In addition, you can continue with this configuration:
Activating the Enable I/O extension function allows you monitor the binary I/O inputs on
the router.
Selecting the Enable XC-CNT extension lets you monitor the expansion port CNT inputs
and outputs status.
Selecting Enable M-BUS extension and entering the Baudrate, Parity and Stop Bits lets
you monitor the meter status connected to the expansion port MBUS status.
Item
Baudrate
Parity
Stop Bits
Parameters Enable XC-CNT extension and Enable M-BUS extension cannot be checked
at the same time.
Selecting Enable reporting to supervisory system and entering the IP Address and Period
lets you send statistical information to the monitoring system, R-SeeNet.
Item
IP Address
Period
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Communication speed
Control parity bit:
none – Data will be sent without parity.
even – Data will be sent with even parity.
odd – Data will be sent with odd parity.
Number of stop bits.
Table 53: SNMP configuration – MBUS extension
Description
IP address
Period of sending statistical information (in minutes).
Table 54: SNMP Configuration – R-SeeNet
3. CONFIGURATION
