Chapter 3
(8) Wait about 15 minutes after completion of the "Move Printer" operation, remove the maintenance cartridge,
and then package it so that waste ink does not leak.
Check that waste ink is no longer leaking after removing the maintenance cartridge. If it is leaking, install the
maintenance cartridge and wait until waste ink no longer leaks.
(9) Attach the cushioning materials and tape.
(10) If the printer is installed on a stand, remove it from the stand.
(11) Pack the printer in the packing box, and then put the roll media, ink tank, and optional devices in another
packing box for moving.
Use the original packing materials for the printer and other optional devices. If they are not available, pack them
with a sufficient amount of cushioning materials.
When the printer is not operating properly
(1) Make sure that the printer is turned off.
(2) Disconnect the interface cable, power cord, and ground cable from the printer.
(3) Remove the roll holder from the roll holder slot.
(4) Drain ink from the printer.
(5) Manually cap the printhead.
* Manual capping is an emergency measure used when the printer does not operate properly, so it can damage
the printhead.
(6) Remove the maintenance cartridge, and then package it so that waste ink does not leak.
(7) Attach all external covers.
(8) Open the top cover, and then secure the carriage with the belt stopper.
(9) Close the top cover.
(10) Attach the cushioning materials and tape.
(11) If the printer is installed on a stand, remove it from the stand.
(12) Pack the printer in the packing box, and then put the roll media, ink tank, and optional devices in another
packing box for moving.
Use the original packing materials for the printer and other optional devices. If they are not available, pack them
with a sufficient amount of cushioning materials.
Before transporting the printer, be sure to go through the following steps to protect the internal mechanism. For
the printer packaging work and the installation work after transportation, refer to the "Quick Start Guide".
* When "Check Free Space in Maintenance C" or "Replace Maintenance Cartridge" is shown on the display,
you cannot make preparations for transportation. First replace the maintenance cartridge, and then make
preparations for transportation.
* Do not incline the printer during transportation. The internal ink may leak and the surrounding area may be
stained. If it is necessary to place the printer with either side up or down or to incline the printer, contact your
sales agent.

3.1.2 Reinstalling the Printer

3.1.2.1 Reinstalling the Printer
When installing the printer after moving it on the same floor having no step
If you have moved the printer to the installation site on the same floor having no step without draining ink, check
the operation test pattern.
When installing the printer after moving it on the same floor having a step(s)
If you have moved the printer to the installation site on the same floor having a step(s) with ink drained, install
it again in the same manner as that for initial installation after reception of the delivered printer.
1) Unpack the printer.
2) Remove the cushioning materials and tape from the printer.
3) Install the maintenance cartridge.
4) Remove the belt stopper.
5) Connect the power cord.
6) Turn on the Power button and install ink tanks according to the displayed messages. Ink filling will starts.
Load paper and check for normal operation.
