If you enable the following options and enter the port number, the router allows you to
remotely access to the router from a PPP interface.
Item
Enable remote HTTP access on port
Enable remote HTTPS access on port
Enable remote FTP access on port
Enable remote SSH access on port
Enable remote Telnet access on port
Enable remote SNMP access on port
Masquerade outgoing packets
Example 1: NAT configuration with one connection to the router:
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
If field and port number are filled in, configura-
tion of the router over web interface is allowed
(disabled in default configuration).
If field and port number are filled in, configura-
tion of the router over web interface is allowed
(disabled in default configuration).
Select this option to allow the router using FTP.
Select this option to allow access to the router
using SSH (disabled in default configuration).
Select this option to allow the router using Telnet.
Select this option to allow access to the router
using SNMP (disabled in default configuration).
Activates/deactivates the network address trans-
lation function.
Table 35: Remote Access Configuration
Figure 31: Example 1 – Topology of NAT Configuration
