2.1.2 Primary LAN, Secondary LAN, WiFi

Items displayed in this part have the same meaning as items in the previous part. More-
over, the MAC Address item shows the MAC address of the corresponding router's interface
(Primary LAN – eth0, Secondary LAN – eth1, WiFi – wlan0). Visible information depends on
configuration (see

2.1.3 Peripheral Ports

Item
Expansion Port 1
Expansion Port 2
Binary Input
Binary Output

2.1.4 System Information

Item
Firmware Version
Serial Number
Profile
Supply Voltage
Temperature
Time
Uptime
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
3.1 or 3.5).
Description
Expansion port fitted to the position 1 (None indicates that this
position is equipped with no port)
Expansion port fitted to the position 2 (None indicates that this
position is equipped with no port)
State of binary input
State of binary output
Table 2: Peripheral Ports
Description
Information about the firmware version
Serial number of the router (in case of N/A is not available)
Current profile – standard or alternative profiles (profiles are used
for example to switch between different modes of operation)
Supply voltage of the router
Temperature in the router
Current date and time
Indicates how long the router is used
Table 3: System Information
5
2. STATUS
