For the expansion port CNT, the following range of OID is used:
OID
.1.3.6.1.4.1.30140.2.1.1.0
.1.3.6.1.4.1.30140.2.1.2.0
.1.3.6.1.4.1.30140.2.1.3.0
.1.3.6.1.4.1.30140.2.1.4.0
.1.3.6.1.4.1.30140.2.1.5.0
.1.3.6.1.4.1.30140.2.1.6.0
.1.3.6.1.4.1.30140.2.1.7.0
.1.3.6.1.4.1.30140.2.1.8.0
.1.3.6.1.4.1.30140.2.1.9.0
For the expansion port M-BUS, the following range of OID is used:
OID
.1.3.6.1.4.1.30140.2.2.<address>.1.0
.1.3.6.1.4.1.30140.2.2.<address>.2.0
.1.3.6.1.4.1.30140.2.2.<address>.3.0
.1.3.6.1.4.1.30140.2.2.<address>.4.0
.1.3.6.1.4.1.30140.2.2.<address>.5.0
.1.3.6.1.4.1.30140.2.2.<address>.6.0
.1.3.6.1.4.1.30140.2.2.<address>.7.0
.1.3.6.1.4.1.30140.2.2.<address>.8.0
.1.3.6.1.4.1.30140.2.2.<address>.9.0
.1.3.6.1.4.1.30140.2.2.<address>.10.0
.1.3.6.1.4.1.30140.2.2.<address>.11.0
.1.3.6.1.4.1.30140.2.2.<address>.12.0
.1.3.6.1.4.1.30140.2.2.<address>.13.0
. .
.
.1.3.6.1.4.1.30140.2.2.<address>.100.0
.1.3.6.1.4.1.30140.2.2.<address>.101.0
The meter address can be from range 0 – 254, where the number 254 is broadcast.
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Analogy input AN1 (range 0-4095)
Analogy input AN2 (range 0-4095)
Counter input CNT1 (range 0-4294967295)
Counter input CNT2 (range 0-4294967295)
Binary input BIN1 (values 0,1)
Binary input BIN2 (values 0,1)
Binary input BIN3 (values 0,1)
Binary input BIN4 (values 0,1)
Binary output OUT1 (values 0,1)
Table 56: Object identifier for CNT port
Description
IdNumber – meter number
Manufacturer
Version – specified meter version
Medium – type of metered medium
Status – errors report
0. VIF – value information field
0. measured value
1. VIF – value information field
1. measured value
2. VIF – value information field
2. measured value
3. VIF – value information field
3. measured value
. .
.
47. VIF – value information field
47. measured value
Table 57: Object identifier for M-BUS port
78
3. CONFIGURATION
