Carriage

j Cutter Unit
A round-bladed cutter for automatic paper cutting.
Linear Scale
k
The linear scale serves a key role in detecting the Carriage position. Be careful not to touch this part when
cleaning inside the Top Cover or clearing paper jams.
l Switch
Set the switch to the side opposite ● if the edges of printed images are blurred. Set the switch to the ● side
before borderless printing. (See "Setting the Blue Switch on the Platen.")

Carriage

Carriage
Printhead Fixer Cover
a
Holds the Printhead in place.
Printhead
b
The printhead is equipped with ink nozzles. The carriage serves a key role in printing.
Printhead Fixer Lever
c
Locks the Printhead Fixer Cover.
d Angle Adjustment Lever
Use this lever to fine-tune the printer to correct misalignment of printed lines.

Ink Tank Cover (Inside)

Ink Tank Cover (Inside)

466
Note: The figure shows the printer as loaded with 700 ml (23.7 fl oz) Ink Tank.
Ink Tanks
a
Cartridges of ink in various colors.
a
b
c
d
a
b
d
P.623
➔
c
iPF830
