • Page 1 ER 75i EDGE router ER 75i DUO ER 75i SL ER 75i DUO SL USER’S GUIDE LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 2: Table Of Contents

    4.14. GRE Tunnel Configuration 4.15. L2TP tunnel Configuration 4.16. DynDNS Client Configuration 4.17. NTP Client Configuration 4.18. SNMP Configuration 4.19. SMTP Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 3 Control by AT commands Possible problems Reference 10. FAQ 11. Customer’s care 12. Product disposal information 13. Guarantee Claim Guidelines 14. Guarantee certificate LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 4 Declared quality system ISO 9001 Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic Issue in CZ, 5/16/2011 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 5: Safety Instructions

    • If it is in the proximity of TV sets, radio receivers and personal computers, the telephone may cause interference. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 6: Description Of The Er 75I, Er 75I Duo, Er 75I Sl And Er 75I Duo Sl Routers

    The EDGE router has four versions. The first version is the basic ER 75i, the second version is the ER 75i DUO with two SIM cards, third version is the ER 75i SL in an aluminum box and the last version is the ER 75i DUO SL with two SIM cards in an aluminum box.

  • Page 7: Delivery Identification

    Expansion port RS485-RS422 XC-485-422 Internal/external power supply Expansion port M-BUSD XC-MBUSD External power supply Expansion port CNT XC-CNT Internal power supply LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 8: Antenna Connection

    2.3. Antenna Connection The whip antenna is connected to the router using an FME on the back panel. External whip antenna: LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 9: Sim Card Reader

    Ethernet – connector RJ45 (10/100 Mbit/s) USB 2.0 – connector USB-B PORT1 Optional – connector RJ45 (150 b/s - - 230400 b/s), RS232, RS485/RS422, M-BUSD, CNT LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 10: Description Of Individual Components Of The Router

    (HTTP) which is security password controlled. Actual firmware version: 2.1.1 (22.4.2011) LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 11: User Interfaces (Connectors)

    USB-B connector (USB) – for connection of the router to the PC. Rear panel ER 75i and ER 75i DUO Front panel ER 75i Front panel ER 75i DUO LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 12 Rear panel ER 75i SL and ER 75i DUO SL Front panel ER 75i SL Front panel ER 75i DUO SL LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 13: Connection Of The Pwr Supply Connector

    Pin 1 – +UN Router Pin 2 – GND The positive pole +UN is marked by a red socket on the power supply. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 14: Connection Of The Eth Connector

    USB data + USB data signal – positive pole Input/Output Negative pole of DC supply voltage The USB router connection: Router USB cable A-B PORT1 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 15: Connection Of The Optional Connector Port1

    The router connection to the PC: Cable KD-2 Router PORT1 • cable KD2 is connected to serial port PC (example COM1) LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 16 2.9. If galvanic separation is required the converter must have an external power supply. Circuit example of the equipment with a router with data length less than 10 m: LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 17 ATTENTION! Power supply is selected on the expansion port RS422 by help of a jumper, 2.9. If galvanic separation is required the converter must have an external power supply. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 18 Circuit example of the equipment with a router with data length more than 10 m: At RS422 data cable more than 10m it is need to use overvoltage protection on the router side! LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 19: Expansion Port M-Busd

    Circuit example of the equipment with a router with data length more than 10 m: If an M-BUS data cable more than 10m it is need to use overvoltage protection on the router side! LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 20: Expansion Port Cnt

    Typical connection of a router measuring circuits: The router does not support to modify any signals of the CNT port, for example logical functions. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 21: Expansion Port Rs232

    If internal power supply is chosen, converter RS485/RS422 is not galvanic separated. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 22 Bus voltage mark 36 .. 43 V Bus voltage space 24 .. 31 V Max. total cable length 1000 m (300Bd, 200nF/km) LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 23 8µA. If current value is 20mA, CNT has higher consumption, also it has higher resistance to industrial noise. Jumper J4 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 24: Modem Status Indication

    Off ...... the network cable is not connected 2.11. Putting into operation Before putting the ER 75i, ER 75i DUO, ER 75i SL or ER 75i DUO SL router into operation it is necessary to connect all components needed for the operation of your applications and the SIM card must be inserted (the modem is off).

  • Page 25: Mechanical External Dimensions And Mounting Recommendations

    DESCRIPTION 2.12. Mechanical external dimensions and mounting recommendations LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 26 ~ 230 V/50 Hz, all signals to sensors must be twisted pairs. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 27 • the circuit diagram of the router is on the following pictures. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 28: Expansion Port Mounting

    The expansion port is mounted to the motherboard by the help of three spacers (position 7). After mounting the expansion port, the box is screwed together by the help of three screws. Connector J3 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 29 Box top part Box bottom part Rear head Front head Spacers for expansion port PORT1 mounting to motherboard Screw for box completion LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 30: Expansion Port Mounting For Er 75I Sl And Er 75I Duo Sl Router

    (position 9). After mounting the expansion port the box is screwed together by the help of four screws. Connector J3 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 31 Rear head Front head Bottom box part Top box part Spacers for expansion port PORT1 mounting to motherboard Screw for box completion LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 32: Configuration Setting Over Web Browser

    RST on front panel. After press button RST it is restoration of the configuration and reset (green LED will be on). LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 33: Network Status

    It is possible to elicit GPRS connection state from the network information. If the GPRS connection is active, then it is in the system information shown as ppp0 connection. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 34: Dhcp Status

    Send SMS when data limit is exceeded (SMS configuration). Information about transferred data is show for primary SIM card only. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 35: Dyndns Status

    To update the contents of the window press the Refresh button. By the help of button Save it is possible to save the system log to the computer. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 36: Lan Configuration

    IP address with address allotted by the help of DHCP, or collision of addresses may occur, thereby malfunctioning the network. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 37 CONFIGURATION Example of the network interface with dynamic DHCP server: 192.168.1.2 GSM/GPRS 192.168.1.1 192.168.1.3 192.168.1.4 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 38 CONFIGURATION Example of the network interface with dynamic and static DHCP server: 192.168.1.2 192.168.1.3 192.168.1.4 GSM/GPRS 192.168.1.1 192.168.1.10 01:23:45:67:89:ab 192.168.1.11 01:54:68:18:ba:7e LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 39 CONFIGURATION Example of the network interface with default gateway and DNS server: 192.168.1.2 192.168.1.3 192.168.1.4 GSM/GPRS 192.168.1.1 192.168.1.20 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 40: Vrrp Configuration

    LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 41: Gprs Configuration

    By parameter PIN it is possible to put PIN to the SIM card always during the starting of the router. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 42 Parameter Switch to primary SIM card after timeout defines conditions, how to switch back to the default SIM card or default APN. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 43 Default value is 1500 bytes. Other settings may cause incorrect transmission of data. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 44 CONFIGURATION The changes in settings will apply after pressing the Apply button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 45: Firewall Configuration

    ICMP. By parameter Target Port it is possible to specify a port number. The changes in settings will apply after pressing the Apply button. Caution! Firewall doesn’t filter via Ethernet. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 46 CONFIGURATION Example of the firewall configuration: TCP/1000 10.0.2.123 ICMP 171.92.5.45 142.2.26.54 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 47: Nat Configuration

    SNMP agent. Choice Masquerade outgoing packets option turns the system address translation NAT. The changes in settings will apply after pressing the Apply button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 48 Connected equipment behind the router must have set Default Gateway on the router. Connected device replies, while PING on IP address of SIM card. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 49 CONFIGURATION Example of the configuration with more connected equipment: SWITCH 162.209.13.222 10.0.0.1:81 ppp0 10.0.0.1 10.0.0.1:82 192.168.1.2:80 10.0.0.1:83 192.168.1.3:80 192.168.1.4:80 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 50: Openvpn Tunnel Configuration

    Compression, compression has to be on both tunnel ends. By parameter NAT Rules it is possible to apply set NAT rules to OpenVPN tunnel. By LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 51 OpenVPN tunnel, for example DHCP options etc. The changes in settings will apply after pressing the Apply button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 52 Remote Subnet Mask: 255.255.255.0 255.255.255.0 Local Interface IP Address: 19.16.1.0 19.16.2.0 Remote Interface IP Address: 19.16.2.0 19.18.1.0 Compression Authenticate mode: none none LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 53: Ipsec Tunnel Configuration

    Extra Options it is possible to define additional parameters of the Ipsec tunnel, for example secure parameters etc. The changes in settings will apply after pressing the Apply button LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 54 CONFIGURATION LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 55: Gre Tunnel Configuration

    GRE tunnel. The column Create switch on tunnels, other columns contain values view set in the GRE Tunnel Configuration windows; configuration is possible by Edit button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 56 Default Gateway 192.168.1.1 GRE tunnel Configuration: Remote External IP Address: 10.0.0.2 10.0.0.1 Remote Subnet: 192.168.2.0 192.168.1.0 Remote Subnet Mask: 255.255.255.0 255.255.255.0 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 57: L2Tp Tunnel Configuration

    (Remote Subnet Mask), username for login to L2TP tunnel (Username) and password (Password). The changes in settings will apply after pressing the Apply button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 58 Local IP Address: 192.168.1.1 Remote IP Address Remote Subnet 192.168.2.0 192.168.1.0 Remote Subnet Mask 255.255.255.0 255.255.255.0 Username user user Password password password LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 59: Dyndns Client Configuration

    IP address of the first DNS server, echo “nameserver yvy.yyy.yyy.yyy“ >> / et/resolf.conf, where yvy.yyy.yyy.yyy is IP address of the ettin DNS server. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 60: Ntp Client Configuration

    By choosing Enable XC-CNT extension it is possible to monitor the expansion port CNT inputs status or by choosing Enable M-BUS extension and enter the Baudrate, Parity LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 61 47. VIF – value information field .1.3.6.1.4.1.30140.2.2.<address>.101.0 47. measured value The meter address can be from range 0..254 when 254 is broadcast. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 62: Smtp Configuration

    Example of the MIB browser: It is important to set the IP address of the SNMP agent (ER 75i) in field Remote SNMP agent. After enter the IP address is in a MIB tree part is possible show object identifier.

  • Page 63: Sms Configuration

    Choices Enable AT-SMS protocol on external port and Enable AT-SMS protocol on TCP port mustn’t be chosen at the same time. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 64 After PPP disconnect, at introduction of the telephone number comes SMS in the form: ER75i (Unit ID) has lost PPP connection. IP address xxx.xxx.xxx.xxx LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 65 CONFIGURATION Configuration of sending this SMS is following: LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 66 CONFIGURATION Example of the router configuration for SMS sending via serial interface: LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 67 CONFIGURATION Example of the router configuration for controlling via SMS from every phone numbers: LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 68 List of all SMS messages AT+CMGR=<index> Read of the definite SMS (all SMS has our index) AT+CMGD=<index> SMS delete according to index LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 69 +CMGL: <index>, <status>,<sender number>, ,<date>,<time> SMS text. +CMGL: 1,“REC READ“,“+420721123456“, ,“08/01/12, 9:48:04+04“ Hello World! Received SMS is possible delete by command AT+CMGD=<index>. AT+CMGD=1 Enter LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 70: Expansion Port Configuration

    M-BUS TCP then sent data will be returned back to the device! If e.g. LINE protocol is set- up on this port, then data will return back to the source. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 71 ER-75i settings ER-75i settings Mode: TCP server Mode: TCP client Server Address: - Server Address: 10.0.0.2 TCP Port: 2000 TCP Port: 2000 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 72: Start-Up Script

    [ "$BIN4" = "1" ]; then gsmsms 739546801 "test SMS bin4-1" if [ "$BIN4" = "0" ]; then gsmsms 739546801 "test SMS bin4-0" OLD4=$BIN4 sleep 2 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 73 2 done Change take effect after restarting router by the help of button Reboot in web administration or by SMS message. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 74: Up/Down Script

    Hardware MAC address and cfg extension is connected automatically and it isn’t needed to enter this. By parameter Unit ID enabled it defines the LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 75: Change Profile

    In basic settings of the router the password is set on default form root. For higher security of your network we recommend changing this password. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 76: Set Real Time Clock

    Possibility to unlock SIM PIN is under Unlock SIM Card item. If the inserted SIM card is secured by a PIN number, enter the PIN to field SIM PIN and push-button Apply. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 77: Send Sms

    In case it is needed to restore the router configuration, it is possible in Restore Configuration menu item to check configuration by help Browse button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 78: Update Firmware

    GPRS connection. 4.34. Reboot To reboot the router select the Reboot menu item and then press the Reboot button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 79: Default Settings

    RST on front panel. After press button RST it is restoration of the configuration and reset (green LED will be on). 4.35.1. LAN Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 80: Vrrp Configuration

    CONFIGURATION 4.35.2. VRRP Configuration 4.35.3. Firewall Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 81: Gprs Configuration

    CONFIGURATION 4.35.4. GPRS Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 82: Nat Configuration

    CONFIGURATION 4.35.5. NAT Configuration 4.35.6. OpenVPN Tunnel Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 83 CONFIGURATION LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 84: Ipsec Tunnel Configuration

    CONFIGURATION 4.35.7. Ipsec Tunnel Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 85: Gre Tunnel Configuration

    CONFIGURATION 4.35.8. GRE Tunnel Configuration 4.35.9. L2TP Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 86: Dyndns Configuration

    CONFIGURATION 4.35.10. DynDNS Configuration 4.35.11. NTP Configuration 4.35.12. SNMP Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 87: Smtp Configuration

    CONFIGURATION 4.35.13. SMTP Configuration 4.35.14. SMS Configuration LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 88: Expansion Port Configuration

    CONFIGURATION 4.35.15. Expansion Port Configuration 4.35.16. Startup Script LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 89: Up/Down Script

    CONFIGURATION 4.35.17. Up/Down Script 4.35.18. Automatic Update LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 90: Configuration Setting Over Telnet

    LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 91: Driver Installation

    "usbmodem.inf" file. Windows will copy the needed files to your computer and configure the modem by assigning a free COM port. After completion of copying the files click on the Finish button. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 92 COM port number menu. The change of COM port setting will apply only after disconnection and reconnection of the USB cable. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 93: Control By At Commands

    How is it possible to enter AT commands? It is necessary to use a USB connection, but it is impossible to connect to GPRS from the router together. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 94 SMS message the router will be in this mode up to next restart. This behaviour is the same for next all control SMS messages. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 95: Customer's Care

    Conel Company hereby declares that the modem narrated in this user’s guide fits all basic demands of directive 1999/5/EC (R&TTE). Declaration about consistency was issued and is possible get it at producer. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 96: Product Disposal Information

    MUST NOT be mixed with other commercial waste for disposal. Check with the terms and conditions of your supplier for disposal information. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 97: Guarantee Claim Guidelines

    (including the exchange of the IMEI), the ownership of the original object of the guarantee claim is passed LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 98 (storm, mains over voltage, etc.). 7. Storage under conditions outside the temperature range. 8. Operation in a chemically aggressive environment. LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 99 LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

  • Page 100: Guarantee Certificate

    14. Guarantee certificate Type of the device Serial number Guarantee period (in months) Seller Date of sale Stamp of the seller LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...
  • Page 101 YES - NO YES - NO YES - NO New serial number of the device (IMEI) Comments Stamp of the repair shop LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de...

This manual is also suitable for:
