3.17 SNMP Configuration
The SNMP page allows you to configure the SNMP v1/v2 or v3 agent which sends in-
formation about the router (and its expansion ports) to a management station. To open the
SNMP page, click SNMP in the Configuration section of the main menu. SNMP (Simple Net-
work Management Protocol) provides status information about the network elements such as
routers or endpoint computers. In the version v3, the communication is secured (encrypted).
To enable the SNMP service, mark the Enable the SNMP agent check box.
Item
Name
Location
Contact
To enable the SNMPv1/v2 function, mark the Enable SNMPv1/v2 access check box. It is
also necessary to specify a password for access to the Community SNMP agent. The default
setting is public.
You can define a different password for the Read community (read only) and the Write
community (read and write) for SNMPv1/v2. You can also define 2 SNMP users for SNMPv3.
You can define a user as read only (Read), and another as read and write (Write). The router
allows you to configure the parameters in the following table for every user separately. The
router uses the parameters for SNMP access only.
To enable the SNMPv3 function, mark the Enable SNMPv3 access check box, then specify
the following parameters:
Item
Username
Authentication
Authentication Password
Privacy
Privacy Password
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Designation of the router.
Location of where you installed the router.
Person who manages the router together with information how to contact
this person.
Table 51: SNMP Agent Configuration
Description
User name
Encryption algorithm on the Authentication Protocol that is
used to verify the identity of the users.
Password used to generate the key used for authentication.
Encryption algorithm on the Privacy Protocol that is used to
ensure confidentiality of data.
Password for encryption on the Privacy Protocol.
Table 52: SNMPv3 Configuration
3. CONFIGURATION
75
