Canon imageprograf ipf700 Service Manual page 163

J102
Pin
Signal name
Number
28 H1-D-DATA-7-OD
29 H1_CLK
30 H1-C-DATA-5-OD
31 /H1-C-HE-5
32 H1-C-DATA-5-EV
33 /H1_LT
34 H1-C-DATA-4-EV
35 /H1-B-HE-3
36 H1-B-DATA-3-EV
37 H1-B-DATA-2-EV
38 /H1-A-HE-1
39 H1-A-DATA-1-EV
40 H1-A-DATA-0-EV
41 /H1-A-HE-0
42 H1-A-DATA-0-OD
43 H1-A-DATA-1-OD
44 /H1-B-HE-2
45 H1-B-DATA-2-OD
46 H1-B-DATA-3-OD
47 /H1-C-HE-4
48 H1-C-DATA-4-OD
49 MLT_SNS_1IN
50 MLT_SNS_2IN
J201
Pin
Signal name
Number
1 PWLED1
2 PWLED2
3 PWLED3
4 PWLED4
5 GND
6 MLT_SNS_1
7 +5V
8 MLT_SNS_2
IN/OUT Function
IN Odd head data signal 7(D)
IN Head clock signal
IN Odd head data signal 5(C)
IN Head heat enable signal 5(C)
IN Even head data signal 5(C)
IN Head latch signal
IN Even head data signal 4(C)
IN Head heat enable signal 3(B)
IN Even head data signal 3(B)
IN Even head data signal 2(B)
IN Head heat enable signal 1(A)
IN Even head data signal 1(A)
IN Even head data signal 0(A)
IN Head heat enable signal 0(A)
IN Odd head data signal 0(A)
IN Odd head data signal 1(A)
IN Head heat enable signal 2(B)
IN Odd head data signal 2(B)
IN Odd head data signal 3(B)
IN Head heat enable signal 4(C)
IN Odd head data signal 4(C)
OUT Multi sensor signal 1
OUT Multi sensor signal 2
T-6-26
IN/OUT Function
OUT Multi sensor LED1 drive signal
OUT Multi sensor LED2 drive signal
OUT Multi sensor LED3 drive signal
OUT Multi sensor LED4 drive signal
- GND
IN Multi sensor signal 1
OUT Power supply (+5V)
IN Multi sensor signal 2
Chapter 6
6-37
