Removing Printed Documents from the Media Take-up Unit (Optional)
8
Remove the Rewind Spool from the Media Take-up Unit.
Important
9
Unlock the flange on the left side of the Rewind Spool by
lifting the lever (a) from the shaft side. Remove the flange.
10
Remove the entire paper core with the rewound printed
documents from the Rewind Spool.
Note
374
•
Always turn off the Media Take-up Unit before removing the Rewind Spool. The Media Take-up Unit may
be damaged if you do not turn it off first.
•
Remove the Rewind Spool, pulling off both ends from the Media Take-up Unit at once. If you do not pull
off both ends at once, the Media Take-up Unit may become damaged.
•
You can leave the Rewind Spool on the Media Take-up Unit even when it is not used for rewinding rolls.
a
