Canon imageprograf ipf700 Service Manual page 146

Chapter 6
J1801
Pin
Signal name
Number
8 VM
9 VMGND
10 VMGND
11 VM_ENB
12 AFCONT
J2501
Pin
Signal name
Number
A1 N.C
A2 N.C(GND)
A3 N.C(LIFT_CAM)
A4 SNS3V
A5 GND
A6 /CRHP
A7 LIFTM_VM
A8 LIFTM0_A
A9 LIFTM2_AX_N0
A10 LIFTM1_B
A11 LIFTM3_BX_N1
A12 /ATUKAIJYO
A13 GND
B1 PUMPM1_AM
B2 PUMPM1_AP
B3 GND
B4 PUMPR_ENCA
B5 SNS5V
B6 PUMPR_ENCB
B7 SNS3V
B8 GND
B9 /CONTROL_CAM_R
B10 GND
B11 /MEDIA_R
B12 SNS5V
B13 N.C
6-20
IN/OUT Function
IN Power supply (+32V)
- GND
- GND
OUT VM enable signal
OUT Normal/power saving switch signal
T-6-2
IN/OUT Function
- N.C
- N.C
- N.C
OUT Power supply (+3.3V)
- GND
IN Lift cam sensor output signal
OUT Power supply (+32V)
OUT Lift motor Drive signal A
OUT Lift motor Drive signal AX
OUT Lift motor Drive signal B
OUT Lift motor Drive signal BX
IN Pressure release switch output signal
- GND
OUT Pump motor Drive signal AM
OUT Pump motor Drive signal AP
- GND
IN Pump encoder output signal A
OUT Power supply (+5V)
IN Pump encoder output signal B
OUT Power supply (+3.3V)
- GND
IN Pump cam sensor output signal
- GND
IN Media sensor output signal
OUT Power supply (+5V)
- N.C
