Example of the IPSec tunnel configuration:
IPsec tunnel configuration:
Configuration
Remote IP Address
Remote Subnet
Remote Subnet Mask
Local Subnet
Local Subnet Mas:
Authenticate mode
Pre-shared key
Examples of different options for configuration and authentication of IPsec tunnel can be found
in the application note IPsec Tunnel [6].
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Figure 40: Topology of IPsec Configuration Example
A
10.0.0.2
192.168.2.0
255.255.255.0
192.168.1.0
255.255.255.0
pre-shared key
test
Table 41: Example IPsec configuration
3. CONFIGURATION
B
10.0.0.1
192.168.1.0
255.255.255.0
192.168.2.0
255.255.255.0
pre-shared key
test
65
