3.5 WiFi Configuration
This item is available only if the router is equipped with a WiFi module.
Configure the WiFi network by selecting the WiFi item in the main menu of the router web
interface. Activate WiFi by selecting Enable WiFi at the top of the form. You may also set the
following properties:
Item
Operating mode
SSID
Broadcast SSID
Probe Hidden
SSID
Country Code
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. 09127/59 460-10 * Fax. 09127/59 460-20 * www.lucom.de
Description
WiFi operating mode:
access point (AP) – The router becomes an access point to
which other devices in station (STA) mode can connect.
station (STA) – The router becomes a client station. It receives
data packets from the available access point (AP) and sends
data from cable connection via the WiFi network.
Unique identifier of WiFi network.
Method of broadcasting the unique identifier of SSID network in bea-
con frame and type of response to a request for sending the beacon
frame.
Enabled – SSID is broadcasted in beacon frame
Zero length – Beacon frame does not include SSID. Requests
for sending beacon frame are ignored.
Clear – All SSID characters in beacon frames are replaced by
0. Original length is kept. Requests for sending beacon frames
are ignored.
Probes hidden SSID (only for station (STA) mode)
Code of the country where the router is installed. This code must be
entered in ISO 3166-1 alpha-2 format. If a country code isn't specified
and the router has not implemented a system to determine this code,
it will use "US" as the default country code.
If no country code is specified or if the wrong country code is entered,
then the router violate country-specific regulations for the use of the
WiFi frequency bands.
37
3. CONFIGURATION
