UG-570

POWER DISTRIBUTIONS FOR DIFFERENT POWER SUPPLY DOMAINS

The
AD9361
has 17 power supply balls. These balls power up different circuits on the part. Table 55 shows the ball number, the ball name,
the recommended routing technique for that ball from the main 1.3 V analog supply plane and a brief description of the block it powers
up in the chip. In some cases, one finger is used to power up two to three 1.3 V power supply balls while in some cases there are some
power supply balls that have a finger just for themselves. Table 55 shows which power supply balls have their own fingers and which balls
are tied together and share one finger. Fingers provide isolation for the concerned 1.3 V power supply balls. Figure 91 shows this
structure.
Table 55. Power Supply Balls on the
Ball
Ball Name
A11
VDDA1P1_TX_VCO
B8
VDD_GPO
B9
VDDA1P3_TX_LO
B10
VDDA1P3_TX_VCO_LDO
B11
TX_VCO_LDO_OUT
D2
VDDA1P3_RX_RF
D3
VDDA1P3_RX_TX
E2
VDDA1P3_RX_LO
E3
VDDA1P3_TX_LO_BUFFER
F2
VDDA1P3_RX_VCO_LDO
F12
VDDD1P3_DIG
G2
RX_VCO_LDO_OUT
G3
VDDA1P1_RX_VCO
H12
VDD_INTERFACE
J3
VDDA1P3_RX_SYNTH
K3
VDDA1P3_TX_SYNTH
K4
VDDA1P3_BB
Tx1
TX BALUN DC FEED
Tx2
TX BALUN DC FEED
AD9361
Recommended Routing
Short to B11 with 1µF bypass capacitor
1 Ω series resistance
GPO pull-up voltage (1.3 V to 3.3 V)
1.3 V separate trace to common supply
point
Short to B9
Short to A11
Short to D3
Short to E3
Short to F2
1.3 V separate trace to common supply
point
1.3 V separate trace to common supply
point
1.3 V separate trace to common supply
point
Short to G3
Short to G2 with 1µF bypass capacitor
1 Ω series resistance
Interface pull-up voltage (1.3 V to 2.5 V)
1.3 V separate trace to common supply
point
1.3 V separate trace to common supply
point
1.3 V separate trace to common supply
point
VIA directly to 1.3 V plane
VIA directly to 1.3 V plane
Rev. A
Description
Powers supply for Tx VCO in the chip
Power supply for the GPO balls
Power supply for Tx LO Generator and LO divider
Power supply for the Tx VCO LDO
Output of the Tx VCO LDO needed to power the Tx VCO on
the chip
Power supply for the Rx LNAs and the mixer GM stages
Power supply for Tx Low pass filter, Tx monitor, Rx trans
impedance amplifier, Rx low pass filter, AuxDAC
Power supply for Rx LO generator and LO divider
Power supply to the Tx LO buffer that goes to the up
converter
Power supply input for the Rx VCO LDO
Powers the digital core
Output of the Rx VCO LDO needed to power the Rx VCO
LDO in the chip
Power supply for the Rx VCO on the chip
Powers the digital interface of the chip
Powers the charge pump, sigma delta modulator and the
VCO calibration block of the Rx synthesizer
Powers the charge pump, sigma-delta modulator and the
VCO calibration block of the Tx synthesizer
Powers the Tx DACs, Rx ADCs and AuxADC
Provides power to the Tx output on Channel 1
Provides power to the Tx output on Channel 2
| Page 124 of 128
