Canon imageprograf ipf700 Service Manual page 147

J2502
Pin
Signal name
Number
1 INKBENM1_AM
2 INKBENM1_AP
3 SNS3V
4 GND
5 /INKBEN_OPEN_R
6 /TANKCOVER_R
7 GND
8 N.C.(SNS3V)
9 N.C.(GND)
10 N.C.(/INKBEN_CAM_R)
J2601
Pin
Signal name
Number
1 POWER_ON
2 GND
3 +5V
4 BUZZER
5 PDO
6 +3.3V
7 PDI
8 GND
9 /PRESET
10 GND
11 PCK
12 PANEL5V_ON
13 /PCS
J2701
Pin
Signal name
Number
A1 /LFENCB
A2 +5V
A3 LF_ENCA
T-6-3
IN/OUT Function
OUT Valve motor drive signal AM
OUT Valve motor drive signal AP
OUT Power supply (+3.3V)
- GND
Valve open/close detection sencor output
IN
signal
IN Ink tank cover switch output signal
- GND
- N.C.
- N.C.
- N.C.
T-6-4
IN/OUT Function
IN Power switch signal
- GND
OUT Power supply (+5V)
OUT Buzzer control signal
OUT Panel IC control signal
OUT Power supply (+3.3V)
OUT Panel IC data signal
- GND
OUT Panel reset signal
- GND
OUT Panel IC clock signal
OUT Power supply (+5V)
OUT Panel IC chip select signal
T-6-5
IN/OUT Function
IN Feed roller encoder output signal B
OUT Power supply (+5V)
IN Feed roller encoder output signal A
Chapter 6
6-21
