3
Generation
rd
Personal 3D Printer
Quick Start Guide
See Inside for Use and Safety Information
The USB Mass Storage Device Contains the User Guide and
Quick Start Guide in other Languages

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cube and is the answer not in the manual?

Questions and answers

Related Manuals for 3D Systems Cube

Summary of Contents for 3D Systems Cube

  • Page 1 Generation Personal 3D Printer Quick Start Guide See Inside for Use and Safety Information The USB Mass Storage Device Contains the User Guide and Quick Start Guide in other Languages...

  • Page 3: Table Of Contents

    Congratulations on the purchase of your new Cube® 3D Printer! This Quick Start Guide has the use and safety information you need to get started. Welcome to the 3D creative revolution – let the possibilities begin! If you have any questions, do not hesitate to reach us at cubifysupport@cubify.com.

  • Page 4: Safety

    • Follow all safety rules in this section and observe all cautions and warnings in this guide. • DO NOT modify any safety features or make modifications to the Cube. Doing so is prohibited and voids your warranty. • Use of print materials other than 3D Systems print materials and genuine 3D Systems components may void warranty.

  • Page 5: Your Cube At A Glance

    YOUR CUBE AT A GLANCE Print Jets Print Jet Tubes Material Cartridges Print Pad Print Platform Touchscreen Display On / Off Button USB Inlet Port (mass storage device only) Power Inlet Refuse Bins with Wipers...

  • Page 6: Unpack Your Cube

    UNPACK YOUR CUBE NOTE: Keep all packing materials for future transport. Shipping the printer without the original packing materials may damage the printer and void the manufacturer’s warranty. Pull the clips (A) and remove them from the top of the printer box and open the box.
  • Page 7 Front View Top View 8” (203 mm) 4” (102 mm) Back Front 4” (102 mm) Hand Clearance Around the Printer Build Plate Travel Area Remove the top insert. Fold the sides inward and remove the lower insert from the printer.
  • Page 8 Open the accessories box and unpack the material cartridges, the USB mass storage device, the power supply, cord, and the Cube Glue bottle. Connect the power supply cable to the power inlet port (A) on the printer.

  • Page 9: What's Included

    WHAT’S INCLUDED Cube Removable Print Pad Cartridges Cube Glue Power Supply Power Cord Pliers Scraper Quick Start Guide Casing and its contents Casing Sandpaper Gap Gauge USB Mass 1.5 mm Allen Storage Device* Wrench Depending on your printer model or configuration, up to two cartridges may be included.

  • Page 10: Setting Up And Activating Your Cube

    SETTING UP AND ACTIVATING YOUR CUBE Select your language. Press the checkmark to confirm your selection. NOTE: The selected language will be indicated. Enter a name for your printer. Scroll through the letters by pressing the arrow symbols on each side of the screen.
  • Page 11 NOTE: The printer will attempt to connect to your network. NOTE: If your network is password protected, your printer will first prompt you to enter the password. Once entered, select the checkmark to continue. NOTE: The display will indicate when the network connection has been made.
  • Page 12 NOTE: If the wrong password was entered, you will be asked to enter the password again after a few seconds. NOTE: Connection to a network is confirmed by a checkmark to the left of the network name. If the network is secured, a lock icon will appear to the right of the network name.
  • Page 13 Log in to Cubify.com. Go to www.cubify.com and select Cubify. Enter your username and password and select Login. NOTE: If you have not activated your account on Cubify, select SIGN UP and follow the instructions. Go to www.cubify.com/activate. NOTE: The serial number for your printer will appear on the printer’s touchscreen...
  • Page 14 serial number Enter your twice and select ACTIVATE. NOTE: Your 4-digit activation code will appear. Please make note of the activation code because it will need to be entered into the printer’s touchscreen display to activate the printer. NOTE: You can access the user guide, Cubify software, and creations.
  • Page 15 activation code Enter the 4-digit into the printer and select the checkmark to continue. checkmark Select the to complete the registration and warranty activation process. Before installing cartridges, select the cartridge icon or select START to begin the process of installing your print cartridge.
  • Page 16 NOTE: The printer will begin to heat. Wait until the printer has finished heating and then follow the user prompts in the touchscreen menu. Insert the print jet (from the cartridge that will be mounted on the left side of the printer) into the top of the printer. Rotate the print jet clockwise until the dots align.
  • Page 17 NOTE: The print jet will begin to heat. Once the print jet has reached the operating temperature, the printer will prime melted material into the refuse bin. The left cartridge has been installed. Select the checkmark to continue. NOTE: The printer will begin to heat. Wait until the printer has finished heating and then follow the user prompts in the touchscreen menu.
  • Page 18 Insert the print jet (from the cartridge that will be mounted on the right side of the printer) into the top of the printer. Rotate the print jet clockwise until the dots align. NOTE: As you rotate the print jet, ensure the print jet tube is tucked under the top of the printer cover.
  • Page 19 The right cartridge has been installed. Select the checkmark to continue. PRINT Press to continue. It is recommended that Auto Level is performed prior to the first print. Ensure the print pad is clean and installed properly and then select the checkmark to continue to Auto Level.
  • Page 20 NOTE: The printer will begin the Auto Level procedure. This may take a few minutes. checkmark Select the to continue. NOTE: If the print pad is not level, remove the print pad and select the checkmark to continue. The print pad is magnetically attached to the adjustment knobs.
  • Page 21 NOTE: Follow the instructions on the screen. Use the included 1.5 mm Allen wrench to loosen the set screws securing the adjustment knobs to the bracket before turning the knobs. Select the checkmark to continue. You will be prompted to perform the Auto Level procedure again.
  • Page 22 checkmark Select the to continue. NOTE: The value presented on the touchscreen display is the absolute print pad position. Note and refer to this value when performing the Manual Level procedure. Your number may differ from the illustration. NOTE: If Auto Gap is not successful, it is recommended that you perform Auto Level and Auto Gap again.
  • Page 23 Select the checkmark to continue. Gently squeeze the bottle and apply a thin layer of Cube Glue to the print pad. Select the checkmark to continue. NOTE: Apply enough glue to cover a square area of 5”/15 cm.
  • Page 24 NOTE: The print jets will begin to heat and then begin printing the welcome message. checkmark Select the to go to the main screen. NOTE: You may also press and release the button next to the touchscreen display to return to the main menu.
  • Page 25 Function Checklist If you skip or exit from a function during the printer setup sequence below, that function can be performed at any time using the utilities in the menu. LANGUAGE CUBE NAME WIFI √ ACTIVATE PRINTER INSTALL CARTRIDGES AUTO LEVEL...

  • Page 26: Finishing Your Creation

    FINISHING YOUR CREATION REMOVING YOUR CREATION FROM THE PRINT PAD Remove the print pad and place it in a container filled with warm tap water. Allow it to soak for approximately ten minutes or until your creation can be easily removed from the print pad. After it has soaked, gently pry the creation from the print pad using the included scraper.

  • Page 27: Maintenance

    MAINTENANCE PRINT PAD MAINTENANCE Auto Level and Auto Gap can be affected by a residual glue or print material adhered to the print pad. These procedures can also be affected by a print pad that is too shiny. Select PLATE MAINTENANCE.
  • Page 28 Clean and dry the print pad thoroughly. Reinstall the print pad with the Cube symbol (A) on the front of the print pad aligned the Cube symbol (B) on print platform. Perform Auto Level and Auto Gap Procedures.

  • Page 29: Gap Verification

    GAP VERIFICATION After the welcome message has printed and has been removed from the print pad, visually inspect the first (bottom) layer of the print and verify the quality. Turn the print upside down and inspect the printing grain. When the gap is optimal, the bottom of the print should appear smooth and the lines should be very light and fused together.
  • Page 30 Gap Is Too Large If the lines are more prominent (see the illustration below) and not tightly fused, the gap is too large. Auto Level and Set Plate Z-Height should be performed. If the first layer begins to fray when removing the print from the print pad, the gap is too large. Gap Is Too Narrow When the gap is too narrow, the part may be very difficult to remove from the print pad.

  • Page 31: Manual Gap Adjustment

    MANUAL GAP ADJUSTMENT If Auto Gap is unsuccessful, you may perform a manual gap adjustment to ensure the first layer of the part prints properly. Select MANUAL GAP ADJUSTMENT. Place the gap gauge on top of the print pad under the left print jet.
  • Page 32 3D Systems, Inc. 333 Three D Systems Circle | Rock Hill, SC | 29730 www.Cubify.com ©2014 3D Systems, Inc. All rights reserved. The 3D Systems logo, 3D Systems, Cube and Cubify are registered trademarks of 3D Systems, Inc. PN: 390186-00 Rev. C...
