3. CONFIGURATION
Example 2: Configure the network interface to connect to a dynamic and static DHCP server:
The range of allocated addresses is from 192.168.1.2 to 192.168.1.4.
The address is allocated for 600 seconds (10 minutes).
The client with the MAC address 01:23:45:67:89:ab has the IP address 192.168.1.10.
The client with the MAC address 01:54:68:18:ba:7e has the IP address 192.168.1.11.
Figure 13: Example 2 – Network Topology with both Static and Dynamic DHCP Servers
Figure 14: Example 2 – LAN Configuration Page
22
