2.2 Mobile WAN Status

The XR5i v2 routers do not display the Mobile WAN status option.
The Mobile WAN menu item contains current information about connections to the mobile
network. The first part of this page (Mobile Network Information) displays basic information
about mobile network the router operates in. There is also information about the module,
which is mounted in the router.
Item
Registration
Operator
Technology
PLMN
Cell
LAC
Channel
Signal Strength
Signal Quality
CSQ
Neighbours
Manufacturer
Model
Revision
IMEI
ESN
MEID
ICCID
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
State of the network registration
Specifies the operator's network the router operates in
Transmission technology
Code of operator
Cell the router is connected to
Location Area Code – unique number assigned to each location area
Channel the router communicates on
Signal strength of the selected cell
Signal quality of the selected cell:
EC/IO for UMTS and CDMA (it's the ratio of the signal received
from the pilot channel – EC – to the overall level of the spectral
density, ie the sum of the signals of other cells – IO)
RSRQ for LTE technology (Defined as the ratio
The value is not available for the EDGE technology
Cell Signal Quality, relative value is given by RSSI (dBm). 2–9 range
means Marginal, 10–14 range means OK, 15–16 range means Good,
20–30 range means excellent.
Signal strength of neighboring hearing cells
Module manufacturer
Type of module
Revision of module
IMEI (International Mobile Equipment Identity) number of module
ESN (Electronic Serial Number) number of module (for CDMA routers)
MEID number of module
Integrated Circuit Card Identifier is international and unique serial
number of the SIM card.
Table 4: Mobile Network Information
