Example 1: The figure below displays the following scenario: the connection to the mobile
network is controlled on the address 8.8.8.8 with the time interval of 60 seconds for the pri-
mary SIM card and on the address www.google.com with the time interval 80 seconds for the
secondary SIM card. In the case of data stream on the router, the control pings are not sent,
but the data stream is monitored.
Example 2: The following configuration illustrates a scenario in which the router changes to
a backup SIM card after exceeding the data limits of 800MB. The router sends a warning SMS
upon reaching 400MB. The accounting period starts on the 18th day of the month.
Example 3: The Primary SIM card changes to the off line mode after the router detects
roaming. The first attempt to change back to the default SIM card is executed after 60 minutes,
the second attempt is executed after 40 minutes, the third attempt is executed after 50 minutes
(40+10).
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Figure 21: Example 1 – Mobile WAN Configuration
Figure 22: Example 2 – Mobile WAN Configuration
Figure 23: Example 3 – Mobile WAN Configuration
35
3. CONFIGURATION
