Line thickness is not uniform

Line thickness is not uniform
Cause
In the Special Settings dialog box of
the Windows printer driver, Fast
Graphic Process is set to On.
The type of paper specified in the
printer driver does not match the type
loaded in the printer.
The blue Switch on the platen is set
incorrectly.

Lines are misaligned

Lines are misaligned
Cause
The Printhead alignment is not adjus-
ted.
The type of paper specified in the print-
er driver does not match the type loa-
ded in the printer.
User's Guide
Access the printer driver Properties dialog box from Print in the File menu of the source
application, and follow these steps to print.
1.
Clear the option Open Preview When Print Job Starts on the Main sheet.
2.
Clear the option Page Layout on the Layout sheet.
3.
Click the Special Settings button in the Layout sheet, open the Special Settings dia-
log box, and set Fast Graphic Process to Off.
Load paper of the same type as you have specified in the printer driver.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Printer.")
Make sure the same type of paper is specified in the printer driver as you have loaded in
the printer.
1.
Press the Stop button and stop printing.
2.
Change the type of paper in the printer driver and try printing again.
Move the Switch numbered corresponding to the size of paper for printing opposite to the ●
position.
(See "Setting the Blue Switch on the Platen.")
Adjust the Printhead alignment.
(See "Automatic Adjustment to Straighten Lines and Colors.")
(See "Manual Adjustment to Straighten Lines and Colors.")
(See "Adjusting Line Misalignment.")
Load paper of the same type as you have specified in the printer driver.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Printer.")
Make sure the same type of paper is specified in the printer driver as you have loaded in
the printer.
1.
Press the Stop button and stop printing.
2.
Change the type of paper in the printer driver and try printing again.
Line thickness is not uniform
Corrective Action
P.333
➔
P.353
➔
P.623
➔
Corrective Action
P.550
➔
P.552
➔
P.554
➔
P.333
➔
P.353
➔
