iPF830
5
Insert the Holder Stopper from the left in the Roll Holder as
shown. Holding it at the position shown (b), push it firmly in
until the flange (a) of the Holder Stopper touches the roll.
Lock the Holder Stopper lever (c) by pushing it down to-
ward the shaft side.
Loading Rolls in the Printer
Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
•
Always load rolls when the printer is on. If the printer is off when you load a roll, the paper may not be advanced
correctly when you turn the printer on.
Important
•
Before loading a roll, confirm whether the inside of the Top Cover or the Ejection Guide is soiled. If soiled, we
recommend cleaning in advance. (See "Cleaning Inside the Top Cover.")
1
Press the Load button.
2
Press ▲ or ▼ to select "Load Roll Paper", and then press the OK button.
•
If any roll paper that will not be used or cut sheet has been fed, a message is shown requesting you to
remove it.
Note
Press ▲ or ▼ to select Yes, and then press the OK button. Remove the paper and go to the next step.
•
If roll paper is loaded but cut sheet is selected as the paper source, a message asking you whether or not
to change paper is displayed.
Press ▲ or ▼ to select Load, and then press the OK button. Remove the paper and proceed to the next
step.
User's Guide
Loading Rolls in the Printer
b
a
P.591
➔
333
