3.3 Mobile WAN Configuration
The XR5i v2 routers do not display the Mobile WAN configuration option.
Select the Mobile WAN item in the Configuration menu section to enter the cellular network
configuration page.

3.3.1 Connection to Mobile Network

If you mark the Create connection to mobile network checkbox, then the router automati-
cally attempts to establish a connection after booting up. You can specify the following param-
eters for each SIM card separately, or to toggle between the SIM cards, specify two different
APNs.
Item
APN
Username
Password
Authentication
IP Address
Phone Number
Operator
Network type
PIN
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Network identifier (Access Point Name)
User name for logging into the GSM network
Password for logging into the GSM network
Authentication protocol in the GSM network:
PAP or CHAP – The router selects the authentication method.
PAP – The router uses the PAP authentication method.
CHAP – The router uses the CHAP authentication method.
Specifies the IP address of SIM card. You manually enter the IP ad-
dress, only when mobile network carrier assigned the IP address.
Specifies the telephone number the router dials for a GPRS or CSD
connection. The router uses a default telephone number *99***1 #.
Specifies the carrier code. You can specify the parameter as the PLNM
preferred carrier code.
Specifies the type of protocol used in the mobile network.
Automatic selection – The router automatically selects the trans-
mission method according to the availability of transmission tech-
nology.
Furthermore, according to the type of router – It's also possible to
select a specific method of data transmission (GPRS, UMTS, . . . )
Specifies the PIN used to unlock the SIM card. Use a PIN parameter
only if the network requires a SIM card router. The SIM card is blocked
after several failed attempts to enter the PIN.
3. CONFIGURATION
Continued on next page
