Fault

When faults occur, the user will be notified with the following screen on the display. The red color is used
to make a clear indication that the printer needs attention.
Users can follow the simple instructions shown in the screen or request additional help with the faults by
using the RIGHT SOFT key "Fault Help" if available. When Fault Help is selected, the user will be provided
a set of screens to help them through the process. However, Fault Help is only offered for faults that are
complex or require several steps with the printer mechanism.
The user can also choose via the LEFT SOFT key to go the "Home" screen, then to the
Wizard sections to adjust menu values (e.g., change media parameters, load Configs, etc.).
NOTE:
The icon will be shown in the upper right corner as a reminder there is a fault that needs to
be cleared. Even when the user has completed all the steps necessary, the icon may continue
to be shown. Some faults are self-clearing in the OFFLINE state while other faults are cleared
only when returning ONLINE. If any fault was not successfully cleared, the Fault screen shown
above will reappear when the user attempts to return ONLINE.

Job in Process

There is no dedicated LED or status indicator for Job in Process. Users will know the printer is receiving
data instead via messages in the circled portion of the ONLINE screen as shown below.
When the printer is in ONLINE mode and data is being received and being processed, the message "Job
in Process" will be shown in the message area. After the job has been printed the message will go away. If
the user is printing in batch mode and the option System > Control > Batch Counter is enabled, the page
count will have priority over the 'Job in Process' message.
When the printer is in OFFLINE mode and in the Home screen, the LEFT SOFT key will be labeled "Cancel
Data" if there is Data in Buffer when the printer is taken OFFLINE. If there is no Data in Buffer, then the LEFT
SOFT key label will not show anything. In order for the Cancel Data operation to be available, the menu
System > Control > Cancel Operation must be enabled.
22
