Attaching the Roll Holder to Rolls
3
With the edge of the roll paper facing forward as shown, in-
sert the Roll Holder from the right of the roll. Insert it firmly
until the roll touches the flange (a) of the Roll Holder.
Important
4
Insert the attachments for the roll paper core on the Holder Stopper.
Align the tips (a) of the attachment with the holes (b) of the Holder Stopper and insert it firmly.
• 3-Inch Paper Core Attachment #2
• 2-Inch Paper Core Attachment
332
•
When loading a roll, be careful to avoid hitting the printer hard with the roll. This may damage the Roll
Holder.
a
b
b
iPF830
a
a
User's Guide
