Lucom lr77 v2 Configuration Manual page 63

Item
Redirect Gateway
Local Interface IP
Address
Remote Interface
IP Address
Ping Interval
Ping Timeout
Renegotiate Interval
Max Fragment Size
Compression
NAT Rules
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Continued from previous page
Description
Activates/deactivates redirection of data on Layer 2.
Specifies the IP address of a local interface.
Specifies the IP address of the interface of opposite side of the
tunnel.
Specifies the time interval after which the router sends a mes-
sage to opposite side of tunnel to verify the existence of the tun-
nel.
Specifies the time interval during which the router waits for a
message sent by the opposite side. For proper verification of the
OpenVPN tunnel, set the Ping Timeout to greater than the Ping
Interval.
Specifies the renegotiate period (reauthorization) of the Open-
VPN tunnel. You can only set this parameter when the Authen-
ticate Mode is set to username/password or X.509 certificate.
After this time period, the router changes the tunnel encryption
to help provide the continues safety of the tunnel.
Maximum size of a sent packet.
Compression of the data sent:
none – No compression is used.
LZO – A lossless compression is used, use the same set-
ting on both sides of the tunnel.
Activates/deactivates the NAT rules for the OpenVPN tunnel:
not applied – NAT rules are not applied to the OpenVPN
tunnel.
applied – NAT rules are applied to the OpenVPN tunnel.
56
3. CONFIGURATION
Continued on next page
