SPECIFICATIONS AND REQUIREMENTS

5

WEIGHT

Maximum Cube Weight (with cartridges):
Maximum Box Weight:

SOFTWARE

Complimentary Cubify software for Windows and Mac OS X as well as iOS and Android mobile applications . These applications
generate .cube3 file for printing on your printer.

OPENGL VERSION

• OpenGLES 2 .0+ on mobile platforms
• Open GL 3 .0+ on Windows and Mac (using 3 .2 library of GLU)

WINDOWS REQUIREMENTS

• Cubify software runs on 32- and 64-bit operating systems
• Windows 7, 8 and 8 .1
• Minimum screen resolution: 1024 x 768
• Windows is required for Ad Hoc Wi-Fi print job submission .

MAC OS X REQUIREMENTS

• OS X 10 .8 and 10 .9
• Minimum screen resolution: 1400 x 900

ANDROID

• 4 .0 ICS (tablets supported)

IOS

• 6 .0+ (iPhone4 and newer)
• Minimum screen resolution: iPhone4

WIRELESS OPTIONS

• 802 .11b/g with WPS Infrastructure
• Ad Hoc mode

USB MASS STORAGE DEVICE

• USB mass storage device (supplied with the printer) to transfer print files to the printer using the USB inlet port.

ELECTRICAL REQUIREMENTS

Outlet Requirements 100 - 240 Volts, at 50/60 Hz
Electrical Rating: 24V DC, 5 amp .

MATERIAL STORAGE

All polymers degrade with time . The following conditions ensure the material remains high quality:
• Do not unpack cartridges from the foil until the material is needed .
• Store at room temperature: 16-29
• Non-condensing relative humidity: 5% - 25%
3D Systems, Inc.
17 lbs . (7 .7 kg)
23 lbs . (10 .43 kg)
C (60 - 85
° ° F)
