3.10 OpenVPN Tunnel Configuration
Select the OpenVPN item to configure an OpenVPN tunnel. The OpenVPN tunnel function
allows you to create a secure connection between two separate LAN networks. The router
allows you to create up to four OpenVPN tunnels.
Item
Create
Description
Edit
Item
Description
Protocol
UDP/TCP port
Remote IP Address
Remote Subnet
Remote Subnet Mask
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
Activates/deactivates the individual tunnel configurations.
Displays the name of the tunnel specified in the configuration form.
Opens the OpenVPN tunnel configuration form.
Table 36: OpenVPN Tunnels Overview
Figure 35: OpenVPN Tunnels List
Description
Specifies the description or name of tunnel.
Specifies the communication protocol.
UDP – The OpenVPN communicates using UDP.
TCP server – The OpenVPN communicates using TCP in
server mode.
TCP client – The OpenVPN communicates using TCP in
client mode.
Specifies the port of the relevant protocol (UDP or TCP).
Specifies the IP address of opposite tunnel side. You can also
use the domain name.
Specifies the IP address of a network behind opposite side of the
tunnel.
Specifies the subnet mask of a network behind opposite side of
the tunnel.
3. CONFIGURATION
Continued on next page
