Media - Printronix T6000 Administrator's Manual

Media

Type
Supply Roll
Optional Internal
Rewinder
Label Material
Media Sensing
Label Taken Sensor (part
of the Peel/Rewinder
Option)
Label Peel-Off
264
Table 15. Media - General Information
Roll-fed, die-cut continuous or fanfold labels, tags or tickets;
most direct thermal or thermal transfer materials.
8 inch (203 mm) maximum diameter on 1.5-inch (37.5 mm) to
3-inch (76 mm) diameter cores.
Accepts up to a 5-inch diameter roll of label backing.
Thermal transfer plain-coated papers, vinyl, Mylar, metallized
paper, non-woven fabric, fine woven fabric, thermal-visible light
scannable paper, infrared scannable paper, thermal ticket/tag
stock, thermally-sensitive plastic stock.
Horizontally moveable sensor assembly. When set to Mark, it
senses a black mark on the underside of tag or label stock. When
set to Disable, it senses no label indicators or ignores all existing
label length indicators on the installed media.
Detects when a printed label is at the printer exit throat. Used
only for Peel-Off Media Handling mode.
Peels and presents label to the operator, one at a time. Automatic
Label Peel-Off is supported only when the internal rewinder is
installed. (The internal rewinder is a factory- or field-installed
option.)
