If you unmark the Enable backup routes switching check box, the backup routes system
operates in the backward compatibility mode. The router selects the default route based on
implicit priorities of the enabled settings for each of the network interfaces, as the case may
be enabling services that set these network interfaces. The following list contains the names
of backup routes and corresponding network interfaces in order of implicit priorities:
Mobile WAN (pppX, usbX)
PPPoE (ppp0)
WiFi STA (wlan0)
Secondary LAN (eth1)
Primary LAN (eth0)
Example: The router selects the Secondary LAN as the default route only if you unmark the
Create connection to mobile network check box on the Mobile WAN page. Alternatively, if you
unmark the Create PPPoE connection check box on the PPPoE page. To select the Primary
LAN, delete the IP address for the Secondary LAN and disabled the DHCP Client for the
Secondary LAN.
Item
Priority
Ping IP Address
Ping Interval
All changes in settings will be applied after pressing the Apply button.
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Priority for the type of connection.
Destination IP address of ping queries to check the connection.
(The address can not be specified as a domain name.)
The time intervals between consecutive ping queries.
Table 30: Backup Routes
