Rx2C SERIES EQUVALENT DIFFERENTIAL IMPEDANCE
FREQUENCY (70MHz TO 6GHz)
Rx2C
450
400
350
300
250
200
150
100
50
0
Figure 46. AD9361 Rx2C Input Differential Impedance
450
400
350
300
250
200
150
100
50
0
FREQUENCY (GHz)
Figure 47. AD9361 Rx2C Input Differential Impedance Magnitude
