3. Configuration
3.1 LAN Configuration
To enter the Local Area Network configuration, select the LAN menu item in the Configu-
ration section. The Primary LAN subitem is for the router's main Ethernet interface (ETH). If
the router has additional Ethernet ports (PORT1 or PORT2), they are configured using the
Secondary LAN subitem. For routers with two additional Ethernet ports, PORT1 and PORT2
are automatically bridged together.
Item
DHCP Client
IP address
Subnet Mask
Bridged
Media type
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Enables/disables the DHCP client function.
disabled – The router does not allow automatic allocation IP ad-
dress from a DHCP server in LAN network.
enabled – The router allows automatic allocation IP address from
a DHCP server in LAN network.
Specifies a fixed set of IP addresses for the network interfaces ETH.
Specifies a Subnet Mask for the IP address.
Activates/deactivates the bridging function on the router.
no – The bridging function is inactive (default).
yes – The bridging function is active.
Specifies the type of duplex and speed used in the network.
Auto-negation – The router automatically sets the best speed
and duplex mode of communication according to the network's
possibilities.
100 Mbps Full Duplex – The router communicates at 100Mbps,
in the full duplex mode.
100 Mbps Half Duplex – The router communicates at 100Mbps,
in the half duplex mode.
10 Mbps Full Duplex – The router communicates at 10Mbps, in
the full duplex mode.
10 Mbps Half Duplex – The router communicates at 10Mbps, in
the half duplex mode.
18
3. CONFIGURATION
Continued on next page
