iPF830
HDD Information
*1:Canon cannot guarantee the accuracy of these estimates. These estimates will also vary depending on the conditions of print-
er use.
*2:This is displayed when Show Job Log is On in System Setup.
*3:Even if Show Job Log is Off in System Setup, it is displayed if a password is configured in Change Password in the
Admin. Menu and the password has been authenticated.
Set./Adj. Menu
Limited items are displayed during printing. The displayed items are indicated by annotations.
Test
Nozzle Check
Print
Status Print
Interface Print
GL2 Set Print
Paper Details
Print Job Log
Menu Map
Color Palette
Adjust
Head
Standard
Printer
Posi.
Adj.
Simple
Other
Head Inc. Adj.
User's Guide
Setting Item
Setting Item
Initial adjustmt
Manual
Description, Instructions
Indicates the total hard disk capacity and the mail box free
space.
Description, Instructions
Print a test pattern to check the nozzles.
Print information about the setting values and condition of
the printer.
Print interface settings information.
Print the settings as specified in GL2 Settings.
Print the paper settings as specified in Paper Details.
Print information to match the Job Log display state.
This is not printed when the Job Log is configured to not
display.
The maximum number of history records in models fitted
with a hard disk is 32.
The maximum number of history records in models not fit-
ted with a hard disk is 10.
Print the menu structure.
Print the GL2 color palette.
An adjustment pattern is printed and the print position is
automatically adjusted to fix misaligned printing. Select
Standard if vertical lines in printed material are warped or
colors are out of alignment. Select Standard also if the
printing results are not improved by executing Simple.
(See "Automatic Adjustment to Straighten Lines and Col-
ors.")
P.550
➔
An adjustment pattern is printed and the print position is
automatically adjusted to fix misaligned printing. Simple
executes a simple adjustment in a short time. Select Sim-
ple when frequently adjusting the printhead, such as dur-
ing daily maintenance. (See "Automatic Adjustment to
Straighten Lines and Colors.")
Printhead position adjustment is executed during the initial
setup. If adjusting the printhead position has not been per-
formed such as due to an error during initial setup or the
state of the operating settings when replacing the print-
head, select Initial adjustmt. (See "Adjustment When In-
stalling the Printhead.")
➔
Input the setting values from the adjustment pattern print-
ing results and adjust the printing position to fix mis-
aligned printing. Normally, select Standard. However,
when printing on special paper, or if printing is not im-
proved after Standard, try Manual. (See "Manual Adjust-
ment to Straighten Lines and Colors.")
Print a test pattern for adjustment of the Printhead orienta-
tion. (See "Adjusting Line Misalignment.")
Menu Settings
P.550
➔
P.553
P.552
➔
P.554
➔
445
