5. Program the LNA gain step words into the internal table.
Table 37. Programming the LNA Gain Steps into the Internal Table
Command Addr/Data
SPIWrite 143,61
SPIWrite 140,00
SPIWrite 141,aa
SPIWrite 143,63
WAIT 3us
SPIWrite 140,01
SPIWrite 141,bb
SPIWrite 143,63
WAIT 3us
SPIWrite 140,02
SPIWrite 141,cc
SPIWrite 143,63
WAIT 3us
SPIWrite 140,03
SPIWrite 141,dd
SPIWrite 143,63
WAIT 3us
SPIWrite 143,01
SPIWrite 143,00
6. Turn on the external single tone at the amplitude determined previously and inject it into Rx1.
7. Run the calibration by setting 0x016[D3].
8. The calibration completes when 0x016[D3] clears.
9. Read the LNA and Mixer error terms as shown in Table 38 into nonvolatile memory.
Table 38. Reading Gain Step Error Words from the
Line
Number Command
1 SPIWrite
2 SPIWrite
3 SPIRead
4 Repeat Step 2 and Step 3 for 3 remaining LNA indices
5 SPIWrite
6 SPIWrite
7 SPIRead
8 Repeat Step 6 and Step 7 for 14 remaining Mixer indices
9 SPIWrite
Programming Gain Step Errors in the Field
During initialization (while the transceiver is in the Alert or Wait states), program the two configuration registers as shown in Table 39
(again, "xx" is the value from Table 35).
Table 39. Config Registers
Line Number Command
1 SPIWrite
2 SPIWrite
Comment
//Write R1 and R2 internal LNA tables & start clock
//LNA index
//LNA gain step from Table 35
//Write data
//Wait for data to fully write to internal table
//LNA index
//LNA gain step from Table 35
//Write data
//Wait for data to fully write to internal table
//LNA index
//LNA gain step from Table 35
//Write data
//Wait for data to fully write to internal table
//LNA index
//LNA gain step from Table 35
//Write data
//Wait for data to fully write to internal table
//Clear write bit
//Stop clock
AD9361
Addr/Data
143,30
140,00
142
143,20
140,00
142
143,00
Addr/Data Comment
145,0F //Set maximum mixer gain index (always 0x0F)
15D,xx //Maximum LNA Gain (from Table 35)
