Enabling Roll Take-Up; Disabling Roll Take-Up - Canon imagePROGRAF iPF830 User Manual

Enabling Roll Take-Up

•
The Media Take-up Unit cannot be used with sheets.
•
Important
If you have attached the Output Stacker, always stow it before using the Media Take-up Unit. (See "Stowing the
Stationary Output Stacker.")
•
Position the Basket Cloth and Basket Rod so they do not interfere with the Media Take-up Sensor. This may
impair operation. (See "Stowing the Stationary Output Stacker.")
•
Rolls are not cut automatically when the Media Take-up Unit is used, regardless of the Cutting Mode setting in
the printer menu or the Automatic Cutting setting in the printer driver. However, you can cut paper by pressing
the Cut button.
•
Color tones after printing may change during the ink drying period for some types of paper. Allow ample drying
time before the final check of colors, and do not remove printed documents from the Media Take-up Unit too
soon.
•
In humid environments, documents printed using plenty of ink on relatively insubstantial media such as light-
weight Canon Coated Paper may not be retracted evenly by the unit. In this case, take steps to control humidity
in the operating environment, or adjust the Roll DryingTime setting so that printed documents are retracted after
the ink has fully dried.
•
In humid environments, documents printed on Fabric Banner or Adhesive Synthetic Paper may not be retrac-
ted evenly by the unit. In this case, take steps to control humidity in the operating environment, or adjust the Roll
DryingTime setting so that printed documents are retracted after the ink has fully dried.

Enabling Roll Take-Up

Enabling Roll Take-Up
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab (
Note
2
Press the OK button.
The Set./Adj. Menu is displayed.
3
Press ▲ or ▼ to select Take-up Reel, and then press the OK button.
4
Press ▲ or ▼ to select Use Take-up Reel, and then press the OK button.
5
Press ▲ or ▼ to select Enable, and then press the OK button.

Disabling Roll Take-Up

Disabling Roll Take-Up

1
Press the Cut button.
2
Press ▲ or ▼ to select Yes, and then press the OK button.
366
The mode now switches from take-up mode to regular mode.
Note
P.360
➔
).
•
If the Tab Selection screen is not displayed, press the Menu button.
•
The printer will also switch from take-up mode to regular mode if you lift the Release Lever and cut the roll
with scissors instead of pressing the Cut button.
P.360
➔
iPF830
User's Guide
