Page 1 Large Format Printer User's Guide Basic Printing Workflow Enhanced Printing Options Printing CAD Drawings ............42 Printing enlargements or reductions ........62 Printing at full size ..............76 Borderless Printing ..............86 Printing banners or at other non-standard sizes ..... 98 Tiling and multiple pages per sheet ........
Page 2 Note In order to be printed easily, this PDF-format manual is converted from the HTML-format instruction manual inclu- ded on the "User Manuals CD-ROM" supplied with the printer. Thus, there are descriptions that are applied only in HTML format, and functions (video display function, etc.) that cannot be used. We appreciate your understanding.
Page 3: Table Of Contents
Contents Basic Printing Workflow Printing procedure Printing Options Using Rolls and Sheets ........................ 16 Turning the Printer On and Off ..........................17 Loading and Printing on Rolls ..........................19 Loading and Printing on Sheets ..........................21 Printing in Windows ..............................22 Printing from Mac OS X ............................
Page 4 Resizing Originals by Entering a Scaling Value (Windows) ................71 Resizing Originals by Entering a Scaling Value (Mac OS X) ................73 Printing at full size Printing on Oversized Paper ........................... 76 Printing at Full Size (Windows) .......................... 77 Printing at Full Size (Mac OS X) ........................78 Borderless Printing at Actual Size ..........................
Page 5 Making the Original Orientation Match the Paper Orientation (Windows) ............148 Making the Original Orientation Match the Paper Orientation (Mac OS X) ............. 149 Using Favorites ..............................152 Cutting Roll Paper After Printing ........................... 152 Cutting Roll Paper After Printing (Windows) ....................152 Cutting Roll Paper After Printing (Mac OS X) ....................
Page 6 Zoom Dialog Box ..............................202 Format Dialog Box ..............................203 Laying out a Multiple-File Document on One Page ....................204 Laying out a Document Created with Multiple Application Programs on One Page ..........206 Selecting an Object .............................. 208 Changing the Object Size ............................. 209 Moving an Object ..............................
Page 7 Configuring Unit Costs in Accounting Manager ....................269 Setting the Unit Cost for Ink ..........................269 Setting the Unit Cost for Paper ........................270 Setting the Unit Cost for Items Other Than Ink and Paper ................271 Configuring Units and Display Settings in Accounting Manager ................. 272 Automatically Acquiring Print Job Logs at Regular Intervals ................
Page 8 Output Settings Panel ............................318 Color Settings Panel .............................. 320 Color Adjustment ............................. 321 Matching ................................. 323 Driver Matching Mode ..........................324 ICC Matching Mode ..........................325 ColorSync ..............................326 Preferences Dialog Box ............................326 Zoom Dialog Box ..............................327 Go to Page Dialog Box ............................
Page 9 ICC Matching Mode ............................371 ColorSync ................................ 372 Printing Enlargements of Scanned Originals from a Color imageRUNNER ............372 Printmonitor The Features of imagePROGRAF Printmonitor ..................... 374 Job Management Using imagePROGRAF Printmonitor ..................375 Media Configuration Tool The Features of Media Configuration Tool ......................376 Procedures for Installing ............................
Page 10 Printer Menu Printer Menu Operations ............................438 Menu Operations ..............................439 Menu Structure ..............................442 Menu Settings ............................... 448 Status Print ................................457 Printing Interface Setting Reports ......................... 459 Printer Parts Printer parts Front ..................................464 Side ..................................465 Top Cover (Inside) ..............................466 Roll Cover (Inside) ..............................
Page 11 Adjustments for Better Print Quality Adjusting the Printhead Adjusting the Printhead ............................502 Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.) ............502 Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) ............503 Adjusting Line Misalignment (Head Inc. Adj.) ...................... 505 Troubleshooting Paper Abrasion and Blurry Images (Head Height) ..............
Page 12 Depression on the leading edge is left ......................... 557 The size of clear film cannot be detected ......................557 Roll Paper is Continuously Ejected ........................557 Printing does not start The Data lamp on the Control Panel does not light up ..................558 The printer does not respond even if print jobs are sent ..................
Page 13 Error Message Error Messages Messages regarding paper MediaType Mismatch ............................580 The paper is too small............................580 The paper is too small............................581 PaprWidth Mismatch ............................. 582 Paper size not detected............................582 Insufficient paper for job ............................583 This paper cannot be used.
Page 14 GL2: W0502 The parameter is out of range......................594 GL2: W0504 This command is not supported...................... 594 Other Messages GARO Wxxxx (x represents a number) ......................... 595 ERROR Exxx-xxxx (x represents a letter or number) .................... 595 Hardware error. xxxxxxxx-xxxx (x represents a letter or number) ................. 595 Top cover is open.
Page 15: Basic Printing Workflow
User's Guide Basic Printing Workflow Printing procedure ..............16 Canceling print jobs ..............25 Pausing Printing ................. 28 Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality...
Page 16: Printing Procedure
Printing Options Using Rolls and Sheets iPF760 Printing procedure Printing procedure Printing Options Using Rolls and Sheets ....................... 16 Turning the Printer On and Off ........................17 Loading and Printing on Rolls ........................19 Loading and Printing on Sheets ........................21 Printing in Windows ............................
Page 17: Turning The Printer On And Off
Press the Power button to turn on the printer. The printer will now start up. After the Display Screen shows the Canon logo, "Starting up... Please wait." is displayed. The Power Lamp is lit when the printer finishes starting up, and the printer is now in Standby.
Page 18 Turning the Printer On and Off iPF760 • If ERROR is shown on the Display Screen see "Error messages." →P.578 • The Power Lamp and Message Lamp are not lit (even once), and nothing appears on the Display Screen Make sure the printer is plugged in correctly. Check the connection at the plug and electrical outlet.
Page 19: Loading And Printing On Rolls
Loading and Printing on Rolls Hold down the Power button for more than a second. After "Shut Down.. Please Wait.." is shown on the Display Screen, the printer shuts off. Loading and Printing on Rolls Loading and Printing on Rolls These are the basic steps for loading and printing on rolls.
Page 20 Loading and Printing on Rolls iPF760 Load the roll in the printer. (See "Loading Rolls in the Printer.") →P.399 Select the type of paper. (See "Changing the Type of Pa- per.") →P.402 • If no barcode has been printed on the roll and you have set ManageRemainRoll to On, specify the roll length after the type of paper.
Page 21: Loading And Printing On Sheets
Loading and Printing on Sheets Send the print job. • Printing in Windows →P.22 • Printing from Mac OS X →P.23 The printer now starts printing the print job. Loading and Printing on Sheets Loading and Printing on Sheets These are the basic steps for loading sheets and then printing.
Page 22: Printing In Windows
Printing in Windows iPF760 Send the print job. • Printing in Windows →P.22 • Printing from Mac OS X →P.23 Load the sheet. (See "Loading Sheets in the Printer.") →P.417 The printer now starts printing the print job. Printing in Windows Printing in Windows Print from the application menu.
Page 23: Printing From Mac Os X
Printing from Mac OS X After confirming that the printer is selected in the dialog box, click Print or OK to start printing. • The appearance of the dialog box varies depending on the software application. In most cases, the dialog box...
Page 24 Printing from Mac OS X iPF760 Click Print to start printing. As shown in the following illustration, you can switch to other panes in this dialog box to complete settings for various methods of printing, including enlarged and reduced printing, borderless printing, and so on.
Page 25: Canceling Print Jobs
Canceling Print Jobs from the Control Panel Canceling print jobs Canceling print jobs Canceling Print Jobs from the Control Panel ....................25 Canceling Print Jobs from Windows ......................26 Canceling Print Jobs from Mac OS X ......................26 Canceling Print Jobs from the Control Panel Canceling Print Jobs from the Control Panel To cancel printing or reception of print jobs, press the Stop button on the Control Panel.
Page 26: Canceling Print Jobs From Windows
Canceling Print Jobs from Windows iPF760 Canceling Print Jobs from Windows Canceling Print Jobs from Windows In the printer window, you can cancel jobs that are being sent to the printer. Using imagePROGRAF Status Monitor, you can cancel print jobs that have already been received by the printer or that are currently being printed.
Page 27 Canceling Print Jobs from Mac OS X Click Pause Printer to stop printing. If there are no jobs in the printer window that can be canceled, (that is, if the print data has already been sent to the printer), click Utility to display image- PROGRAF Printmonitor.
Page 28: Pausing Printing
Pausing Printing iPF760 Pausing Printing Pausing Printing Pausing Printing Pausing Printing During printing, if you set Pause Print in the Control Panel menu to On, printing is stopped at that point and the printer enters a state in which printing is paused. (See "Control Panel Display.") →P.431...
Page 29: Enhanced Printing Options
User's Guide Basic Printing Workflow Enhanced Printing Options Choosing Paper for Printing ............30 Printing Photos and Office Documents ........31 Printing CAD Drawings .............. 42 Adjusting Images ................ 50 Printing enlargements or reductions .......... 62 Printing at full size ..............76 Borderless Printing ..............
Page 30: Choosing Paper For Printing
Choosing a Paper for Printing iPF760 Choosing Paper for Printing Choosing Paper for Printing Choosing a Paper for Printing ........................30 Specifying Paper in the Printer Driver ......................30 Choosing a Paper for Printing Choosing a Paper for Printing Choosing the right paper for your particular printing application will give you the best printing results.
Page 31: Printing Photos And Office Documents
Printing Photos and Images Printing Photos and Office Documents Printing Photos and Office Documents Printing Photos and Images ........................... 31 Printing Photos and Images (Windows) ....................32 Printing Photos and Images (Mac OS X) ....................33 Printing Office Documents ..........................36 Printing Office Documents (Windows) ......................
Page 32: Printing Photos And Images (Windows)
Printing Photos and Images (Windows) iPF760 Print Quality Description Fast Printing in draft mode can help you work more efficiently when checking layouts. For instructions on printing photos and images, refer to the following topics, as appropriate for your computer and operating system.
Page 33: Printing Photos And Images (Mac Os X)
Printing Photos and Images (Mac OS X) Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click 10"x12".
Page 34 Printing Photos and Images (Mac OS X) iPF760 This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 35 Printing Photos and Images (Mac OS X) Make your selection in the Print Quality list. Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, 10 in.
Page 36: Printing Office Documents
Printing Office Documents iPF760 Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) " →P.294 Note Printing Office Documents Printing Office Documents Printing is easy when you simply choose the type of original to print.
Page 37 Printing Office Documents (Windows) Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. After confirming that Easy Settings is selected, click Office Document in the Print Target list.
Page 38: Printing Office Documents (Mac Os X)
Printing Office Documents (Mac OS X) iPF760 Printing Office Documents (Mac OS X) Printing Office Documents (Mac OS X) This topic describes how to print office documents based on the following example. • Document: Office document created using word-processing or spreadsheet programs •...
Page 39: Using Posterartist To Compose Originals
Using PosterArtist to Compose Originals After confirming that Easy Settings is selected, click Office Document in the Print Target list. • You can check the settings values selected in the Print Target list by clicking View set.. Note Make your selection in the Print Quality list.
Page 40 Using PosterArtist to Compose Originals iPF760 Select the printer in the dialog box, and then open the printer driver dialog box. (See "Accessing the Printer Driver Dialog Box from Applications(Windows).") →P.164 Make sure the Main sheet is displayed. Click the Layout tab to display the Layout sheet.
Page 41 Using PosterArtist to Compose Originals Choose the page to load in PosterArtist. Edit and rearrange the image in the PosterArtist window as desired. Without closing the PosterArtist window, repeat steps 1-8 to arrange originals from multiple applications on the same page.
Page 42: Printing Cad Drawings
Printing CAD Drawings iPF760 Printing CAD Drawings Printing CAD Drawings Printing CAD Drawings ..........................42 Printing Line Drawings and Text ........................42 Printing Line Drawings and Text (Windows) ..................... 43 Printing Line Drawings and Text (Mac OS X) ................... 44 Printing from AutoCAD ...........................
Page 43: Printing Line Drawings And Text (Windows)
Printing Line Drawings and Text (Windows) Print Quality Description Highest A setting for printing at the highest resolution when quality is most important. Printing takes longer and consumes more ink than in other modes, but this mode offers superior printing quality.
Page 44: Printing Line Drawings And Text (Mac Os X)
Printing Line Drawings and Text (Mac OS X) iPF760 Click the Page Setup tab to display the Page Setup sheet. Page Size, click the size of the original as specified in the application. In this case, click ISO A3. Select and click a roll paper in the Paper Source list.
Page 45 Printing Line Drawings and Text (Mac OS X) This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 46 Printing Line Drawings and Text (Mac OS X) iPF760 Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, ISO A2/A3 (420.0mm).
Page 47: Printing From Autocad
Printer Driver Optimization Module for AutoCAD is in- stalled if in Plotter of Printer/plotter this is dis- played:iPFxxxx - Optimized driver - by Canon Inc.. Installation of Printer Driver Optimization Module for AutoCAD If Printer Driver Optimization Module for AutoCAD is not installed, install it by the following method.
Page 48: Specifying Colors And Printing Cad Drawings
Color (CAD) 2 Print in brighter colors. Color (CAD) 3 Print with approximate colors emulating Canon iPF500, iPF600, iPF700, iPF510, iPF610, iPF710, iPF605, iPF720, iPF810, iPF815, iPF820, iPF825. Color (CAD) 4 Print emulating the HP Designjet 500/800, in colors resembling colors produced by these print- ers.
Page 49: Hp-Gl/2 Printing
HP-GL/2 Printing HP-GL/2 Printing This printer supports printing using the original Canon GARO printer control language and printing using HP-GL/2 and HP RTL emulation to print in colors resembling the colors produced by printers from other companies. The printer automatically switches to the corresponding processing depending on whether a GARO or HP-GL/2 and HP RTL emulation job is received.
Page 50: Adjusting Images
Adjusting the Color in the Printer Driver iPF760 Adjusting Images Adjusting Images Adjusting the Color in the Printer Driver ......................50 Fine-Tuning Colors of Photos and Images (Windows) ................51 Fine-Tuning Colors of Photos and Images (Mac OS X) ................54 Giving Priority to Particular Graphic Elements and Colors for Printing ............
Page 51: Fine-Tuning Colors Of Photos And Images (Windows)
Fine-Tuning Colors of Photos and Images (Windows) Matching Mode Description Remarks Driver Matching Mode Enables printing of optimal color tones using You should normally select this mode. a driver specific color profile. ICC Matching Mode Enables color matching using ICC profiles.
Page 52 Fine-Tuning Colors of Photos and Images (Windows) iPF760 Select the printer in the dialog box, and then display the printer driver dialog box.(See " Accessing the Print- er Driver Dialog Box from Applications(Windows) ") →P.164 Make sure the Main sheet is displayed.
Page 53 Fine-Tuning Colors of Photos and Images (Windows) Click Color Settings to display the Color Settings dialog box. On the Color Adjustment sheet, adjust the color tones, brightness, and so on as desired. Adjustment Item Description Fine-tune color tones by adjusting the levels of Cyan, Magenta, and Yellow.
Page 54: Fine-Tuning Colors Of Photos And Images (Mac Os X)
Fine-Tuning Colors of Photos and Images (Mac OS X) iPF760 Confirm the print settings and print as desired. • For tips on confirming print settings, see " Confirming Print Settings(Windows) " →P.161 Note Fine-Tuning Colors of Photos and Images (Mac OS X) Fine-Tuning Colors of Photos and Images (Mac OS X) You can specify your own print settings instead of using the Print Target presets.
Page 55 Fine-Tuning Colors of Photos and Images (Mac OS X) Click Advanced Settings to switch the print mode. Click Color in the Color Mode list. Click Set to display the Color Settings dialog box. On the Color Adjustment pane, adjust the color tones, brightness, and so on as desired.
Page 56: Giving Priority To Particular Graphic Elements And Colors For Printing
Giving Priority to Particular Graphic Elements and Colors for Printing iPF760 Access the Page Setup pane. Confirm the settings of Paper Source and Page Size. Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) "...
Page 57 Giving Priority to Particular Graphic Elements and Colors for Printing Print Quality (*1) Description Print Priority Highest A setting for printing at the highest resolution when Image quality is most important. Printing takes longer and consumes more ink than in other modes, but this mode offers superior printing quality.
Page 58: Choosing The Document Type And Printing Conditions (Windows)
Choosing the Document Type and Printing Conditions (Windows) iPF760 Setting Item Description Economy Printing When this mode is selected, less ink is consumed than in regular printing, but the quality is diminished. Select this mode if you want to conserve ink when checking drawings, for example. Depending on the Media Type and Print Quality settings, this mode may not be available.
Page 59 Choosing the Document Type and Printing Conditions (Windows) Click Advanced Settings to switch the print mode. Click Line Drawing/Text in the Print Priority list. Click High (1200dpi) in the Print Quality list. • Options displayed in the Print Quality list vary depending on the paper type.
Page 60: Choosing The Document Type And Printing Conditions (Mac Os X)
Choosing the Document Type and Printing Conditions (Mac OS X) iPF760 Confirm the print settings and print as desired. • For tips on confirming print settings, see " Confirming Print Settings(Windows) " →P.161 Note Choosing the Document Type and Printing Conditions (Mac OS X) Choosing the Document Type and Printing Conditions (Mac OS X) You can specify your own print settings instead of using the Print Target presets.
Page 61 Choosing the Document Type and Printing Conditions (Mac OS X) Click Advanced Settings to switch the print mode. Click Line Drawing in the Print Priority list. Click High(1200dpi) in the Print Quality list. • Options displayed in the Print Quality list vary depending on the type of paper.
Page 62: Printing Enlargements Or Reductions
Resizing Originals to Match the Paper Size iPF760 Printing enlargements or reductions Printing enlargements or reductions Resizing Originals to Match the Paper Size ....................62 Resizing Originals to Match the Paper Size (Windows) ................62 Resizing Originals to Match the Paper Size (Mac OS X) ................64 Resizing Originals to Fit the Roll Width ......................
Page 63 Resizing Originals to Match the Paper Size (Windows) Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Select the printing application in the Print Target list.
Page 64: Resizing Originals To Match The Paper Size (Mac Os X)
Resizing Originals to Match the Paper Size (Mac OS X) iPF760 Resizing Originals to Match the Paper Size (Mac OS X) Resizing Originals to Match the Paper Size (Mac OS X) This topic describes how to enlarge originals before printing to match the paper size, based on the following exam- ple.
Page 65 Resizing Originals to Match the Paper Size (Mac OS X) Make your selection in the Print Quality list. Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, ISO A2/A3...
Page 66: Resizing Originals To Fit The Roll Width
Resizing Originals to Fit the Roll Width iPF760 Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) " →P.294 Note Resizing Originals to Fit the Roll Width Resizing Originals to Fit the Roll Width You can freely adjust the size of originals by enlarging or reducing them as desired.
Page 67 Resizing Originals to Fit the Roll Width (Windows) Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Select the printing application in the Print Target list.
Page 68: Resizing Originals To Fit The Roll Width (Mac Os X)
Resizing Originals to Fit the Roll Width (Mac OS X) iPF760 Select the Enlarged/Reduced Printing check box. • If the Enlarged/Reduced Printing check box is not displayed on the Page Setup sheet, clear the Bor- Note derless Printing check box.
Page 69 Resizing Originals to Fit the Roll Width (Mac OS X) This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 70: Resizing Originals By Entering A Scaling Value
Resizing Originals by Entering a Scaling Value iPF760 Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, 16 in. (406.4mm).
Page 71: Resizing Originals By Entering A Scaling Value (Windows)
Resizing Originals by Entering a Scaling Value (Windows) • Scaling Enlarge or reduce originals by a particular amount, as desired. For instructions on entering a scaling value to resize originals, refer to the following topics, as appropriate for your computer and operating system.
Page 72 Resizing Originals by Entering a Scaling Value (Windows) iPF760 Select the printing application in the Print Target list. Click the Page Setup tab to display the Page Setup sheet. Select and click a roll paper in the Paper Source list.
Page 73: Resizing Originals By Entering A Scaling Value (Mac Os X)
Resizing Originals by Entering a Scaling Value (Mac OS X) Resizing Originals by Entering a Scaling Value (Mac OS X) Resizing Originals by Entering a Scaling Value (Mac OS X) This topic describes how to enlarge originals before printing by entering a scaling value, based on the following example.
Page 74 Resizing Originals by Entering a Scaling Value (Mac OS X) iPF760 Make your selection in the Print Quality list. Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, ISO A2/A3...
Page 75 Resizing Originals by Entering a Scaling Value (Mac OS X) Click Scaling and enter 120. • You can specify enlargement that exceeds the paper size, but in this case, the portion off the edge of the paper will not be printed.
Page 76: Printing At Full Size
Printing on Oversized Paper iPF760 Printing at full size Printing at full size Printing on Oversized Paper .......................... 76 Printing at Full Size (Windows) ......................... 77 Printing at Full Size (Mac OS X) ........................ 78 Borderless Printing at Actual Size ........................80 Borderless Printing at Actual Size (Windows) ..................
Page 77: Printing At Full Size (Windows)
Printing at Full Size (Windows) Printing at Full Size (Windows) Printing at Full Size (Windows) This topic describes how to print at full size based on the following example. (Oversized Printing) • Document: Any Type • Page Size: A4 (210.0×297.0 mm)/Letter (8.3 × 11.7 in) •...
Page 78: Printing At Full Size (Mac Os X)
Printing at Full Size (Mac OS X) iPF760 Select and click a roll paper in the Paper Source list. Select the width of the loaded roll in the Roll Paper Width list—in this case, ISO A2/A3 Roll (420.0mm). Confirm the print settings and print as desired.
Page 79 Printing at Full Size (Mac OS X) Access the Main pane. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Make your selection in the Print Target list. Make your selection in the Print Quality list.
Page 80: Borderless Printing At Actual Size
Borderless Printing at Actual Size iPF760 Make sure Page Size shows the original size as specified in Paper Size in the Page Attributes di- alog box—in this case, ISO A4 - Oversize. Confirm the print settings, and then click Print to start printing.
Page 81: Borderless Printing At Actual Size (Windows)
Borderless Printing at Actual Size (Windows) • Print Image with Actual Size Prints originals at actual size, without enlarging or reducing them. Originals must be prepared in a size that exceeds the dimensions of the paper by 3 mm (0.12 in) on each side.
Page 82 Borderless Printing at Actual Size (Windows) iPF760 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Heavyweight Coated Paper. Select the print target in the Print Target list.
Page 83: Borderless Printing At Actual Size (Mac Os X)
Borderless Printing at Actual Size (Mac OS X) Select the Borderless Printing check box to dis- play the Information dialog box. Select the width of the loaded roll in the Roll Paper Width list—in this case, click 10-in. Roll (254.0mm).
Page 84 Borderless Printing at Actual Size (Mac OS X) iPF760 This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 85 Borderless Printing at Actual Size (Mac OS X) Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Confirm that the roll paper width matches the paper size. Roll Width list—in this case, 10 in. (254.0mm).
Page 86: Borderless Printing
Borderless Printing on Paper of Equivalent Size iPF760 Borderless Printing Borderless Printing Borderless Printing on Paper of Equivalent Size ................... 86 Borderless Printing by Resizing Originals to Match the Paper Size (Windows) ........87 Borderless Printing by Resizing Originals to Match the Paper Size (Mac OS X) ........89 Borderless Printing by Resizing Originals to Fit the Roll Width ..............
Page 87: Borderless Printing By Resizing Originals To Match The Paper Size (Windows)
Borderless Printing by Resizing Originals to Match the Paper Size (Windows) • Fit Paper Size Enlarge or reduce the original to match the size of the paper you are using. • The printer driver automatically enlarges originals 3 mm (0.12 in) past the dimensions of the paper on each side.
Page 88 Borderless Printing by Resizing Originals to Match the Paper Size (Windows) iPF760 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Heavyweight Coated Paper. Select the print target in the Print Target list.
Page 89: Borderless Printing By Resizing Originals To Match The Paper Size (Mac Os X)
Borderless Printing by Resizing Originals to Match the Paper Size (Mac OS X) Select the Borderless Printing check box to dis- play the Information dialog box. Select the width of the loaded roll in the Roll Paper Width list—in this case, click 10-in. Roll (254.0mm).
Page 90 Borderless Printing by Resizing Originals to Match the Paper Size (Mac OS X) iPF760 This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 91 Borderless Printing by Resizing Originals to Match the Paper Size (Mac OS X) Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, 10 in.
Page 92: Borderless Printing By Resizing Originals To Fit The Roll Width
Borderless Printing by Resizing Originals to Fit the Roll Width iPF760 Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) " →P.294 Note Borderless Printing by Resizing Originals to Fit the Roll Width...
Page 93: Borderless Printing By Resizing Originals To Fit The Roll Width (Windows)
Borderless Printing by Resizing Originals to Fit the Roll Width (Windows) • You can combine this function with rotating pages 90 degrees before printing so that the original width (relative to portrait orientation) matches the roll paper width in borderless printing.
Page 94: Borderless Printing By Resizing Originals To Fit The Roll Width (Mac Os X)
Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) iPF760 Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4 or Letter (8.5"x11").
Page 95 Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) • Paper: Roll paper • Paper type: Heavyweight Coated Paper • Roll paper width: 10 inches (254.0 mm) This sets the Format for and Paper Size.
Page 96 Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) iPF760 Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, 10 in.
Page 97 Borderless Printing by Resizing Originals to Fit the Roll Width (Mac OS X) Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) "...
Page 98: Printing Banners Or At Other Non-Standard Sizes
Printing Vertical or Horizontal Banners (Large-Format Printing) iPF760 Printing banners or at other non-standard sizes Printing banners or at other non-standard sizes Printing Vertical or Horizontal Banners (Large-Format Printing) ..............98 Printing Vertical or Horizontal Banners (Large-Format Printing; Windows) ..........98 Printing Vertical or Horizontal Banners (Large-Format Printing;...
Page 99 Printing Vertical or Horizontal Banners (Large-Format Printing; Windows) • Document: A horizontal banner created in Microsoft Word • Page size: Non-standard (100×500 mm [3.9×19.7 in]) • Paper: Roll • Paper type: Plain Paper • Roll paper width: 16 in (406.4 mm) The print procedure is as follows.
Page 100 Printing Vertical or Horizontal Banners (Large-Format Printing; Windows) iPF760 • Although you can even set Custom Size for the paper size, the maximum settable size is 3.2 m. The setting of Custom Size is disabled when you exit the application software.
Page 101 Printing Vertical or Horizontal Banners (Large-Format Printing; Windows) Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size you registered, My Horizontal Banner. Select the Enlarged/Reduced Printing check box. •...
Page 102: Printing Vertical Or Horizontal Banners (Large-Format Printing; Mac Os X)
Printing Vertical or Horizontal Banners (Large-Format Printing; Mac OS X) iPF760 If printing is unsuccessful, you may be able to print after completing the following setting. On the Layout sheet, click Special Settings to dis- play the Special Settings dialog box.
Page 103 Printing Vertical or Horizontal Banners (Large-Format Printing; Mac OS X) Register a Custom Page Sizes This example describes how to register and print using a page size that is horizontally elongated and suitable for banners in either horizontal or vertical format.
Page 104 Printing Vertical or Horizontal Banners (Large-Format Printing; Mac OS X) iPF760 Access the Main pane. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Make your selection in the Print Target list.
Page 105: Printing On Non-Standard Paper Sizes
Printing on Non-Standard Paper Sizes Select the Enlarged/Reduced Printing check box. Click Fit Roll Paper Width. Confirm the print settings, and click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) "...
Page 106 Printing on Non-Standard Paper Sizes (Windows) iPF760 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. After confirming that Easy Settings is selected, select from the Print Target list.
Page 107 Printing on Non-Standard Paper Sizes (Windows) In the Page Size list, click the size you added,430 mm Square. Confirm the print settings and print as desired. • For tips on confirming print settings, see " Confirming Print Settings(Windows) "...
Page 108: Printing On Non-Standard Paper Sizes (Mac Os X)
Printing on Non-Standard Paper Sizes (Mac OS X) iPF760 Click the Page Setup tab to display the Page Setup sheet. Click Manual in the Paper Source list. Click Custom Size in the Page Size list to display the Custom Size Settings dialog box.
Page 109 Printing on Non-Standard Paper Sizes (Mac OS X) Choose Print in the application menu. Select the printer in the Printer list. Click Manage Custom Sizes in the Paper Size list to display the Custom Page Sizes dialog box. In Page Size, enter the height and width of the original. Here, enter 43.00 cm in Height and Width.
Page 110 Printing on Non-Standard Paper Sizes (Mac OS X) iPF760 In the Media Type list, select the type of paper that is loaded. After confirming that Easy Settings is selected, select from the Print Target list. Make your selection in the Print Quality list.
Page 111: Tiling And Multiple Pages Per Sheet
Printing Multiple Originals Next to Each Other Tiling and multiple pages per sheet Tiling and multiple pages per sheet Printing Multiple Originals Next to Each Other ..................... 111 Printing Multiple Originals Next to Each Other (Windows) ..............112 Printing Multiple Originals Next to Each Other (Mac OS X) ..............114 Printing Multiple Pages Continuously ......................
Page 112: Printing Multiple Originals Next To Each Other (Windows)
Printing Multiple Originals Next to Each Other (Windows) iPF760 • imagePROGRAF Free Layout (Macintosh) Besides combining multiple pages in a single-page layout, you can combine originals from multiple files—even multiple source applications—in a single-page layout. For instructions on arranging originals from multiple applications, refer to the following topics.
Page 113 Printing Multiple Originals Next to Each Other (Windows) Click the Layout tab to display the Layout sheet. Select the Page Layout check box. Click Free Layout in the Page Layout list. When you attempt to print, the imagePROGRAF Free Layout window is displayed.
Page 114: Printing Multiple Originals Next To Each Other (Mac Os X)
Edit and rearrange the image in the Canon imagePROGRAF Free Layout window as desired. • Without closing the Canon imagePROGRAF Free Layout window, repeat steps 1 to 4 to arrange originals from multiple applications on the same page. Note •...
Page 115: Printing Multiple Pages Continuously
Printing Multiple Pages Continuously Printing Multiple Pages Continuously Printing Multiple Pages Continuously You can print multiple pages as a single continuous image, without margins between pages. • Roll paper (banner) • This feature is only available with rolls. It cannot be used when printing on sheets.
Page 116 Printing Multiple Pages Continuously (Windows) iPF760 Make sure the Main sheet is displayed. In the Media Type list, click the type of paper that is loaded. Click the Page Setup tab to display the Page Setup sheet. Select and click a roll paper in the Paper Source list.
Page 117: Printing Multiple Pages Continuously (Mac Os X)
Printing Multiple Pages Continuously (Mac OS X) Printing Multiple Pages Continuously (Mac OS X) Printing Multiple Pages Continuously (Mac OS X) This topic describes how to print multiple pages as a single continuous image, without margins between pages. •...
Page 118: Printing Multiple Pages Per Sheet
Printing Multiple Pages Per Sheet iPF760 Access the Page Setup pane. Click Roll Paper (Banner) in the Paper Source list. Confirm the print settings, and then click Print to start printing. • For tips on confirming print settings, see " Confirming Print Settings(Mac OS X) "...
Page 119: Printing Multiple Pages Per Sheet (Windows)
Printing Multiple Pages Per Sheet (Windows) For instructions on printing multiple pages per sheet, refer to the following topics, as appropriate for your com- puter and operating system. • Printing Multiple Pages Per Sheet (Windows) →P.119 • Printing Multiple Pages Per Sheet (Mac OS X) →P.121...
Page 120 Printing Multiple Pages Per Sheet (Windows) iPF760 Click the Page Setup tab to display the Page Setup sheet. Page Size, click the size of the original as specified in the application software. In this case, click ISO Select and click a roll paper in the Paper Source list.
Page 121: Printing Multiple Pages Per Sheet (Mac Os X)
Printing Multiple Pages Per Sheet (Mac OS X) Printing Multiple Pages Per Sheet (Mac OS X) Printing Multiple Pages Per Sheet (Mac OS X) This topic describes how to print four pages of an original on a single sheet, based on the following example.
Page 122 Printing Multiple Pages Per Sheet (Mac OS X) iPF760 Access the Main pane. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Make your selection in the Print Target list.
Page 123: Printing Posters In Sections
Printing Posters in Sections Make sure Page Size shows the original size as specified in Paper Size in the Page Attributes di- alog box—in this case, ISO A3. Confirm the print settings, and then click Print to start printing.
Page 124 Printing Large Posters (Windows) iPF760 Select the printer in the dialog box, and then display the printer driver dialog box.(See " Accessing the Print- er Driver Dialog Box from Applications(Windows) ") →P.164 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded.
Page 125 Printing Large Posters (Windows) Click the Layout tab to display the Layout sheet. Select the Page Layout check box. Click Poster (2 x 2) in the Page Layout list. • Follow the steps below to print only a portion of the poster as divided for printing.
Page 126: Centering Originals
Printing Originals Centered on Rolls iPF760 Centering originals Centering originals Printing Originals Centered on Rolls ......................126 Printing Originals Centered on Rolls (Windows) ..................126 Printing Originals Centered on Rolls (Mac OS X) ................... 128 Printing Originals Centered on Sheets ......................130 Printing Originals Centered on Sheets (Windows) ..................
Page 127 Printing Originals Centered on Rolls (Windows) Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Select the print target in the Print Target list.
Page 128: Printing Originals Centered On Rolls (Mac Os X)
Printing Originals Centered on Rolls (Mac OS X) iPF760 Click the Layout tab to display the Layout sheet. Select the Print Centered check box. Confirm the print settings and print as desired. • For tips on confirming print settings, see " Confirming Print Settings(Windows) "...
Page 129 Printing Originals Centered on Rolls (Mac OS X) In the Paper Size list, click the size of the original. In this case, click ISO A4. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
Page 130: Printing Originals Centered On Sheets
Printing Originals Centered on Sheets iPF760 Make sure the width of the loaded roll is displayed in Roll Width —in this case, ISO A3/A4 (297.0mm). • If the width of the roll loaded in the printer is not shown Roll Width, click...
Page 131: Printing Originals Centered On Sheets (Windows)
Printing Originals Centered on Sheets (Windows) Aligns the center of the original with the center of the sheet. For instructions on centering originals when printing on sheets, refer to the following topics, as appropriate for your computer and operating system.
Page 132 Printing Originals Centered on Sheets (Windows) iPF760 Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO Select the Enlarged/Reduced Printing check box.
Page 133: Printing Originals Centered On Sheets (Mac Os X)
Printing Originals Centered on Sheets (Mac OS X) Printing Originals Centered on Sheets (Mac OS X) Printing Originals Centered on Sheets (Mac OS X) This topic describes how to center originals for printing on sheets, based on the following example.
Page 134 Printing Originals Centered on Sheets (Mac OS X) iPF760 Make your selection in the Print Quality list. Access the Page Setup pane. Click Manual in the Paper Source list. Page Size setting matches the orig- Make sure the inal size as selected in Paper Size in the Page At- tributes dialog box—in this case, ISO A4 - for Paper...
Page 135: Conserving Roll Paper
Conserving Roll Paper by Rotating Originals 90 Degrees Conserving roll paper Conserving roll paper Conserving Roll Paper by Rotating Originals 90 Degrees ................135 Conserving Roll Paper by Rotating Originals 90 Degrees (Windows) ............ 135 Conserving Roll Paper by Rotating Originals 90 Degrees (Mac OS X) ..........136 Conserving Roll Paper by Printing Originals Without Top and Bottom Margins ..........
Page 136: Conserving Roll Paper By Rotating Originals 90 Degrees (Mac Os X)
Conserving Roll Paper by Rotating Originals 90 Degrees (Mac OS X) iPF760 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Click the Page Setup tab to display the Page Setup sheet.
Page 137 Conserving Roll Paper by Rotating Originals 90 Degrees (Mac OS X) • Page size: A4 (210.0 × 297.0 mm [8.3 × 11.7 in]) • Paper: Roll paper • Paper type: Plain Paper • Roll paper width: A3/A4 roll (297.0 mm [11.7 in]) This example illustrates how to rotate an A4 (210.0×297.0 mm)/Letter (8.3 ×...
Page 138 Conserving Roll Paper by Rotating Originals 90 Degrees (Mac OS X) iPF760 Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in Roll Width —in this case, ISO A3/A4 (297.0mm).
Page 139: Conserving Roll Paper By Printing Originals Without Top And Bottom Margins
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins Conserving Roll Paper by Printing Originals Without Top and Bottom Margins Conserving Roll Paper by Printing Originals Without Top and Bottom Margins You can conserve roll paper by specifying particular settings as suitable for your original.
Page 140 Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Windows) iPF760 Make sure the Main sheet is displayed. In the Media Type list, select the type of paper that is loaded. In this case, click Plain Paper. Click the Page Setup tab to display the Page Setup sheet.
Page 141: Conserving Roll Paper By Printing Originals Without Top And Bottom Margins (Mac Os X)
Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Mac OS X) Click the Layout tab to display the Layout sheet. Select the No Spaces at Top or Bottom (Conserve Paper) check box. Confirm the print settings and print as desired.
Page 142 Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Mac OS X) iPF760 In the Paper Size list, click the size of the original. In this case, click ISO A4. If you configured the settings using the Page Attributes dialog box, click OK to close the dialog box, and then select Print from the application software menu.
Page 143 Conserving Roll Paper by Printing Originals Without Top and Bottom Margins (Mac OS X) Make sure the Page Size setting matches the orig- inal size as selected in Paper Size in the Page At- tributes dialog box—in this case, ISO A4.
Page 144: Checking Images Before Printing
Checking the Layout in a Preview Before Printing iPF760 Checking Images Before Printing Checking Images Before Printing Checking the Layout in a Preview Before Printing Checking the Layout in a Preview Before Printing You can check the print layout on the preview screen.
Page 145: Other Useful Settings
Printing With Watermarks Other useful settings Other useful settings Printing With Watermarks ..........................145 Printing with Watermarks— COPY, FILE COPY, and so on (Windows) ..........146 Making the Original Orientation Match the Paper Orientation ..............147 Making the Original Orientation Match the Paper Orientation (Windows) ..........148 Making the Original Orientation Match the Paper Orientation (Mac OS X) ..........
Page 146: Printing With Watermarks- Copy, File Copy, And So On (Windows)
Printing with Watermarks— COPY, FILE COPY, and so on (Windows) iPF760 Printing with Watermarks— COPY, FILE COPY, and so on (Windows) Printing with Watermarks— COPY, FILE COPY, and so on (Windows) This topic describes how to print with watermarks, based on the following example of printing with a FILE COPY watermark.
Page 147: Making The Original Orientation Match The Paper Orientation
Making the Original Orientation Match the Paper Orientation Page Size, click the size of the original as specified in the application software. In this case, click ISO Select and click a roll paper in the Paper Source list. Select the width of the loaded roll in the Roll Paper Width list—in this case, ISO A2/A3 Roll...
Page 148: Making The Original Orientation Match The Paper Orientation (Windows)
Making the Original Orientation Match the Paper Orientation (Windows) iPF760 For instructions on specifying the original orientation before printing, refer to the following topics, as appropri- ate for your computer and operating system. • Making the Original Orientation Match the Paper Orientation (Windows) →P.148...
Page 149: Making The Original Orientation Match The Paper Orientation (Mac Os X)
Making the Original Orientation Match the Paper Orientation (Mac OS X) Click the Page Setup tab to display the Page Setup sheet. In the Page Size list, click the size of the original as specified in the application. In this case, click ISO A4 or Letter (8.5"x11").
Page 150 Making the Original Orientation Match the Paper Orientation (Mac OS X) iPF760 This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 151 Making the Original Orientation Match the Paper Orientation (Mac OS X) Access the Page Setup pane. Select and click a roll paper in the Paper Source list. Make sure the width of the loaded roll is displayed in the Roll Width list—in this case, ISO A2/A3...
Page 152: Using Favorites
Using Favorites iPF760 Using Favorites Using Favorites You can register print settings as Favorites to reuse settings from a particular job that met your expectations, or settings for a particular page size that you will use repeatedly. • Favorites Registering a favorite for later use. You can choose the settings you have registered from a list before printing, and you can check the settings details.
Page 153: Cutting Roll Paper After Printing (Mac Os X)
Cutting Roll Paper After Printing (Mac OS X) Click the Page Setup tab to display the Page Setup sheet. Select and click a roll paper in the Paper Source list. Click Roll Paper Options to display the Roll Pa- per Options dialog box.
Page 154 Cutting Roll Paper After Printing (Mac OS X) iPF760 This sets the Format for and Paper Size. • The configuration method varies depending on the OS and application software you are using. Note If Page Setup is displayed in the application menu, the settings are configured by opening the Page Attributes dialog box from Page Setup.
Page 155 Cutting Roll Paper After Printing (Mac OS X) Access the Main pane. In the Media Type list, select the type of paper that is loaded. Click Set to display the Paper Detailed Settings dialog box. To enable automatic cutting, click Printer Default in the Automatic Cutting list.
Page 156 User's Guide...
Page 157: Windows Software
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Printer Driver ................158 Preview ..................187 Free Layout ................197 Color imageRUNNER Enlargement Copy ........ 218 Print Plug-In for Office .............. 227 Status Monitor ................263 Accounting ................265 Device Setup Utility ..............
Page 158: Printer Driver
Printer Driver Settings iPF760 Printer Driver Printer Driver Printer Driver Settings ..........................158 Specifying Paper in the Printer Driver ......................159 Confirming Print Settings ..........................161 Checking the Layout in a Preview Before Printing ..................161 Using Favorites ............................162 Accessing the Printer Driver Dialog Box from Applications .................
Page 159: Specifying Paper In The Printer Driver
Specifying Paper in the Printer Driver • Paper Detailed Settings Dialog Box →P.170 • View Settings Dialog Box for the Printing Application →P.171 • Color Adjustment Sheet: Color →P.171 • Matching Sheet →P.173 • Color Adjustment Sheet: Monochrome →P.174 •...
Page 160 Specifying Paper in the Printer Driver iPF760 Choose Print in the application menu. Select the printer in the dialog box, and then display the printer driver dialog box.(See " Accessing the Print- ") er Driver Dialog Box from Applications →P.164 Make sure the Main sheet is displayed.
Page 161: Confirming Print Settings
Confirming Print Settings Confirming Print Settings Confirming Print Settings There are two ways to confirm the print settings, as follows. • Checking a preview of the settings A preview of the settings is displayed on the left side of the Main, Page Setup, and Layout sheets. By check- ing illustrations and numerical values in the preview, you can confirm current settings for the page size, orien- tation, paper source, layout, and so on.
Page 162: Using Favorites
Using Favorites iPF760 Make sure the Main sheet is displayed. Select the Open Preview When Print Job Starts check box. After you click OK, when you print a job, the image- PROGRAF Preview window will be displayed. • If PageComposer is running, access the Special Settings dialog box from the Layout sheet and clear Enable Preview Switching.
Page 163 Using Favorites Perform normal printing settings. The favorite is registered from here. Click the Favorites tab to display the Favorites sheet. Click Add to display the Add dialog box. Enter a desired name in Name, such as Photos for Presentations or Monthly Report.
Page 164: Accessing The Printer Driver Dialog Box From Applications
Accessing the Printer Driver Dialog Box from Applications iPF760 Click the Favorites tab to display the Favorites sheet. In the Favorites, choose the favorite you registered. • Import and specify the favorite file. To import a favorite, click Note Click Apply Favorite to replace the favorite settings with the current print settings.
Page 165: Accessing The Printer Driver Dialog Box From The Operating System Menu
Accessing the Printer Driver Dialog Box from the Operating System Menu Six sheets of print settings are displayed by the print- er driver: Main, Page Setup, Layout, Favorites, Utility, and Support. • The titles of dialog boxes may vary depending on the application, and sheets other than these six sheets may be displayed.
Page 166 Accessing the Printer Driver Dialog Box from the Operating System Menu iPF760 Select the printer, and then display the printer proper- ties dialog box. Click Printing Preferences to display the Printing Preferences dialog box, titled with the name of this printer.
Page 167: Main Sheet
Main Sheet • If you access the printer driver dialog box from the operating system menu, changes you make to the settings will apply to all applications you use for printing. Important • You can also access the printer driver dialog box from applications.
Page 168 Main Sheet iPF760 • Defaults Restores all settings on the sheet to the default values. Configuration using Easy Settings • Print Target Choose presets that match the type of document to be printed. • Printing Photos and Images →P.31 •...
Page 169: Paper Information On Printer Dialog Box
Paper Information on Printer Dialog Box • Print Priority Choose the graphic elements that you want to emphasize for printing. • Giving Priority to Particular Graphic Elements and Colors for Printing →P.56 • Print Quality Choose the level of print quality.
Page 170: Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box iPF760 • To display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by Media Type.(See " Main Sheet ") →P.167 Note • Paper Source Shows the paper source supported by the printer, as well as information about the loaded paper. To update the paper source and media type settings in the printer driver, select the desired Paper Source option and click OK.
Page 171: View Settings Dialog Box For The Printing Application
View Settings Dialog Box for the Printing Application View Settings Dialog Box for the Printing Application View Settings Dialog Box for the Printing Application In the View Settings dialog box, you can check details of the selected printing application.
Page 172: Object Adjustment Dialog Box: Color
Object Adjustment dialog box: Color iPF760 • View Color Pattern Select this checkbox to display the color pattern. • Apply to Sample Select this checkbox to apply the changed settings to the sample image. • Cyan / Magenta / Yellow Fine-tune color tones by adjusting the levels of each color.
Page 173: Matching Sheet
Matching Sheet • Image Select this option to apply color adjustment to image areas, such as photos. • Graphics Select this option to apply color adjustment to graphics, such as lines and circles. • Text Select this option to apply color adjustment to text.
Page 174: Color Adjustment Sheet: Monochrome
Color Adjustment Sheet: Monochrome iPF760 ICC Matching Mode, Driver ICM Mode and Host ICM Mode The following options are available when you select ICC Matching Mode, Driver ICM Mode, or Host ICM Mode in Matching Mode list. • Matching Mode Select the color matching mode to use, as desired.
Page 175 Color Adjustment Sheet: Monochrome • To display the Color Adjustment sheet, on the Main sheet, click Color Settings by Color Mode in Advanced Settings. (See " Main Sheet ") →P.167 Note • Sample Type Choose a sample image from Standard, Portrait, Landscape, or Graphics.
Page 176: Object Adjustment Dialog Box: Monochrome
Object Adjustment dialog box: Monochrome iPF760 Object Adjustment dialog box: Monochrome Object Adjustment dialog box: Monochrome In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.
Page 177 Page Setup Sheet • Borderless Printing Borderless printing is available if roll paper is selected in the Paper Source list. Choose from the following options when this setting is activated. • Borderless Printing on Paper of Equivalent Size →P.86 •...
Page 178 Page Setup Sheet iPF760 • Orientation Choose the printing orientation. • Making the Original Orientation Match the Paper Orientation →P.147 • Rotate Page 90 degrees (Conserve Paper) Activate this setting to rotate the document image by 90 degrees before printing.
Page 179: Paper Size Options Dialog Box
Paper Size Options Dialog Box Paper Size Options Dialog Box Paper Size Options Dialog Box In the Paper Size Options dialog box, you can create and register your own Custom Paper Size. The sizes you define are listed with standard paper sizes for selection later as needed.
Page 180: Layout Sheet
Layout Sheet iPF760 Layout Sheet Layout Sheet The following settings are available on the Layout sheet. For details on settings items, refer to the printer driver help. • Page Layout Activate this setting to select a particular page layout. •...
Page 181: Page Options Dialog Box
Page Options Dialog Box • Copies Enter the number of copies to print, in a range of 1–999. • Reverse Order Activate this option to print pages in reverse order. • Collate Activate this option to print complete sets in the specified quantity.
Page 182: Special Settings Dialog Box
Special Settings Dialog Box iPF760 • Format Settings Click to display the Format Settings dialog box, which enables you to complete format-related settings. • If you specify the same position for multiple items, the items are printed from left to right in this order: date, user name, and page number.
Page 183: Favorites Sheet
Favorites Sheet • Reduce Print Unevenness If you are concerned about print unevenness, the printing results can be improved by selecting this option. However, printing may take longer for some images. • Adjust faint lines If fine lines are printed in colors that do not match the colors of other shapes, clearing this option may help produce the expected results.
Page 184: Utility Sheet
Utility Sheet iPF760 • Click to display the Add dialog box, which enables you to add the current print settings as a favorite. • Import Click to display the Open dialog box, which enables you to import favorite settings saved as a file.
Page 185: Support Sheet
On the Support sheet, you can view support information and the user's manual. • Support Information Click to access the Canon support webpage, where you can find the latest information on the printer and con- sumables, check for printer driver updates, and browse other information. •...
Page 186: Device Settings Sheet
Device Settings Sheet iPF760 Device Settings Sheet Device Settings Sheet Many settings items on the printer properties sheets are controlled by Windows applications. However, the Device Settings sheet is for configuring the printer, and it is an extension of the printer driver.
Page 187: Preview
The Features of Preview Preview Preview The Features of Preview ..........................187 Starting Preview ............................187 Preview Main Window ..........................188 Dialog Area ..............................190 Enlarge/Reduce the screen display ......................191 Moving a Page ............................. 191 Using the ruler .............................. 191 Priority setting for rotating 90 degrees ......................
Page 188: Preview Main Window
Preview Main Window iPF760 Preview main window is displayed. Preview Main Window Preview Main Window The Preview main window consists of the menu and tool bars, preview and dialog area and status bar. • You can use the View menu to show or hide the tool bar.
Page 189 Preview Main Window • Preview Area You can check the settings you made in this area. • Dialog Area This allows you to set the print conditions and perform a print job. For more information about Dialog Area, see "Dialog Area."...
Page 190: Dialog Area
Dialog Area iPF760 Dialog Area Dialog Area You can select the layout and print on the center. • Media Type / Paper Source /Paper Size You can confirm the information that is set. • Layout Selection You can print which conserves paper by selecting the layout.
Page 191: Enlarge/Reduce The Screen Display
Enlarge/Reduce the screen display • Printer Information You can confirm the information acquired from the printer. • Update Printer Information Button Click the button to update the printer information with connecting to the printer. • Status Monitor Button Click the button to start Status Monitor.
Page 192: Priority Setting For Rotating 90 Degrees
Priority setting for rotating 90 degrees iPF760 Priority setting for rotating 90 degrees Priority setting for rotating 90 degrees You can select Rotate 90 Degrees If Possible or Use Driver Settings from the Options menu. Setting Details Rotate 90 Degrees If Possible Rotates pages in portrait orientation 90 degrees before printing.
Page 193: Printing With Selecting The Layout
Printing with Selecting the Layout Printing with Selecting the Layout Printing with Selecting the Layout You can print which conserves paper by selecting the layout. In Layout Selection, click the layout button to use. Button Details Upper Button Turn at the position of...
Page 194 Printing with Selecting the Layout iPF760 • Right Button or Left Button can be selected only when the rotated pages can fit lengthwise across the roll. • By clicking Right Button or Left Button, you can save paper by printing in landscape orientation on roll paper.
Page 195: Print On The Center
Print on the Center Print on the Center Print on the Center You can print on the center of the media loaded in the printer. Click the Center Originals Across Roll check box on. Click the Print button Printing on the center begins.
Page 196: Not Print Spaces At The Top/Bottom
Not Print Spaces at the Top/Bottom iPF760 Not Print Spaces at the Top/Bottom Not Print Spaces at the Top/Bottom You can save paper on not to feed roll paper for the empty spaces when the print data contains spaces at the top or bottom.
Page 197: Free Layout
The Features of Free Layout Free Layout Free Layout The Features of Free Layout ........................197 Starting Free Layout ............................. 197 Free Layout Main Window ..........................199 Detailed Settings ............................200 Preferences Dialog Box ..........................200 Page Options Dialog Box ..........................201 Zoom Dialog Box ............................
Page 198 Starting Free Layout iPF760 From the application software's File menu, select the printer setup menu to open the Print dialog box. • Normally, select Print from the File menu. Note From the list, select the printer and select the Layout sheet.
Page 199: Free Layout Main Window
Free Layout Main Window Free Layout Main Window Free Layout Main Window The Free Layout main window consists of the menu and tool bars, layout area and status bar. • You can use the View menu to show or hide the tool and status bar.
Page 200: Detailed Settings
Detailed Settings iPF760 • Status Bar This shows the paper size, unit of length, and number of objects. Detailed Settings Detailed Settings The printer driver opens when you select Detailed Settings from the File menu. The printer driver is used to con- figure basic settings to match the type of media loaded in the printer.
Page 201: Page Options Dialog Box
Page Options Dialog Box • You can input between 10.0 and 200.0(mm) (between 0.39 and 7.88(inch)). • You can change the numbers by clicking either ▲ button or ▼ button. Note • Divisions You can change the number of divisions of grid lines so that they serve as a guide to laying out objects.
Page 202: Zoom Dialog Box
Zoom Dialog Box iPF760 Setting Details Auto Settings The one-page length to be printed on roll paper is automatically set so that the laid-out objects are printed on one page. Manual Settings You can input the length of one page to print on roll paper in numerical characters.
Page 203: Format Dialog Box
Format Dialog Box Format Dialog Box Format Dialog Box This dialog box appears when you select Format from the Object menu after you select an object. Size Sheet You can rotate, enlarge, or reduce an object. • When the objects are not selected, you can not select Format.
Page 204: Laying Out A Multiple-File Document On One Page
Laying out a Multiple-File Document on One Page iPF760 Position Sheet You can rotate, enlarge, or reduce an object. • When the objects are not selected, you can not select Format. Note • Object Position You can move the object position by changing the values.
Page 205 Laying out a Multiple-File Document on One Page Click Properties to open the Properties dialog box. In the Page Setup sheet, select Paper Source. • Your printer is depicted in the lower-left area of this screen. Note In the Layout sheet, click on the Page Layout check box and select Free Layout from the list.
Page 206: Laying Out A Document Created With Multiple Application Programs On One Page
Laying out a Document Created with Multiple Application Programs on One Page iPF760 In the Print dialog box, select the pages to print and the number of copies, and click the OK button. Free Layout starts, laying out the document created with application software in the layout area as an ob- ject.
Page 207 Laying out a Document Created with Multiple Application Programs on One Page Click Properties to open the Properties dialog box. In the Page Setup sheet, select Paper Source. • Your printer is depicted in the lower-left area of this screen.
Page 208: Selecting An Object
Selecting an Object iPF760 In the Print dialog box, select the pages to print and the number of copies, and click the OK button. Free Layout starts, laying out the document created with application software in the layout area as an ob- ject.
Page 209: Changing The Object Size
Changing the Object Size • To select an object, click that object. • To select multiple successive objects, click them while holding down the Shift key. Note • To select multiple arbitrary objects, click them while holding down the Ctrl key.
Page 210: Moving An Object
Moving an Object iPF760 Moving an Object Moving an Object You can move the object position. Select an object. Place the pointer inside the selection box of the ob- ject to show the crosshair handle, and drag it to move the object.
Page 211: Aligning Objects
Aligning Objects Aligning Objects Aligning Objects You can align objects systematically. Select multiple objects. Click the align button from the toolbar. Alternatively, you may select the align menu from the Object menu. • Align Top Lays out the objects, justifying them to the top.
Page 212: Changing The Object Overlapping Order
Changing the Object Overlapping Order iPF760 • Center Horizontally Lays out the objects, justifying them to the hori- zontal center. • Align Right Lays out the objects, justifying them to the right. Changing the Object Overlapping Order Changing the Object Overlapping Order You can change the object overlapping order.
Page 213: Pasting A Copied Or Cut Object
Pasting a Copied or Cut Object • Send to Back Moves the object to the backmost position. • Bring Forward Moves the object one position to the front. • Send Backward Moves the object one position to the back.
Page 214: Folded Duplex Window
Folded Duplex Window iPF760 Folded Duplex Window Folded Duplex Window This window is displayed if you select Folded Duplex from the Edit menu after selecting an object. Using the Fol- ded Duplex function allows you to print with fold lines added.
Page 215: Finished Size Settings Dialog Box
Finished Size Settings Dialog Box • Layout Area This allows you to check the arrangement and orientation of objects. • Status Bar This shows the paper source, roll paper width, and output size. Finished Size Settings Dialog Box Finished Size Settings Dialog Box This dialog box is displayed when you select Finished Size Settings from the Edit menu.
Page 216: Binding Settings Dialog Box
Binding Settings Dialog Box iPF760 Binding Settings Dialog Box Binding Settings Dialog Box This is displayed when you select Binding Settings from the Edit menu. This allows you to configure the binding edge settings. • Binding Edge Configures the binding edge when folding paper.
Page 217: Prints Using Folded Duplex
Prints using Folded Duplex Prints using Folded Duplex Prints using Folded Duplex This prints 2 pages consecutively. Folding back the paper at the fold lines of the center substitutes for duplex print- ing. Select two objects from the layout area of Free Layout.
Page 218: Color Imagerunner Enlargement Copy
The Features of Color imageRUNNER Enlargement Copy iPF760 Color imageRUNNER Enlargement Copy Color imageRUNNER Enlargement Copy The Features of Color imageRUNNER Enlargement Copy ................218 Starting Color imageRUNNER Enlargement Copy ..................218 Color imageRUNNER Enlargement Copy Dialog Box ................. 219 Hot Folder ..............................
Page 219: Color Imagerunner Enlargement Copy Dialog Box
Color imageRUNNER Enlargement Copy Dialog Box The Color imageRUNNER Enlargement Copy dia- log box displays. • If you click on the Add to Startup folder check box in the Color imageRUNNER Enlargement Copy dialog box, the icon of Color imageRUNNER Enlargement Copy utility will appear on the task bar when starting Windows thereafter.
Page 220: Hot Folder
Hot Folder iPF760 • Hot Folder The hot folder list appears. • Add Button Click the button to open the Easy Setup Wizard dialog box so that you can add a hot folder. • Edit Button From the Hot Folder list, select a hot folder and click the button to open the Add/Edit Hot Folder dialog box that allows you to edit the hot folder.
Page 221 Creating a New Hot Folder The Easy Setup Wizard dialog box displays. Click the Next button. Select the type of printer to use. Click the Next button. Select the media type to print. • If the Borderless Printing checkbox is checked, only media types that can be used for borderless printing are displayed in the list.
Page 222 Creating a New Hot Folder iPF760 Select roll paper or cut sheet to print. Also, select the media size to print. Click the Next button. Select the color matching method. Click the Next button. To receive a document scanned with the Color imageRUNNER, you need to share a folder. Enter the folder shared name in Shared Name.
Page 223: Specifying An Existing Shared Folder As A Hot Folder
Specifying an Existing Shared Folder as a Hot Folder Click Finish button to close the Easy Setup Wizard dialog box. The hot folder you have created appears in the Hot Folder list in the Color imageRUNNER Enlarge- ment Copy dialog box.
Page 224 Specifying an Existing Shared Folder as a Hot Folder iPF760 The Easy Setup Wizard dialog box displays. Click the Manual Settings button. The Add/Edit Hot Folder dialog box displays. Enter the hot folder name in Name. Click the Browse botton, with selecting Specify a folder, to set the existing shared folder.
Page 225: Setting The Print Parameters
Setting the Print Parameters As necessary, set the print conditions in the hot fold- er. (See "Setting the Print Parameters.") →P.225 Click the OK button to close the Add/Edit Hot Fold- er dialog box. The hot folder you have created appears in the Hot Folder list in the Color imageRUNNER Enlarge- ment Copy dialog box.
Page 226: Printing Enlargements Of Scanned Originals From A Color Imagerunner
Printing Enlargements of Scanned Originals from a Color imageRUNNER iPF760 Refer to Printer Driver for details on the printer driver. →P.158 • The only three sheets displayed are the Main sheet, the Page Setup sheet, and the Layout sheet. Some of the printer driver settings may be disabled.
Page 227: Print Plug-In For Office
Print Plug-In for Office features Print Plug-In for Office Print Plug-In for Office Print Plug-In for Office features ........................227 Steps to install .............................. 227 Steps to uninstall ............................230 When Print Plug-In for Office is not displayed ..................... 230 To start from Microsoft Word ........................
Page 228 Steps to install iPF760 Insert "User Software CD-ROM" into the CD-ROM drive and start the installer. • If the installer screen does not display, open the CD-ROM icon from My Computer, click setup.exe, and open the icon. Note Click the Install Individual Software button.
Page 229 Steps to install Read the License Agreement, and click the Yes but- ton. Click the Start button. Click the Yes button. Click the Exit button. The installation for Print Plug-In for Office is com- plete. User's Guide...
Page 230: Steps To Uninstall
Steps to uninstall iPF760 • When you install this software, the virtual printer Canon imagePROGRAF PrintPlugIn may be installed. If you want to use this software, do not uninstall the virtual printer Canon imagePROGRAF PrintPlugIn. Important • The Print Plug-In for Office toolbar/ribbon might not be displayed in Microsoft Office after installing imagePROGRAF Print Plug-In for Office.
Page 231 When Print Plug-In for Office is not displayed Install Print Plug-In for Office. For information about instsalling, see "Steps to install." →P.227 Enabling Print Plug-In for Office for items disabled in Office applications If a problem occurs, such as the system or an application terminating abnormally, the Microsoft Office application disables add-ins as a safety precaution.
Page 232 When Print Plug-In for Office is not displayed iPF760 Close all the dialog boxes and restart the Office application. • For Microsoft Office 2007 Click the Office button and then click the <applica- tion name> options button. From the list on the left side of the <application name> options dialog box, select Add-ins.
Page 233: To Start From Microsoft Word
To start from Microsoft Word Close all the dialog boxes and restart the Office application. • For Microsoft Office 2003 Click About <application name> in the Help menu of appli- cation. Click the Disabled Items button in the About <appli- cation name>...
Page 234 To start from Microsoft Word iPF760 If Start imagePROGRAF Print Plug-In is displayed on the toolbar/ ribbon, click it. • If the imagePROGRAF Print Plug-In toolbar/ribbon is not displayed, refer to the following. • Important When Print Plug-In for Office is not displayed →P.230...
Page 235: Print Matching Roll Width (Word)
Print Matching Roll Width (Word) Large-Format Printing Wizard dialog box • If you want to change the display to another file or application while the Large-Format Printing Wizard is open, close the Large-Format Printing Wizard dialog box. Otherwise, you may not be able to change displays Important or operate the toolbar/ribbon.
Page 236 Print Matching Roll Width (Word) iPF760 Click Print Matching Roll Width. Select Roll Paper Width that is set in the printer. Select image size. Select layout. Select Next. Select Media Type. Select Print Range from All Pages, Current Page, and Pages.
Page 237: Borderless Printing (Word)
Borderless Printing (Word) Press Print to start printing. Borderless Printing (Word) Borderless Printing (Word) Prints up to the border of the media. Photos and posters can be printed without worrying about margins. Start Microsoft Word. If Start imagePROGRAF Print Plug-In is displayed, click it.
Page 238 Borderless Printing (Word) iPF760 Select Roll Paper Width that is set in the printer. Select Layout. Select Next. Select Media Type. Select Print Range from All Pages, Current Page, and Pages. For Pages, insert the page number. Enter Copies. •...
Page 239: Multi-Page Printing (Word)
Multi-Page Printing (Word) Multi-Page Printing (Word) Multi-Page Printing (Word) Prints multiple pages as one page. You can print handouts into a single page, or print matter with many pages. Start Microsoft Word. If Start imagePROGRAF Print Plug-In is displayed, click it.
Page 240: Register The Settings (Word)
Register the settings (Word) iPF760 Select Next. Select Media Type. Select Print Range from All Pages, Current Page, and Pages. If Pages is selected, enter the number of pages. Enter Copies. • When Print in Draft mode is selected, printing is fast but the print quality is poor.
Page 241: Print Using Registered Settings (Word)
Print Using Registered Settings (Word) Click the One-Touch Registration button. Enter name in Name. Up to 31 characters can be entered. Click . The name you entered is displayed in Registered Settings. Click OK, and return to the Print screen.
Page 242 Print Using Registered Settings (Word) iPF760 Click Print Using Registered Settings. Click the Next button. Select Media Type. Select Print Range from All Pages, Current Page, or Pages. If Pages is selected, enter the number of pages. Enter Copies. •...
Page 243: Portrait Orientation / Landscape Orientation (Word)
Portrait Orientation / Landscape Orientation (Word) Portrait Orientation / Landscape Orientation (Word) Portrait Orientation / Landscape Orientation (Word) Print to the edge of the roll width. You can print large exhibits and posters, or print the Landscape or Portrait Orien- tation Page Sizes made in the Large-Format Printing Wizard.
Page 244: To Start From Microsoft Powerpoint
To start from Microsoft PowerPoint iPF760 Adjust Length from the list-box or slide-bar. Click the Create Page button. Click OK if the message is displayed. Edit and create the document. • Printing is done in Print Matching Roll Width of the Printing Wizard. For details on Print Matching Roll Width, refer to see "Print Matching Roll Width (Word)."...
Page 245 To start from Microsoft PowerPoint Icon Contents Print Button The print Wizard is displayed. The settings Print Matching Roll Width, Borderless Printing, Multi-Page Printing, and Print Using Registered Settings can be set. Large-Format Wizard is displayed. Settings for Portrait or Landscape Orientation can be set.
Page 246: Print Matching Roll Width (Powerpoint)
Print Matching Roll Width (PowerPoint) iPF760 Print Matching Roll Width (PowerPoint) Print Matching Roll Width (PowerPoint) Prints to the edge of the roll width. You can print large exhibits and posters, and also print Portrait and Landscape orientations made in Large-Format Printing Wizard.
Page 247: Borderless Printing (Powerpoint)
Borderless Printing (PowerPoint) Select Next. Select Media Type. Select Print Range from All Slides, Current Slide, and Slides. If Slides is selected, enter the slide number. Enter Copies. • When Print in Draft mode is selected, printing is fast but the print quality is poor.
Page 248 Borderless Printing (PowerPoint) iPF760 Click Print from the imagePROGRAF Print Plug-In toolbar/ribbon. The Printing Wizard dialog box is displayed. • If you want to change the display to another file or application while the Printing Wizard is open, close the Printing Wizard dialog box.
Page 249 Borderless Printing (PowerPoint) Select Roll Paper Width that is set in the printer. Select Layout. Select Next. Select Media Type. Select Print Range from All Slides, Current Slide, and Slides. If Slides is selected, enter the slide number. Enter Copies.
Page 250: Multi-Page Printing (Powerpoint)
Multi-Page Printing (PowerPoint) iPF760 Multi-Page Printing (PowerPoint) Multi-Page Printing (PowerPoint) Prints multiple pages as one page. You can print handouts into a single page, or print matter with many pages. Start Microsoft PowerPoint. If Start imagePROGRAF Print Plug-In is displayed, click it.
Page 251: Register The Settings (Powerpoint)
Register the settings (PowerPoint) Select Next. Select Media Type. Select Print Range from All Slides, Current Slide, and Slides. If Slides is selected, enter the slide number. Enter Copies. • When Print in Draft mode is selected, printing is fast but the print quality is poor.
Page 252: Print Using Registered Settings (Powerpoint)
Print Using Registered Settings (PowerPoint) iPF760 Click the One-Touch Registration button. Enter name in Name. Up to 31 characters can be entered. Click . The name you entered is displayed in Registered Settings. Click OK, and return to the Print screen.
Page 253 Print Using Registered Settings (PowerPoint) Click Print Using Registered Settings. Click the Next button. Select Media Type. Select Print Range from All Slides, Current Slide, and Slides. If Slides is selected, enter the slide number. Enter Copies. • When Print in Draft mode is selected, printing is fast but the print quality is poor.
Page 254: Portrait Orientation / Landscape Orientation (Powerpoint)
Portrait Orientation / Landscape Orientation (PowerPoint) iPF760 Portrait Orientation / Landscape Orientation (PowerPoint) Portrait Orientation / Landscape Orientation (PowerPoint) Print to the edge of the roll width. You can print large exhibits and posters, or print the Landscape or Portrait Orien- tation Page Sizes made in the Large-Format Printing Wizard.
Page 255: To Start From Microsoft Excel
To start from Microsoft Excel Click the Create Page button. Click OK if the message is displayed. Edit and create the document. • The layout may collapse if you create a form using existing data. If that is the case, modify the data again.
Page 256: Print Entire Sheet (Excel)
Print Entire Sheet (Excel) iPF760 Printing Wizard dialog box • If you want to change the display to another file or application while the Printing Wizard is open, close the Printing Wizard dialog box. Otherwise, you may not be able to change displays or operate the toolbar/ribbon.
Page 257 Print Entire Sheet (Excel) If a print area is set, a confirmation message dialog box will appear. To print the entire sheet, cancel the setting of the print area. The Printing Wizard dialog box is displayed. Click Print Entire Sheet.
Page 258: Print Selected Area (Excel)
Print Selected Area (Excel) iPF760 • If data analysis requires time, a message dialog will appear. If you select No, you will return to the application. Note Select Roll Paper Width that is set in the printer. Select image size.
Page 259 Print Selected Area (Excel) If Start imagePROGRAF Print Plug-In is displayed, click it. Click Print from the imagePROGRAF Print Plug-In toolbar/ribbon. • When more than one worksheet is selected, the Printing Wizard cannot be run. Select only one worksheet and click Print again.
Page 260 Print Selected Area (Excel) iPF760 The Layout menu will appear automatically. • If the range selected in Excel 2007/2010 is too large, it will not be possible to analyze the data. Select a small- er range and then run the analysis.
Page 261: Configuring Binding (Excel)
Configuring Binding (Excel) Enter Copies. • When Print in Draft mode is selected, printing is fast but the print quality is poor. • Note When Saturation is selected, you can print posters, etc., vividly. • Press the Print Preview button to display the preview screen. You can check and make changes to the layout in the preview screen.
Page 262: Configuring Special Settings
Configuring Special Settings iPF760 Click the OK button. Return to the Layout screen. Check that the Binding settings are applied in the preview screen. Configure the settings in the Printing Wizard dialog box. Configuring Special Settings Configuring Special Settings You can configure Special Settings from the imagePROGRAF Print Plug-In toolbar.
Page 263: Status Monitor
The Features of imagePROGRAF Status Monitor Status Monitor Status Monitor The Features of imagePROGRAF Status Monitor ..................263 Job Management Using imagePROGRAF Status Monitor ................264 The Features of imagePROGRAF Status Monitor The Features of imagePROGRAF Status Monitor imagePROGRAF Status Monitor is a utility for checking the printer status and managing print jobs.
Page 264: Job Management Using Imageprograf Status Monitor
Job Management Using imagePROGRAF Status Monitor iPF760 • For details, refer to the imagePROGRAF Status Monitor help. Note Job Management Using imagePROGRAF Status Monitor Job Management Using imagePROGRAF Status Monitor You can use the Job sheet in imagePROGRAF Status Monitor for operations such as pausing and canceling print jobs.
Page 265: Accounting
• The Accounting Manager in Status Monitor displays approximate estimates of the amount of paper consumed and the ink consumed per job. Canon cannot guarantee the accuracy of these estimates. These estimates will also vary depend- Important ing on the conditions of printer use.
Page 266: Accounting Manager Main Window
Accounting Manager Main Window iPF760 Select Accounting in the Accounting menu. Or, open the Accounting sheet and click the Ac- counting button. Accounting Manager Main Window Accounting Manager Main Window The Accounting Manager main window consists of a title bar, menu bar, toolbars, listed job selection area, job list area, totals area and status bar.
Page 267 Accounting Manager Main Window If you are using regular data acquisition, this area allows you to view the collective job logs for each specified period. For more information on how to select the job logs displayed, see Switching Between Displaying Jobs on Printer and Regularly Acquired Jobs →P.273...
Page 268: Job List Area
Job List Area iPF760 • Status Bar Displays messages and other information. Job List Area Job List Area The content and items of the jobs displayed in the job list area are as follows. • Job Cost This is the cost incurred in printing.
Page 269: Accounting Manager Basic Procedures
Accounting Manager Basic Procedures Accounting Manager Basic Procedures Accounting Manager Basic Procedures The first time you use the Accounting Manager, use the following procedures to configure the settings. Configure unit costs, including the costs of ink and paper. For details of the unit cost settings, see Configuring Unit Costs in Accounting Manager →P.269...
Page 270: Setting The Unit Cost For Paper
Setting the Unit Cost for Paper iPF760 To set the same unit cost for all the inks Select the Use same price for all ink checkbox. Enter the Tank Capacity and corresponding Price. Click the OK button. • Your settings are not applied until you click the OK button.
Page 271: Setting The Unit Cost For Items Other Than Ink And Paper
Setting the Unit Cost for Items Other Than Ink and Paper Enter the Width and Length of the paper, and the Price per area for the configured width x height. Click the Add button. To change the unit cost for a media type you have already set, click the Overwrite button.
Page 272: Configuring Units And Display Settings In Accounting Manager
Configuring Units and Display Settings in Accounting Manager iPF760 Configuring Units and Display Settings in Accounting Manager Configuring Units and Display Settings in Accounting Manager Select Units and Display in the Settings menu to open the Units and Display dialog box. Use this dialog box to configure the display settings.
Page 273: Canceling Regular Print Job Log Acquisition
Canceling Regular Print Job Log Acquisition • Immediately after you configure Regular Data Acquisition, no print jobs are displayed. Wait a few moments and then se- lect Refresh in the View menu to display the print jobs. Note •...
Page 274: Showing Job Properties
Showing Job Properties iPF760 • Listed Jobs Exports the data for the print jobs currently displayed in the list as a CSV file. Showing Job Properties Showing Job Properties If you select a job in the job list and then select Show Job Properties in the File menu, the Job Properties dialog box appears, allowing you to check information such as detailed cost data.
Page 275: Device Setup Utility
Device Setup Utility Device Setup Utility Device Setup Utility imagePROGRAF Device Setup Utility ......................275 Installing imagePROGRAF Device Setup Utility ................... 275 Configuring the IP Address Using imagePROGRAF Device Setup Utility ........... 275 imagePROGRAF Device Setup Utility imagePROGRAF Device Setup Utility imagePROGRAF Device Setup Utility is a utility to establish communication between the printer and your computer by completing relevant settings.
Page 276 Configuring the IP Address Using imagePROGRAF Device Setup Utility iPF760 In the Device Name list displayed, select the printer to configure. Choose Protocol Settings from the Printer menu. Select the IPv4 tab. In the Setting IP Address list, choose Manual.
Page 277 Configuring the IP Address Using imagePROGRAF Device Setup Utility Select the IPv6 tab. In IPv6, select On. When there is an IPv6-compatible router in the network environment, select On in Stateless Address. Additionally, when there is an DHCPv6-compatible server in the network environment, select On in DHCPv6.
Page 278: Media Configuration Tool
The Features of Media Configuration Tool iPF760 Media Configuration Tool Media Configuration Tool The Features of Media Configuration Tool ....................278 Installation Procedures ..........................278 Starting the Media Configuration Tool ......................280 Media Configuration Tool Main Window ...................... 281 Editing Media Type Information ........................281 Adding Media Types ..........................
Page 279 Installation Procedures The next screen presents selections for the country or area where the printer is used. Select a country or territory then click the Next but- ton. The License Agreement is displayed. Select I accept the terms of the license agreement and click the Next button.
Page 280: Starting The Media Configuration Tool
Starting the Media Configuration Tool iPF760 The Ready to Install the Program screen appears. Click the Install button. All the required files are copied to your computer and InstallShield Wizard Complete screen appears. Click the Finish button. This completes the installation of Media Configuration Tool.
Page 281: Media Configuration Tool Main Window
For more information about Edit Media Type Information, see "Editing Media Type Information." →P.281 • Support Information Button Click this button to access the Canon support webpage, where you can find the latest printer information, check for software updates, and browse other information. • User Manual Button Click this button to display the printer user manual.
Page 282: Adding Media Types
Note Adding Media Types Adding Media Types Media information files (.amf files) released by Canon are registered in the printer control panel and printer driver. • Do not perform printing on the target printer while adding the media types. •...
Page 283 Adding Media Types The Browse for Folder dialog box opens. Select the folder that contains the media information files (.amf files), and then click the OK button. The names of media information files in the folder you selected in the Browse for Folder dialog box are dis- played under Media Information File in the Add Me- dia Type dialog box.
Page 284: Changing Media Names
Changing Media Names iPF760 The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types." →P.288 • Be sure to click the Update button. If you do not, your changes will not be applied to the printer and printer driver.
Page 285: Deleting Media Types You Have Added
Deleting Media Types You Have Added In the Edit Media Types dialog box, click the Update button. The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types."...
Page 286: Switching Media Types Display Show/Hide
Switching Media Types Display Show/Hide iPF760 In the Edit Media Types dialog box, click the Update button. The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types."...
Page 287: Changing The Display Order Of Media Types
Changing the Display Order of Media Types In the Edit Media Types dialog box, click the Update button. The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types."...
Page 288: Updating Media Types
Updating Media Types iPF760 In the Edit Media Types dialog box, click the Update button. The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types."...
Page 289 Updating Media Types • Do not attempt to print or turn the printer off while the program is communicating with the printer. • When the program cannot communicate with the print- Important er, the following warning message is displayed.
Page 290 User's Guide...
Page 291: Mac Os X Software
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Printer Driver ................292 Preview ..................310 Free Layout ................332 Color imageRUNNER Enlargement Copy ........ 357 Printmonitor ................374 Media Configuration Tool ............376...
Page 292: Printer Driver
Printer Driver Settings iPF760 Printer Driver Printer Driver Printer Driver Settings ..........................292 Specifying Paper in the Printer Driver ......................293 Confirming Print Settings ..........................294 Checking the Layout in a Preview Before Printing ..................295 Using Favorites ............................296 Accessing the Printer Driver Dialog Box from Applications .................
Page 293: Specifying Paper In The Printer Driver
Specifying Paper in the Printer Driver You can view support information and the user's manual. With the imagePROGRAF Free Layout feature, you can arrange originals from various source applications on a single page before printing. For details, see Free Layout →P.332...
Page 294: Confirming Print Settings
Confirming Print Settings iPF760 Access the Page Setup pane. In the Paper Source list, select how paper is supplied. If you have selected Manual in Paper Source, make sure the size as selected in Page Setup is dis- played in Page Size.
Page 295: Checking The Layout In A Preview Before Printing
Checking the Layout in a Preview Before Printing Checking the Layout in a Preview Before Printing This topic describes how to check the layout before printing using the Canon imagePROGRAF Preview function. Choose Print in the application menu. User's Guide...
Page 296: Using Favorites
Click Print. The Canon imagePROGRAF Preview window is displayed. Check the layout and adjust settings in the Canon imagePROGRAF Preview window as desired. Print from the Canon imagePROGRAF Preview menu. • For details on imagePROGRAF Preview functions, refer to Preview →P.310...
Page 297: Main Pane
Main Pane Select the printer in the Printer list. Click Print to start printing. As shown in the following illustration, you can switch to other panes in this dialog box to complete settings for various methods of printing, including enlarged and reduced printing, borderless printing, and so on.
Page 298 Main Pane iPF760 • Displays Paper Detailed Settings. You can configure the printing settings to match the type of media, such as the ink drying time. • Paper Detailed Settings Dialog Box →P.300 • Print Preview If you turn this on, imagePROGRAF Preview starts before printing.
Page 299 Main Pane Configuration using Advanced Settings • Print Priority Choose the graphic elements that you want to emphasize for printing. • Giving Priority to Particular Graphic Elements and Colors for Printing →P.56 • Print Quality Choose the level of print quality.
Page 300: Paper Information On Printer Dialog Box
Paper Information on Printer Dialog Box iPF760 Paper Information on Printer Dialog Box Paper Information on Printer Dialog Box On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and config- ure printer driver media type setting.
Page 301: View Settings Dialog Box For The Printing Application
View settings Dialog Box for the Printing Application • Drying Time Specify the time that the printer waits for ink to dry, as needed. The Drying Time setting is only valid for rolls. • (See " Specifying the Ink Drying Time for Rolls ")
Page 302: Matching Pane
Matching pane iPF760 Matching pane Matching pane On the Matching pane, you can specify color matching to compensate for differences in the appearance of colors on various devices. • If No color correction is selected under Color Mode, the Matching pane is not displayed.
Page 303: Color Settings Pane: Color
Color Settings Pane: Color • To display the Matching pane, on the Main pane, click Color Settings by Color Mode in Advanced Settings, and then click the Matching tab.(See " Main Pane ") →P.297 Note • Matching Mode Select the color matching mode to use, as desired.
Page 304: Object Adjustment Dialog Box: Color
Object Adjustment dialog box: Color iPF760 • Gray Tone Adjust the color tone of grays as desired. Choose Cool (tinged with blue) or Warm (tinged with red). • Brightness Adjust the overall image brightness as desired. You can adjust the brightness if the printed document is lighter or darker than the original image (that is, the original photo that was scanned or the original graphic as it ap- pears on the computer screen).
Page 305: Color Settings Pane: Monochrome
Color Settings Pane: Monochrome Color Settings Pane: Monochrome Color Settings Pane: Monochrome On the Color Adjustment pane for monochrome printing, you can adjust the brightness and contrast. • To display the Color Adjustment pane, on the Main pane, click Color Settings in Advanced Settings.(See " Main Pane ")
Page 306: Object Adjustment Dialog Box: Monochrome
Object Adjustment dialog box: Monochrome iPF760 Object Adjustment dialog box: Monochrome Object Adjustment dialog box: Monochrome In the Object Adjustment dialog box, you can specify what type of print jobs to apply color adjustment to. If an original comprises images, graphics, and text, you can specify which portion to apply color adjustment to.
Page 307 Page Setup Pane • Page Size Displays the size of the original, as specified in the page settings of the application. For details on page sizes available in the application. see " Paper Sizes " →P.392 • Enlarged/Reduced Printing Select this checkbox to choose the following options.
Page 308: Utility Pane
Utility Pane iPF760 Utility Pane Utility Pane The following settings are available on the Utility pane. • Click to display the Printer Information dialog box, which offers the following maintenance for the printer. • Nozzle (ink ejecting outlet) cleaning •...
Page 309: Support Pane
On the Support pane, you can view support information and the user's manual. • Support Information Click to access the Canon support webpage, where you can find the latest information on the printer and con- sumables, check for printer driver updates, and browse other information. •...
Page 310: Preview
The Features of Preview iPF760 Preview Preview The Features of Preview ..........................310 Starting Preview ............................310 Preview Main Window ..........................311 Paper Settings Panel ............................ 314 Easy Settings ............................315 Advanced Settings ..........................317 Output Settings Panel ..........................318 Color Settings Panel .............................
Page 311: Preview Main Window
Preview Main Window Click the Print button in the Print dialog box. • Your printer is depicted in the lower-left area of this screen. Note Preview main window is displayed. Preview Main Window Preview Main Window The Preview main window consists of the menu and tool bars, and preview, dialog , drawer and status area.
Page 312 Preview Main Window iPF760 • Menu Bar This allows you to select menus required for operations. • Tool Bar This allows you to select tool buttons required for major operations. • Preview Area You can check the settings you made in this area.
Page 313 Preview Main Window • Dialog Area This allows you to set the print conditions and perform a print job. • Drawer Area This allows you to display the thumbnails of a document. This area appears when you click Drawer from the tool bar.
Page 314: Paper Settings Panel
Paper Settings Panel iPF760 Paper Settings Panel Paper Settings Panel This panel appears when you select Paper Settings in the dialog area. • Media Type This allows you to select the media type. • Always select media type that is actually set in the printer. When the media you chose is different from the media set in the printer, you may not receive the desired print results.
Page 315: Easy Settings
Easy Settings • Available only if rolls are selected in Paper Source. Note • Copies You can input the number of print copies in numerical characters. • The maximum value is 999. • You can change the numbers by clicking either ▲ button or ▼ button.
Page 316: Print Quality
Easy Settings iPF760 Setting Details Default Settings Suitable for printing normal documents that contain a mixture of text, photographs, and graph- ics. Office Document Suitable for printing handouts as well as general office documents for which print clarity is key.
Page 317: Advanced Settings
Advanced Settings Advanced Settings Advanced Settings Presents detailed settings for the print quality, the color mode, and other items so you can select the values for these settings yourself. • Print Priority Select a print quality mode that is appropriate for the print job.
Page 318: Output Settings Panel
Output Settings Panel iPF760 • The availability of settings is determined by the media type and print priority selections. • Note Printing time is longer and more ink is consumed with High than with Fast, however, print quality is higher.
Page 319 Output Settings Panel • Borderless Printing You can print the media without margins on all sides when the roll paper with the specific width and the specif- ic media type is used. For more information about Borderless Printing, see "Print with No Borders."...
Page 320: Color Settings Panel
Color Settings Panel iPF760 Color Settings Panel Color Settings Panel This panel appears when you select Color Settings in the dialog area. • Color Mode You can select a color mode to suit the print job. Setting Details Color Enables color printing.
Page 321: Color Adjustment
Color Adjustment • Print Button Click the button to begin printing. • Update Printer Info. Button Click the button to acquire printer information. Color Adjustment Color Adjustment You can set the color adjustment. Adjusting Color Normally colors should be adjusted in the software application, but if you see colors in the printout that do not match colors on the screen, you can perform color adjustments.
Page 322 Color Adjustment iPF760 Setting Details Gray Tone Adjusts gray from cool black (bluish tones) to warm black (reddish tones). • You can also click the up or down arrow, or enter the number directly to increase or decrease the value.
Page 323: Matching
Matching Matching Matching You can set the matching. • If No color correction is selected under Color Mode, the Matching is not displayed. Important • Matching Mode You can select a matching mode to suit the print job. Setting Details Enables printing of optimal color tones using a driver specific color profile.
Page 324: Driver Matching Mode
Driver Matching Mode iPF760 • You can select only after ICC Matching Mode has been selected in Matching Mode. Note • Printer Profile Select the printer profile. • (Using Mac OS X 10.4)You can select only after ICC Matching Mode or ColorSync has been selected in Matching Mode.
Page 325: Icc Matching Mode
ICC Matching Mode Setting Details Colorimetric Color-matching optimized for printing image data with accurate colors in input color space. This is the easiest-to-use mode when you want to adjust the color and print. However, gra- dation may be lost for colors of wider range than the color reproduction range of the printer.
Page 326: Colorsync
ColorSync iPF760 ColorSync ColorSync Check that ColorSync is selected in Matching Mode. To apply ColorSync to previews, check the Soft Proof check box. Preferences Dialog Box Preferences Dialog Box This dialog box appears when you select Preferences from the imagePROGRAF Advanced Preview menu. You can set the preferences for Preview.
Page 327: Zoom Dialog Box
Zoom Dialog Box Zoom Dialog Box Zoom Dialog Box This dialog box appears when you select Zoom from the View menu. You can enlarge or reduce the screen dis- play. • Scaling Set the magnification for enlargement or reduction of the screen display.
Page 328: Print On The Center
Print on the Center iPF760 Click the Borderless Printing check box on. Click the Print button. Borderless printing begins. Print on the Center Print on the Center You can print on the center of the media loaded in the printer.
Page 329: Print Page Rotated 90 Degrees
Print Page Rotated 90 Degrees On the Output Settings panel, click the No Spaces at Top or Bottom check box on. Click the Print button. Printing on the settings with no spaces at top or bottom begins. Print Page Rotated 90 Degrees Print Page Rotated 90 Degrees You can save paper by printing in landscape orientation on roll paper.
Page 330: Display With All
Display with All iPF760 Fitting to the width of the paper, it is displayed. Display with All Display with All In the preview area, you can display all. Select Fit Screen from the tool bar. All is displayed. Display with Actual Size Display with Actual Size In the preview area, you can display the actual size.
Page 331: Moving A Page
Moving a Page Actual size is displayed. Moving a Page Moving a Page You can move a page to display in the preview area. Select each button in Go to Page on the tool bar. Setting Details Go to the first page.
Page 332: Free Layout
The Features of Free Layout iPF760 Free Layout Free Layout The Features of Free Layout ........................332 Starting Free Layout ............................. 332 Free Layout Main Window ..........................333 Paper Settings Panel ............................ 336 Easy Settings ............................337 Advanced Settings ..........................339 Color Settings Panel .............................
Page 333: Free Layout Main Window
Free Layout Main Window Click the Print button in the Print dialog box. • Your printer is depicted in the lower-left area of this screen. Note Free Layout main window is displayed. Free Layout Main Window Free Layout Main Window The Free Layout main window consists of the menu and tool bars, layout area and dialog areas.
Page 334 Free Layout Main Window iPF760 • Menu Bar This allows you to select menus required for operations. • Tool Bar This allows you to select tool buttons required for major operations. • Layout Area This allows you to lay out objects and edit the object size and orientation.
Page 335 Free Layout Main Window • Dialog Area This allows you to set the print conditions and perform a print job. User's Guide...
Page 336: Paper Settings Panel
Paper Settings Panel iPF760 Paper Settings Panel Paper Settings Panel This panel appears when you select Paper Settings in the dialog area. • Media Type This allows you to select the media type. • Always select media type that is actually set in the printer. When the media you chose is different from the media set in the printer, you may not receive the desired print results.
Page 337: Easy Settings
Easy Settings • Available only if rolls are selected in Paper Source. Note • Copies You can input the number of print copies in numerical characters. • The maximum value is 999. • You can change the numbers by clicking either ▲ button or ▼ button.
Page 338 Easy Settings iPF760 Setting Details Default Settings Suitable for printing normal documents that contain a mixture of text, photographs, and graph- ics. Office Document Suitable for printing handouts as well as general office documents for which print clarity is key.
Page 339: Advanced Settings
Advanced Settings Advanced Settings Advanced Settings Presents detailed settings for the print priority, the print quality, and other items so you can select the values for these settings yourself. • Print Priority Select a print quality mode that is appropriate for the print job.
Page 340: Color Settings Panel
Color Settings Panel iPF760 • The availability of settings is determined by the media type and print priority selections. • Note Printing time is longer and more ink is consumed with High than with Fast, however, print quality is higher.
Page 341: Color Adjustment
Color Adjustment • Color Adjustment →P.341 • Matching →P.343 • Matching is not displayed if No color correction has been selected in Color Mode. Note • Restore Defaults Button Click the button to reset to the setting when starting Free Layout.
Page 342 Color Adjustment iPF760 Setting Details Magenta Adjusts the strength of colors to compensate the hues. Yellow Adjusts the strength of colors to compensate the hues. Brightness Adjusts the brightness of the entire image. When the results of the printout are brighter than the original images such as the original photo before scanning and graphics created on the display, or when you want to print in different degrees of brightness, use this feature.
Page 343: Matching
Matching Drag each slider to the left or right to adjust. Setting Details Brightness Adjusts the brightness of the entire image. When the results of the printout are brighter than the original images such as the original photo before scanning and graphics created on the display, or when you want to print in different degrees of brightness, use this feature.
Page 344: Printer Profile
Matching iPF760 Setting Details ColorSync Enables color matching by using the ColorSync function of Mac OS. Select this if you want to →P.347 perform soft proofing using ColorSync before printing. • You need to set each correction on the printer driver.
Page 345: Driver Matching Mode
Driver Matching Mode Driver Matching Mode Driver Matching Mode Under Matching Mode, select Driver Matching Mode. Click Matching Method list, and then select a setting. Setting Details Auto Automatically selects the best color matching method for each Image, Graphics, Text.
Page 346: Icc Matching Mode
ICC Matching Mode iPF760 ICC Matching Mode ICC Matching Mode Under Matching Mode, select ICC Matching Mode. Click the Matching Method list, and then select a setting. Setting Details Perceptual Color-matching optimized for printing typical photos attractively. Smooth gradation is a fea- ture.
Page 347: Colorsync
ColorSync ColorSync ColorSync Check that ColorSync is selected in Matching Mode. Place a checkmark on Soft Proof to simulate the output product in Layout Area. Preferences Dialog Box Preferences Dialog Box This dialog box appears when you select Preferences from the imagePROGRAF Advanced Preview menu. You can set the preferences for Free Layout.
Page 348: Page Setup Dialog Box
Page Setup Dialog Box iPF760 • Gridlines You can input a grid line width value in numerical characters so that they serve as a guide to laying out ob- jects. • You can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
Page 349: Zoom Dialog Box
Zoom Dialog Box • Paper Orientation This selects the paper orientation. The following settings are available for orientation. Setting Details Vertical Prints the image and text created with the application software in the orientation as it is. Horizontal Prints the image and text by rotating sideways 90 degrees from the orientation as specified in the application.
Page 350: Format Dialog Box
Format Dialog Box iPF760 Format Dialog Box Format Dialog Box This dialog box appears when you select Format from the Object menu after you select an object. You can rotate, enlarge, or reduce an object. • When the objects are not selected, you can not select Format.
Page 351: Laying Out A Document Created With Multiple Application Programs On One Page
Laying out a Document Created with Multiple Application Programs on One Page In the Print dialog box, select the pages to print and the number of copies, and click the Print button. Free Layout starts, laying out the document created with application software in the layout area as an ob- ject.
Page 352: Changing The Object Size
Changing the Object Size iPF760 Changing the Object Size Changing the Object Size You can change the object size by means of mouse operation or by specifying a scaling value. • The vertical-to-horizontal ratio remains unchanged when the object is enlarged or reduced.
Page 353: Rotating An Object
Rotating an Object Rotating an Object Rotating an Object You can rotate the object. Select an object. Select Rotate Left or Rotate Right from the toolbar. Alternatively, you may click on the Rotate check box in the Format Dialog Box then select Rotate →P.350...
Page 354 Aligning Objects iPF760 Select the align menu from the Object menu. • Align Top Lays out the objects, justifying them to the top. • Center Vertically Lays out the objects, justifying them to the verti- cal center. • Align Bottom Lays out the objects, justifying them to the bot- tom.
Page 355: Changing The Object Overlapping Order
Changing the Object Overlapping Order • Center Horizontally Lays out the objects, justifying them to the hori- zontal center. • Align Right Lays out the objects, justifying them to the right. Changing the Object Overlapping Order Changing the Object Overlapping Order You can change the object overlapping order.
Page 356: Pasting A Copied Or Cut Object
Pasting a Copied or Cut Object iPF760 • Bring Forward Moves the object one position to the front. • Send Backward Moves the object one position to the back. Pasting a Copied or Cut Object Pasting a Copied or Cut Object Click Copy or Cut from the toolbar.
Page 357: Color Imagerunner Enlargement Copy
The Features of Color imageRUNNER Enlargement Copy Color imageRUNNER Enlargement Copy Color imageRUNNER Enlargement Copy The Features of Color imageRUNNER Enlargement Copy ................357 Starting Color imageRUNNER Enlargement Copy ..................358 Color imageRUNNER Enlargement Copy Dialog Box ................. 359 Hot Folder ..............................
Page 358: Starting Color Imagerunner Enlargement Copy
NER Enlargement Copy. to open the Color image- RUNNER Enlargement Copy dialog box. • You can also start the utility directly by clicking on the Color imageRUNNER Enlargement Copy.app icon in Applica- tions > Canon Utilities > iR Enlargement Copy. Note User's Guide...
Page 359: Color Imagerunner Enlargement Copy Dialog Box
Color imageRUNNER Enlargement Copy Dialog Box Color imageRUNNER Enlargement Copy Dialog Box Color imageRUNNER Enlargement Copy Dialog Box The explanation below is on the Color imageRUNNER Enlargement Copy dialog box. • For the step to open the Color imageRUNNER Enlargement Copy dialog box, see "Starting Color imageRUNNER En- largement Copy."...
Page 360: Creating A New Hot Folder
Creating a New Hot Folder iPF760 Creating a New Hot Folder Creating a New Hot Folder Open the Color imageRUNNER Enlargement Copy dialog box. • For the step to open the Color imageRUNNER Enlargement Copy dialog box, see "Starting Color imageRUN- NER Enlargement Copy."...
Page 361: Editing A Hot Folder (Setting Print Conditions)
Editing a Hot Folder (Setting Print Conditions) Click the OK button. The created Hot Folder is listed in the Color imageRUNNER Enlargement Copy di- alog box. Click the Close button to close the Color imageRUNNER Enlargement Copy dialog box.
Page 362 Editing a Hot Folder (Setting Print Conditions) iPF760 Make the necessary settings in the Paper Settings Panel →P.364 Make the necessary settings in the Output Settings Panel →P.368 User's Guide...
Page 363: Deleting A Hot Folder
Deleting a Hot Folder Make the necessary settings in the Color Settings Panel →P.369 Click the OK button to close the Add/Edit Hot Folder dialog box. From the Apple Menu, open the Sharing dialog box for System Preferences. For OS X 10.4: Check the Windows Sharing and FTP Access checkboxes to configure the sharing.
Page 364: Setting The Print Parameters
Setting the Print Parameters iPF760 Select Delete the entire folder, as well as items in the list above, and then click the Delete button. Read the messag,e and then click the OK button. • Select Delete files in the folder to delete only files in the hot folder.
Page 365: Easy Settings
Easy Settings • Paper Source You can select the paper source. The following settings are available for paper source. Setting Details Manual Select for manual paper feed printing. Roll Paper Select to print on roll paper. • Roll Paper Width This selects the width of the roll media set to the printer.
Page 366 Easy Settings iPF760 • Print Target You can easily select the best settings for the print job simply. If you select each Print Target item the corresponding comment for that item is displayed below the list. Setting Details Default Settings Suitable for printing normal documents that contain a mixture of text, photographs, and graph- ics.
Page 367: Advanced Settings
Advanced Settings Advanced Settings Advanced Settings Presents detailed settings for the print priority, the print quality, and other items so you can select the values for these settings yourself. • Print Priority Select a print quality mode that is appropriate for the print job.
Page 368: Output Settings Panel
Output Settings Panel iPF760 Output Settings Panel Output Settings Panel • Enlarged/Reduced Printing Select the method for enlarged/reduced printing. The following settings are available for enlarged/reduced printing. Setting Details Fit Paper Size Enlarges/reduces the whole page automatically to fit the media size selected for output. Select the media size to print from Paper Size.
Page 369: Color Settings Panel
Color Settings Panel • This feature is useful when you print the document enlarged or reduced with Scaling as well. When an image is scaled, it is always enlarged or reduced in reference to a starting point in the upper left corner of the page. If the Note image is reduced, the bottom and right margins are enlarged and the top and left margins remain unchanged.
Page 370: Driver Matching Mode
Driver Matching Mode iPF760 Setting Details Color Enables color printing. Monochrome Disables color printing and converts image from continuous color to grayscaled monochrome. Color (CAD) Prints lines in the best color possible so they are easy to see. Monochrome Bitmap Prints all colors other than white in black.
Page 371: Icc Matching Mode
ICC Matching Mode Setting Details Colorimetric Color-matching optimized for printing image data with accurate colors in input color space. This is the easiest-to-use mode when you want to adjust the color and print. However, gra- dation may be lost for colors of wider range than the color reproduction range of the printer.
Page 372: Colorsync
ColorSync iPF760 ColorSync ColorSync Under Matching Mode, select ColorSync. Click the Printer Profile list, and then select a printer profile. • Available when using Mac OS X 10.4. Note Printing Enlargements of Scanned Originals from a Color imageRUNNER Printing Enlargements of Scanned Originals from a Color imageRUNNER Scanned originals from a Color imageRUNNER can be enlarged and printed automatically.
Page 373 Printing Enlargements of Scanned Originals from a Color imageRUNNER Press Favorites, and then press the Favorites button assigned to the hot folder. Press Start on the control panel. If you scan originals on the platen glass, after scanning all originals, press Done on the touch-panel display.
Page 374: Printmonitor
The Features of imagePROGRAF Printmonitor iPF760 Printmonitor Printmonitor The Features of imagePROGRAF Printmonitor .................... 374 Job Management Using imagePROGRAF Printmonitor ................375 The Features of imagePROGRAF Printmonitor The Features of imagePROGRAF Printmonitor imagePROGRAF Printmonitor is a utility for checking the printer status and managing print jobs.
Page 375: Job Management Using Imageprograf Printmonitor
Job Management Using imagePROGRAF Printmonitor Job Management Using imagePROGRAF Printmonitor Job Management Using imagePROGRAF Printmonitor You can use the Driver Panel in imagePROGRAF Printmonitor for operations such as pausing and canceling print jobs. • Pausing/Resuming Print Jobs Selecting a print job and clicking the button pauses printing of the selected job.
Page 376: Media Configuration Tool
The Features of Media Configuration Tool iPF760 Media Configuration Tool Media Configuration Tool The Features of Media Configuration Tool ....................376 Procedures for Installing ..........................376 Procedures for Uninstalling .......................... 378 Starting the Media Configuration Tool ......................380 Media Configuration Tool main window ....................... 381 Editing Media Type Information ........................
Page 377 Select a country or territory then click the OK button. The License is displayed. After you have read Canon Software License Agree- ment, click the Continue button. Click the Agree button. Select Easy Install then click the Install button.
Page 378: Procedures For Uninstalling
When the installation is completed properly, the Media Configuration Tool folder is saved in the following fold- Note Applications > Canon Utilities > iPFxxxx Media Configuration Tool • The iPFxxxx in the folder above will be the printer name in use.
Page 379 Select a country or territory then click the OK button. The License is displayed. After you have read Canon Software License Agree- ment, click the Continue button. Click the Agree button. Select Uninstall.
Page 380: Starting The Media Configuration Tool
Media Configuration Tool has been uninstalled. Starting the Media Configuration Tool Starting the Media Configuration Tool Follow the procedure below to start the Media Configuration Tool. From the Applications menu > Canon Utilities >iPFxxxx Media Configuration Tool > MCTxxxx.app. User's Guide...
Page 381: Media Configuration Tool Main Window
For more information about Edit Media Type Information, see "Editing Media Type Information." →P.382 • Support Information Button Click this button to access the Canon support webpage, where you can find the latest printer information, check for software updates, and browse other information. • User Manual Button Click this button to display the printer user manual.
Page 382: Editing Media Type Information
Note Adding Media Types Adding Media Types Media information files (.amf files) released by Canon are registered in the printer control panel and printer driver. • Do not perform printing on the target printer while adding the media types. •...
Page 383 Adding Media Types The Add Media Type dialog box displays. Click the Browse button. Select the folder that contains the media information files (.amf files), and then click the Open button. The names of media information files in the folder...
Page 384: Changing Media Names
Changing Media Names iPF760 In the Edit Media Types dialog box, click the Update button. The Update Media Types wizard is started at this point. For details on the procedure to update paper information using the Update Media Types wizard, see "Updating Media Types."...
Page 385: Deleting Media Types You Have Added
Deleting Media Types You Have Added The Rename Media dialog box is displayed. Edit the names in Name in Printer Driver and Name on Control Panel and click the OK button. • To restore the original names, click the Restore button.
Page 386: Switching Media Types Display Show/Hide
Switching Media Types Display Show/Hide iPF760 In the Media Type list, select the name of the media to delete. Click the Delete button. • Only paper for which Status in the Media Type is Add can be deleted. Note In the Edit Media Types dialog box, click the Update button.
Page 387: Changing The Display Order Of Media Types
Changing the Display Order of Media Types In the Media Type list, select the name of the media to switch off or on for display. Click the Show/Hide button. The selected paper is alternately shown or hidden. • The names of media switched for non-display appear grayed out in the Media Type list.
Page 388: Updating Media Types
Updating Media Types iPF760 Select the paper in the Media Type list for which to change the display order, and then click the buttons to move the item ( The selected item moves one line up or down for ev- ery button click.
Page 389 Updating Media Types Confirm the printer, where media type information is to be updated, to be displayed in Printer in the Up- date Media Types - Select Printer dialog box, and then click the Next button. Communication with the printer starts and the follow- ing dialog box is displayed.
Page 390 Updating Media Types iPF760 Communication with the printer starts and the follow- ing dialog box is displayed. • Do not attempt to print or turn the printer off while the program is communicating with the printer. Important • When the program cannot communicate with the print- er, the following warning message is displayed.
Page 391: Handling Paper
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Paper ..................392 Handling rolls ................397 Handling sheets ................ 417 Output Stacker ................. 423 Control Panel Printer Parts Network Setting Adjustments for Better Print Quality...
Page 392: Paper
Types of Paper iPF760 Paper Paper Types of Paper ............................. 392 Paper Sizes ..............................392 Displaying the Paper Reference Guide ....................... 394 Updating paper information ......................... 395 Types of Paper Types of Paper The following types of paper are supported by the printer. For details on the paper supported by the printer, refer to the Paper Reference Guide.
Page 393 Paper Sizes Roll Width Roll Paper Width Setting in Printer Driver Borderless Printing ( *1 ) 431.8 mm (17.00 in) 17-in. Roll (431.8mm) 420.0 mm (16.54 in) ISO A2/A3 Roll (420.0mm) 406.4 mm (16.00 in) 16-in. Roll (406.4mm) 355.6 mm (14.00 in) 14-in.
Page 394: Displaying The Paper Reference Guide
Displaying the Paper Reference Guide iPF760 Paper Sizes Dimensions DIN C0 917.0 × 1296.0 mm (36.10 × 51.02 in) DIN C1 648.0 × 917.0 mm (25.51 × 36.10 in) DIN C2 458.0 × 648.0 mm (18.03 × 25.51 in) DIN C3 324.0 ×...
Page 395: Updating Paper Information
Download the latest Media Information File (Media Information File) after accessing the imagePROGRAF-dedica- ted site from imagePROGRAF Support Information. If you cannot download it, contact your Canon dealer. For details on Media Information File (Media Information File), refer as follows.
Page 396 Updating paper information iPF760 • Windows Double-click the iPFxxxx Support desktop icon. (iPFxxxx indicates the printer model.) The imagePROGRAF Support Information window is displayed. Click Visit the imagePROGRAF webpage. The default browser on your computer is started and the imagePROGRAF webpage is displayed.
Page 397: Handling Rolls
Attaching the Roll Holder to Rolls Handling rolls Handling rolls Attaching the Roll Holder to Rolls ........................ 397 Loading Rolls in the Printer .......................... 399 Changing the Type of Paper ........................402 Specifying the Paper Length ........................403 Removing the Roll from the Printer ....................... 404 Removing the Roll Holder from Rolls ......................
Page 398 Attaching the Roll Holder to Rolls iPF760 Lift the Holder Stopper lever (a) from the shaft side to unlock it. Holding the Holder Stopper at the position indicated (b), remove it from the Roll Holder. Insert the respective attachments for the roll paper core on the Roll Holder and Holder Stopper.
Page 399: Loading Rolls In The Printer
Loading Rolls in the Printer With the edge of the roll paper facing forward as shown, insert the Roll Holder from the right of the roll. Insert it firmly until the roll touches the flange (a) of the Roll Holder, leaving no gap.
Page 400 Loading Rolls in the Printer iPF760 Press ▲ or ▼ to select Load Roll Paper, and then press the OK button. • If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Page 401 Loading Rolls in the Printer Holding the Roll Holder flange (a), guide the holder along the Roll Loading Slots (b) on both ends, keep- ing the holder level as you load it in the Roll Holder Slot. • Do not force the Roll Holder into the printer with the right and left ends reversed. This may damage the printer and Roll Holder.
Page 402: Changing The Type Of Paper
Changing the Type of Paper iPF760 • For details on types of paper to select, see the Paper Reference Guide. (See "Types of Paper.") →P.392 Note Holding it at the positions indicated, close the Roll Cover. • Cut the edge of the roll after the paper is advanced if it is soiled or if there are cuts from scissors or the blade after removing creased edges.
Page 403: Specifying The Paper Length
Specifying the Paper Length Press ▲ or ▼ to select the type of paper loaded in the printer, and then press the OK button. • Be sure to select the correct paper type. If this setting does not match the loaded paper, it may cause feed errors and affect printing quality.
Page 404: Removing The Roll From The Printer
Removing the Roll from the Printer iPF760 • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button. The Paper Menu is displayed. Press ▲ or ▼ to select Chg. Paper Size, and then press the OK button.
Page 405 Removing the Roll from the Printer Positioning your hands as shown, open the Roll Cov- Using both hands, rotate the Roll Holder toward the back to rewind the roll. Holding the Roll Holder flange (a), remove the holder from the Roll Holder Slot.
Page 406: Removing The Roll Holder From Rolls
Removing the Roll Holder from Rolls iPF760 Holding it at the positions indicated, close the Roll Cover. • To load new paper in the printer at this point, see "Loading Rolls in the Printer." →P.399 Note Removing the Roll Holder from Rolls...
Page 407: Feeding Roll Paper Manually
Feeding Roll Paper Manually When removing attachments, push the tips (a) in as you remove the attachment. • 3-Inch Paper Core Attachment R ( Roll Holder side) • 3-Inch Paper Core Attachment L ( Holder Stopper side) • 2-Inch Paper Core Attachment •...
Page 408: Keeping Track Of The Amount Of Roll Paper Left
Keeping Track of the Amount of Roll Paper Left iPF760 Press the Feed button. Press the ▲ or ▼ button to advance or retract the roll. Press ▲ to retract the roll manually. Press ▼ to advance the roll manually.
Page 409 Specifying the Ink Drying Time for Rolls Windows Display the printer driver dialog box. (See "Accessing the Printer Driver Dialog Box from the Operating System Menu(Windows).") →P.165 Select the Main sheet and click Advanced Set- tings in Media Type.
Page 410: Specifying The Cutting Method For Rolls
Specifying the Cutting Method for Rolls iPF760 In the Paper Detailed Settings dialog box displayed next, select the desired settings values in tween Pages and Between Scans in Drying Time, and then click OK. (See "Paper Detailed Settings Dialog Box(Mac OS X).")
Page 411 Specifying the Cutting Method for Rolls Eject (waiting for ink to dry after printing) • When cutting wide printed documents after ejection, have two people support the documents. If the paper drops, printed documents may be damaged. Important •...
Page 412 Specifying the Cutting Method for Rolls iPF760 Manual (when using media that cannot be cut with the Cutter Unit) On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Paper tab ( • If the Tab Selection screen is not displayed, press the Menu button.
Page 413 Specifying the Cutting Method for Rolls Cut the roll paper manually with scissors or the like. Press the OK button. After the roll is rewound, it stops automatically. Paper cutting (to have the roll cut at your specified position) Press the Feed button.
Page 414: Cutting The Leading Edge Of Roll Paper Automatically
Cutting the Leading Edge of Roll Paper Automatically iPF760 Press the Cut button. Press ▲ or ▼ to select Yes, and then press the OK button. After the roll paper is cut, it is rewound automatically. • If paper would be short when cut at a particular position, the roll may automatically be advanced in some cases before cutting.
Page 415: Reducing Dust From Cutting Rolls
Reducing Dust from Cutting Rolls • In the condition at the time of factory shipment, the setting differs depending on the paper. For details, refer to the Paper Reference Guide. (See "Types of Paper.") →P.392 Note Follow these steps to change the Trim Edge First setting.
Page 416 Reducing Dust from Cutting Rolls iPF760 • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button. The Paper Menu is displayed. Press ▲ or ▼ to select Paper Details, and then press the OK button.
Page 417: Handling Sheets
Loading Sheets in the Printer Handling sheets Handling sheets Loading Sheets in the Printer ........................417 Printing From a Desired Starting Point ......................419 Removing Sheets ............................422 Loading Sheets in the Printer Loading Sheets in the Printer Follow these steps to load sheets in the printer.
Page 418 Loading Sheets in the Printer iPF760 Slide the Width Guide (a) to align it with the mark for the size of paper you will load. Load a single sheet printing-side up in the Paper Feed Slot, with the right edge aligned with the Paper Alignment Guide (a) to the right of the Roll Cover.
Page 419: Printing From A Desired Starting Point
Printing From a Desired Starting Point Move the Width Guide (a) carefully to match the size of paper loaded. Set the Width Guide against the edge of the paper to prevent the paper from becoming crooked or wrinkled. Press the OK button.
Page 420 Printing From a Desired Starting Point iPF760 Press ▲ or ▼ to select Paper Details, and then press the OK button. Press ▲ or ▼ to select the type of paper, and then press the OK button. Press ▲ or ▼ to select Width Detection, and then press the OK button.
Page 421 Printing From a Desired Starting Point Keeping the right edge of the paper aligned with the extended line of the Paper Alignment Line (a) to the right of the ejection guide and the leading edge aligned with the groove (b) at the far end of the Plat- en, load the paper at the position from which to start printing.
Page 422: Removing Sheets
Removing Sheets iPF760 Removing Sheets Removing Sheets Remove sheets from the printer as follows. On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Paper tab ( • If the Tab Selection screen is not displayed, press the Menu button.
Page 423: Output Stacker
Using the Output Stacker Output Stacker Output Stacker Using the Output Stacker Using the Output Stacker This section describes how to use the Output Stacker. • When storing printed documents on the Output Stacker Use position (1). For details on how to use the Extended position which is a useful function for retrieving prin- ted matter, refer to the note regarding the Extended position.
Page 424 Using the Output Stacker iPF760 Extended position A Extended position B • Switching to Extended position A Switch the stacker to Extended position A as follows. Lift the Support Rod to the position shown (a) and switch the stacker to Extended position A.
Page 425 Using the Output Stacker When using 24-inch or A1 (portrait) roll paper, pull out the Adjustable Stopper (a). This completes the proce- dure for switching to Extended position A. Once the printing has finished, use the following procedure to return to the regular position.
Page 426 Using the Output Stacker iPF760 Grasp the Output stacker handle (a) and pull out the Output Stacker so that it tilts towards you. Open the Output Stacker Ejection Guides (a). This completes the procedure of switching to Extended position B.
Page 427 Using the Output Stacker Hold onto the Output stacker handle (a) and pull the Output stacker release lever (b) towards you. While continuing to hold the Output stacker handle (a), slowly lower the Output Stacker. Return to the regular position.
Page 428 User's Guide...
Page 429: Control Panel
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Operations and Display Screen ..........430 Printer Menu ................438 Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables...
Page 430: Operations And Display Screen
Control Panel iPF760 Operations and Display Screen Operations and Display Screen Control Panel ..............................430 Control Panel Display ........................... 431 How to View Instructions With Navigate ....................... 435 Checking Instructions During Printer Operations ..................436 Control Panel Control Panel Display Screen Shows printer menus, as well as the printer status and messages.
Page 431: Control Panel Display
Control Panel Display The Power button is lit when the printer is on or in Sleep mode. Stop button Cancels print jobs in progress and ends the ink drying period. Navigate button Enables you to check instructions for loading and removing paper or replacing ink tanks or printheads, as well as other operations.
Page 432: Printer Status And Modes
Control Panel Display iPF760 Types of tabs The Tab Selection screen presents four tabs. Each tab is represented by an icon in the top row. Press the ◀ or ▶ button to access other tabs. Paper tab A tab indicating status and showing menus related to paper. Pressing the OK button when this tab is high- lighted will display the Paper Menu.
Page 433: Mode Transition
Control Panel Display Standby The printer is ready to receive jobs sent from the computer. Jobs sent from the computer are printed imme- diately. Printing Paused Printing is paused on the printer. Any jobs sent from the computer are held without being printed.
Page 434 Control Panel Display iPF760 The printer mode is indicated as follows. *1: The printer automatically enters Sleep mode when idle for a specific period (by default, five minutes), that is, if no print jobs are received or buttons are pressed while all covers are closed. However, it does not enter Sleep mode while error messages are displayed.
Page 435: How To View Instructions With Navigate
How to View Instructions With Navigate If multiple errors occur, tabs related to errors other than the error currently shown flash. Press the ◀ or ▶ button to access other tabs and check those errors. If multiple errors occur that are related to the Job tab and Settings/Adj.
Page 436: Checking Instructions During Printer Operations
Checking Instructions During Printer Operations iPF760 Example: Loading sheets Checking Instructions During Printer Operations Checking Instructions During Printer Operations You can refer to instructions on the printer control panel when loading paper, replacing ink tanks, or performing other operations. How to view instructions Once you complete an action described in the instructions, the printer detects the action and switches to the next instruction screen.
Page 437 Checking Instructions During Printer Operations When all actions in the sequence are finished, the instruction screen for the next step is displayed. Example: Ink tank replacement • During a continuous display of instructions, you can press the ◀ button to pause the instructions on the current screen.
Page 438: Printer Menu
Printer Menu Operations iPF760 Printer Menu Printer Menu Printer Menu Operations ..........................438 Menu Operations ............................439 Menu Structure ............................. 442 Menu Settings .............................. 448 Status Print ..............................457 Printing Interface Setting Reports ........................ 459 Printer Menu Operations Printer Menu Operations The printer menu is classified into regular menu items available when no print job is in progress and menu during printing items only available while printing is in progress.
Page 439: Menu Operations
Menu Operations Fine-tuning paper feeding Display of printer-related information For a description of specific menu items available, see "Menu Settings." →P.448 For instructions on selecting menu items during printing, see "Menu Operations." →P.439 Menu Operations Menu Operations To view available menus organized on tabs, select a tab on the Tab Selection screen and press the OK button.
Page 440 Menu Operations iPF760 • Press Back to access a higher menu in the menu list, and press OK to access a lower one. If not all menu items are displayed, hold down ▲ or ▼ to scroll through higher and lower menu items. Items you select are highlighted.
Page 441 Menu Operations Specifying numerical values Follow these steps to enter numbers. In this example, network settings items are entered. Press the ◀ or ▶ button to move to the next field for input. Press the ▲ or ▼ button to enter the value.
Page 442: Menu Structure
Menu Structure iPF760 Menu Structure Menu Structure The menu structure is shown categorized by tab. The * on the right side of an item indicates the default value. The printer menu is classified into regular menu items available when no print job is in progress and menu during printing items only available while printing is in progress.
Page 443: Ink Menu
Menu Structure First Level Second Level Third Level Fourth Level Fifth Level Paper Details Keep Paper Type Off *┋ On *1: For information on the types of paper the printer supports, refer to the Paper Reference Guide. (See Paper Reference Guide .) Types of paper in the printer driver and related software (as well as on the Control Panel) are updated when you install the printer driver from the User Software CD-ROM or if you update paper information with the Media Configuration Tool.
Page 444 Menu Structure iPF760 First Level Second Level Third Level Fourth Level Fifth Level Sixth Level Seventh Level Eighth Level Change A:High ┋ B:Standard/Draft Settings Mainte- Head Head Cleaning A ┋ Head Cleaning B nance Cleaning Nozzle Check Replace P.head Repl. maint cart Head Info ProductName: ┋...
Page 445 Menu Structure First Level Second Level Third Level Fourth Level Fifth Level Sixth Level Seventh Level Eighth Level GL2 Set Print Interface EOP Timer 10 sec. ┋ 30 sec. ┋ 1 min. ┋ 2 min. ┋ 5 min. ┋ 10 min. *┋ 30 min. ┋ 60 min.
Page 446 Menu Structure iPF760 First Level Second Level Third Level Fourth Level Fifth Level Sixth Level Seventh Level Eighth Level MAC Ad- xxxxxxxxxxx dress ( *8 ) Interface Print ( *8 ) Return Defaults ( *8 ) System Set- Sleep Timer 5 min.
Page 447 Menu Structure First Level Second Level Third Level Fourth Level Fifth Level Sixth Level Seventh Level Eighth Level Ink Info Head Info Product- Name: s/n: Days elapsed: Count [Mdot]: Printhead L ProductName: ┋ s/n: ┋ Days elapsed: ┋ Count [Mdot]: Printhead R ProductName: ┋...
Page 448: Menu Settings
Menu Settings iPF760 Menu Settings Menu Settings Menu items are as follows. The printer menu is classified into regular menu items available when no print job is in progress and menu during printing items only available while printing is in progress. see "Printer Menu Operations."...
Page 449 Menu Settings Setting Item Description, Instructions Paper Details (The type of paper Scan Wait Time Specify the time to wait for the ink to dry between each scan (after is displayed here.) the printhead finishes moving in one direction), in consideration of ( *1 ) how quickly the ink dries.
Page 450: Set./Adj. Menu
*1: Indicates a rough estimate of how much ink was consumed per page. Actual ink consumption may be different. The average margin of error for estimates calculated according to Canon measurement conditions for ink costs is ±15%. Canon does not guarantee the accuracy of these estimates.
Page 451 Menu Settings Setting Item Description, Instructions Adjust Head Auto(Standard) The printer prints and reads a test pattern for automatic ad- Printer Posi. justment of Printhead alignment relative to the printing direc- Adj. tion. (See "Automatic Adjustment to Straighten Lines and Col- ors (Head Posi.
Page 452 Print in brighter colors. Color (CAD) 3 Print emulating the following printers, in colors resembling colors produced by these printers: Canon iPF500, iPF600, iPF700, iPF510, iPF610, iPF710, iPF605, iPF720, iPF810, iPF815, iPF820, and iPF825. ( *2 ) Color (CAD) 4 Print emulating the HP Designjet 500/800, in colors resem- bling colors produced by these printers.( *2 )
Page 453 Menu Settings Setting Item Description, Instructions GL2 Set- Line & Pen Set- Select Palette Choose Software to print according to software settings. tings Choose Palette A or Palette B to print using the value speci- Manager fied in Define Palette.
Page 454 Menu Settings iPF760 Setting Item Description, Instructions GL2 Set- Proces- PageSizeProcess1 Normally, the area available for printing excludes a margin tings singOp- required by the printer, and images are positioned according- tion ly. Selecting On in this setting eliminates any misalignment of the printing position if the image itself includes a border.
Page 455 Menu Settings Setting Item Description, Instructions Interface Ethernet Spanning Tree Choose whether spanning-tree packets are supported over Setup Driver the LAN. MAC Address Indicates the MAC address. Interface Print Print interface settings information. Return Defaults Choose OK to restore Interface Setup settings to the default values.
Page 456 Menu Settings iPF760 Setting Item Description, Instructions System Keep Paper Size Setup TrimEdge Reload Specify whether to trim the leading edge of the currently re- tracted roll when the roll is advanced. Cut the edge if you are concerned about any marks left on the roll when the roll is left in the retracted position.
Page 457: Status Print
*1: Indicates a rough estimate of how much ink was consumed per page. Actual ink consumption may be different. The average margin of error for estimates calculated according to Canon measurement conditions for ink costs is ±15%. Canon does not guarantee the accuracy of these estimates.
Page 458 Press ▲ or ▼ to select Status Print, and then press the OK button. Checking the information in Status Print reports The following information is included in Status Print reports. Canon imagePROGRAF iPFxxxx Status Print Printer model Firm Firmware Version...
Page 459: Printing Interface Setting Reports
Printing Interface Setting Reports Nozzle-check settings. Timing Warning Use USB Setting value for using USB. Use Ethernet Setting value for using Ethernet. Use RemoteUI Settings used by RemoteUI. Printer Info Various printer information. Ink Info Ink-related information. Maintenance Cartridge capacity (%) C,M,Y,MBK,MBK2,BK Ink levels.
Page 460 Press ▲ or ▼ to select Test Print, and then press the OK button. Press ▲ or ▼ to select Interface Print, and then press the OK button. Confirming Interface Print information The following information is included in the Interface Print report. Canon imagePROGRAF iPFxxxx Interface Print Printer model Firm Firmware Version...
Page 461 Printing Interface Setting Reports TCP/IPv4 IPv4 settings values. Primary DNS Server Address Secondary DNS Server Address DNS Host Name DNS Domain Name MulticastDNS ServiceName SNMPv1 SNMPv3 TCP/IPv6 Use IPv6 IPv6 settings values. Use DHCPv6 Stateful Address Prefix Length Primary DNS Server Address...
Page 462 Printing Interface Setting Reports iPF760 NetWare Bindery PServer NetWare settings val- Polling Interval ues. RPrinter Print Server Name Printer Number NDS PServer Tree Name Context Name Print Server Name Print Server Password Polling Interval NPrinter Print Server Name Printer Number...
Page 463: Printer Parts
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Printer parts ................464 Optional accessories ..............470 Network Setting Adjustments for Better Print Quality Maintenance and Consumables Troubleshooting...
Page 464: Printer Parts
Front iPF760 Printer parts Printer parts Front ................................464 Side ................................465 Top Cover (Inside) ............................466 Roll Cover (Inside) ............................467 Carriage ............................... 467 Ink Tank Cover (Inside) ..........................468 Stand ................................469 Front Front Roll Cover Open this cover to load rolls. (See "Roll Cover (Inside).") →P.467...
Page 465: Side
Side Maintenance Cartridge Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.) Cutter Unit A round-bladed cutter for automatic roll cutting. Cutter Rail The Cutter Unit passes over this rail to cut paper.
Page 466: Top Cover (Inside)
Top Cover (Inside) iPF760 Ethernet Port Connect an Ethernet cable to this port. The lamp is lit if the Ethernet cable is connected correctly and commu- nication is possible between the computer and printer. USB Port Connect a USB cable to this port. The printer is compatible with Hi-Speed USB connections.
Page 467: Roll Cover (Inside)
Roll Cover (Inside) Roll Cover (Inside) Roll Cover (Inside) Roll Holder Load the roll on this holder. Holder Stopper Secure rolls on the Roll Holder with this part. Roll Loading Slots Slide the Roll Holder along these slots. Roll Holder Slot Load the Roll Holder into this holder slot.
Page 468: Ink Tank Cover (Inside)
Ink Tank Cover (Inside) iPF760 Printhead Fixer Lever Locks the Printhead Fixer Cover. Printhead Fixer Cover Holds the Printhead in place. Ink Tank Cover (Inside) Ink Tank Cover (Inside) Left Side Right Side Ink Tank Lock Lever A lever that locks the Ink Tank in place and protects it. Lift and press down the lever when replacing an Ink Tank.
Page 469: Stand
Stand Stand Stand • Printer Stand ST-34 Accessory Pocket Stores printer accessories. Output Stacker Printed documents are ejected into the output tray. Locking Caster Lock to immobilize the caster. Before moving the printer, always unlock all four casters. Moving the printer while casters are locked may scratch the casters or the floor.
Page 470: Optional Accessories
Roll Holder Set iPF760 Optional accessories Optional accessories Roll Holder Set Roll Holder Set Load a roll on the roll holder and then load the holder in the printer. The Roll Holder in the Roll Holder Set RH2-33 is for use with both 2-inch and 3-inch paper cores. Use the correct attachment for the particular paper core. (See "Attaching the Roll Holder to Rolls.")
Page 471: Network Setting
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Network Environment ............... 472 Using RemoteUI ............... 475 Initial Settings ................477 NetWare Settings ..............484 Mac OS X Settings ..............492 Other Settings ................
Page 472: Network Environment
Network Environment iPF760 Network Environment Network Environment Network Environment Network Environment System requirements The system requirements, which vary depending on your network, are as follows. • Printing over a TCP/IP network (when using IPv4) • Compatible operating systems • Windows XP (Home Edition or Professional) •...
Page 473 Network Environment • In NetWare 6.0, iPrint is not supported. Note Network Environment After confirming what type of network environment you will connect the printer to, set up the printer and computers as needed. • Example of a Windows network In Windows networks, print over TCP/IP.
Page 474 Network Environment iPF760 • Even if there is a NetWare server in your network environment, you can use it in conjunction with TCP/IP or Apple- Talk. In this case, complete the settings for each protocol you will use. Note User's Guide...
Page 475: Using Remoteui
Using RemoteUI Using RemoteUI Using RemoteUI Using RemoteUI Using RemoteUI RemoteUI is software with which you can access the printer via the network from your Web browser to confirm the printer status, operate jobs, and configure the settings. Since the software (Web server) for using RemoteUI is built in the printer, preparing software other than a Web browser is unnecessary.
Page 476 Using RemoteUI iPF760 • For the Web browser, use Netscape Navigator 6.0 or later, Internet Explorer 5.01 or later, or Firefox 1.5 or later. For Mac OS X, Safari 1.32 or later or 2.03 or later also is supported. Important •...
Page 477: Initial Settings
Configuring the IP Address on the Printer Initial Settings Initial Settings Configuring the IP Address on the Printer ....................477 Configuring the IP Address Using the Printer Control Panel ..............477 Configuring the IP Address Using ARP and PING Commands .............. 478 Configuring TCP/IPv6 Network Settings .......................
Page 478: Configuring The Ip Address Using Arp And Ping Commands
Configuring the IP Address Using ARP and PING Commands iPF760 Press ▲ or ▼ to select TCP/IP, and then press the OK button. Press ▲ or ▼ to select IPv4, and then press the OK button. Press ▲ or ▼ to select IPv4 Settings, and then press the OK button.
Page 479: Configuring Tcp/Ipv6 Network Settings
Configuring TCP/IPv6 Network Settings Press ▲ or ▼ to select Interface Setup, and then press the OK button. Press ▲ or ▼ to select Ethernet Driver, and then press the OK button. Press ▲ or ▼ to select MAC Address, and then press the OK button.
Page 480: Configuring The Printer Driver Destination (Windows)
Configuring the Printer Driver Destination (Windows) iPF760 Press ▲ or ▼ to select IPv6 Support, and then press the OK button. Press ▲ or ▼ to select On, and then press the OK button. • Once you set IPv6 Support to On, the IPv6 StlessAddrs setting takes effect.
Page 481: Configuring The Printer's Tcp/Ip Network Settings With Remoteui
Configuring the Printer's TCP/IP Network Settings With RemoteUI Configuring the Printer's TCP/IP Network Settings With RemoteUI Configuring the Printer's TCP/IP Network Settings With RemoteUI Follow the steps below to configure the TCP/IP network settings. When using an IPv4 IP address Start the web browser and enter the following URL in the Location (or Address) box to display the Remo- teUI page.
Page 482 Configuring the Printer's TCP/IP Network Settings With RemoteUI iPF760 Item Details Default Setting Multicast DNS Service Specify the printer's Multicast DNS service name. (1–63 characters) Canon iPFxxxx Name This name will be displayed when Bonjour functions are used. (xxxxxx) Click OK to display the Network page.
Page 483 Configuring the Printer's TCP/IP Network Settings With RemoteUI Item Details Default Setting DNS Domain Name Specify the printer domain name, up to 63 characters. Use sin- blank gle-byte letters, numbers, - (hyphens), and . (periods). Do not use numbers, -, or . for the first character, or - or . for the last character.
Page 484: Netware Settings
Configuring NetWare Network Settings iPF760 NetWare Settings NetWare Settings Configuring NetWare Network Settings ....................... 484 Specifying the Printer's Frame Type ......................484 Specifying NetWare Print Services ......................487 Configuring the Printer's NetWare Network Settings With RemoteUI ............489 Configuring NetWare Network Settings Configuring NetWare Network Settings Follow these steps to configure the network environment when using the printer in a NetWare network.
Page 485 Specifying the Printer's Frame Type • You can specify the frame type by using RemoteUI if the printer's IP address is configured. • Note For instructions on installing imagePROGRAF Device Setup Utility, see "Installing imagePROGRAF Device Setup Utility." →P.275 Specifying the frame type using imagePROGRAF Device Setup Utility Start imagePROGRAF Device Setup Utility.
Page 486 Specifying the Printer's Frame Type iPF760 Select the IPv4 tab. In IP Address, enter the IP ad- dress assigned to the printer, and then enter the sub- net mask in Subnet Mask and the default gateway in Gateway Address. •...
Page 487: Specifying Netware Print Services
Specifying NetWare Print Services Press ▲ or ▼ to select On, and then press the OK button. The display reverts to the NetWare menu. Press ▲ or ▼ to select Frame Type, and then press the OK button. Press ▲ or ▼ to select the frame type to use, and then press the OK button.
Page 488 Specifying NetWare Print Services iPF760 Queue server mode and remote printer mode are both supported. • Queue server mode When using queue server mode, all print server functions are supported, so there is no need for other print server software or hardware. In NDS queue server mode (NDS PServer), the NDS print server is used for printing.
Page 489: Configuring The Printer's Netware Network Settings With Remoteui
Configuring the Printer's NetWare Network Settings With RemoteUI Switch to bindery mode. If the print server has not been created, create it. In Available Options, select Quick Setup, and press the Enter key. Enter the name of the new print server, the new printer, and the queue.
Page 490 Configuring the Printer's NetWare Network Settings With RemoteUI iPF760 Default Set- Item Details ting NCP Burst Mode Activate this setting to use NCP Burst Mode. This mode supports fast data transfer when printing in queue server mode. Normally, leave the setting On.
Page 491 Configuring the Printer's NetWare Network Settings With RemoteUI In Print Server Name, enter the advertising name of the print server created in " Specifying Net- ." Ware Print Services →P.487 In Printer Number, enter the same printer number specified in " Specifying NetWare Print Serv- ices ."...
Page 492: Mac Os X Settings
If you use the printer in a TCP/IP network, make sure the printer's IP address is configured correctly. (See "Configuring the IP Address Using the Printer Control Panel.") →P.477 Important Navigate to Applications > Canon Utilities > imagePROGRAF PrinterSetup and double-click image- PROGRAF PrinterSetup.app. Click Next. Click Registering IP Address.
Page 493: Configuring The Destination For Bonjour Network
By default, Bonjour is activated on the printer. You can activate or deactivate the Bonjour function or change the printer name by using RemoteUI. For instructions on changing it, see "Using RemoteUI." →P.475 Navigate to Applications > Canon Utilities > imagePROGRAF PrinterSetup and double-click image- PROGRAF PrinterSetup.app. Click Next.
Page 494: Configuring The Destination For Appletalk Networks
Configuring the Destination for AppleTalk Networks iPF760 Select the printer to register and click Next. Complete Printer Name and Location as desired and click Register. Click Finish. Configuring the Destination for AppleTalk Networks Configuring the Destination for AppleTalk Networks To print over an AppleTalk network, activate the AppleTalk protocol and configure the destination as follows.
Page 495 Configuring the Destination for AppleTalk Networks • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button. The Set./Adj. Menu is displayed. Press ▲ or ▼ to select Interface Setup, and then press the OK button.
Page 496: Configuring The Printer's Appletalk Network Settings
10.4. If you use multiple printers in the same zone, assign a unique name to each printer. By default, the network interface name is Canon NB-18GB (xxxxxx). (Here, xxxxxx is the last six digits of the printer's MAC address.) *2: If zones have been created on the network, enter the name of the printer's zone. If there are no zones, leave the asterisk * entry (for the default zone) as it is.
Page 497 Configuring the Printer's AppleTalk Network Settings Click OK to display the Network page. User's Guide...
Page 498: Other Settings
Specifying Printer-Related Information iPF760 Other Settings Other Settings Specifying Printer-Related Information ......................498 Configuring the Communication Mode Manually ..................499 Email Notification When Printing is Finished or Errors Occur ..............500 Initializing the Network Settings ........................500 Specifying Printer-Related Information Specifying Printer-Related Information Follow the steps below to specify device information and security settings.
Page 499: Configuring The Communication Mode Manually
Configuring the Communication Mode Manually Configuring the Communication Mode Manually Configuring the Communication Mode Manually This topic gives instructions for configuring the communication mode manually. On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj.
Page 500: Email Notification When Printing Is Finished Or Errors Occur
Email Notification When Printing is Finished or Errors Occur iPF760 Email Notification When Printing is Finished or Errors Occur Email Notification When Printing is Finished or Errors Occur The printer can notify you of the printer status by email. Even when you are away from the printer, you can know when printing is finished or if errors occur.
Page 501: Adjustments For Better Print Quality
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Adjusting the Printhead ............502 Adjusting the feed amount ............509 Maintenance and Consumables...
Page 502: Adjusting The Printhead
Adjusting the Printhead iPF760 Adjusting the Printhead Adjusting the Printhead Adjusting the Printhead ..........................502 Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj.) ..........502 Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) ........... 503 Adjusting Line Misalignment (Head Inc. Adj.) ..................... 505 Troubleshooting Paper Abrasion and Blurry Images (Head Height) ............
Page 503: Manual Adjustment To Straighten Lines And Colors (Head Posi. Adj.)
Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) • When printing on special paper, or if printing is not improved after Auto(Advanced), try Manual. (See "Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.).") →P.503 Note •...
Page 504 Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj.) iPF760 Manual adjustment requires you to examine the printed test pattern and enter an adjustment value. • Manual may be unavailable in some cases, even if it is displayed in the menu.
Page 505: Adjusting Line Misalignment (Head Inc. Adj.)
Adjusting Line Misalignment (Head Inc. Adj.) Examine adjustment test pattern D-1 and determine the num- ber with straight lines. • If two patterns seem equally good and you cannot decide which one is better, choose an intermediate value. For example, choose 11 if you cannot decide whether pattern 10 or 12 is better.
Page 506 Adjusting Line Misalignment (Head Inc. Adj.) iPF760 • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button. The Set./Adj. Menu is displayed. Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
Page 507: Troubleshooting Paper Abrasion And Blurry Images (Head Height)
Troubleshooting Paper Abrasion and Blurry Images (Head Height) Examine the test pattern for adjustment. Determine the straightest set of lines. Open the Top Cover and move the Angle Adjustment Lev- er to match the number (or the square) of the straightest set of lines.
Page 508 Troubleshooting Paper Abrasion and Blurry Images (Head Height) iPF760 Press ▲ or ▼ to select the desired setting value, and then press the OK button. • Depending on the type of paper, some setting values may not be available. Note...
Page 509: Adjusting The Feed Amount
Adjusting the Feed Amount Adjusting the feed amount Adjusting the feed amount Adjusting the Feed Amount .......................... 509 Selecting a Feed Amount Adjustment Method (Feed Priority) ..............509 Automatic Banding Adjustment (Adj. Quality) ..................510 Manual Banding Adjustment (Adj. Quality) ..................... 511 Fine-Tuning the Paper Feed Amount (Adj.
Page 510: Automatic Banding Adjustment (Adj. Quality)
Automatic Banding Adjustment (Adj. Quality) iPF760 On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab ( • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button.
Page 511: Manual Banding Adjustment (Adj. Quality)
Manual Banding Adjustment (Adj. Quality) Perform adjustment as follows. Load the paper. • Attaching the Roll Holder to Rolls →P.397 • Loading Rolls in the Printer →P.399 • Loading Sheets in the Printer →P.417 • Always make sure the loaded paper matches the type of paper specified. Adjustment cannot be completed cor- rectly unless the loaded paper matches the settings.
Page 512 Manual Banding Adjustment (Adj. Quality) iPF760 Paper to Prepare Rolls An unused roll at least 10 inches wide Sheets Two sheets of unused paper of at least A4/Letter size Perform adjustment as follows. Load the paper. • Attaching the Roll Holder to Rolls →P.397...
Page 513: Fine-Tuning The Paper Feed Amount (Adj. Fine Feed)
Fine-Tuning the Paper Feed Amount (Adj. Fine Feed) Press ▲ or ▼ to select the pattern number you have decided, and then press the OK button. Test pattern B is printed for adjustment. • If you printed test pattern A on a sheet, follow the instructions on the Display Screen and use another sheet of the same type of paper.
Page 514 Adjusting Line Length (Adjust Length) iPF760 • B:Standard/Draft This setting is applied when Standard or Fast is selected in Print Quality in the printer driver. • Always check the Adj. Priority values before using Adjust Length. (See "Selecting a Feed Amount Adjustment Method (Feed Priority).")
Page 515: Adjusting The Vacuum Strength (Vacuumstrngth)
Adjusting the Vacuum Strength (VacuumStrngth) Press ▲ or ▼ to enter the amount of discrepancy, and then press the OK button. If the scale is shorter than the actual size, use a positive setting value. If it is longer, use a negative value.
Page 516 User's Guide...
Page 517: Maintenance And Consumables
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables Ink Tanks .................. 518 Printheads ................524 Maintenance Cartridge ............. 532 Cleaning the Printer ..............
Page 518: Ink Tanks
Ink Tanks iPF760 Ink Tanks Ink Tanks Ink Tanks ..............................518 Replacing Ink Tanks ............................ 518 Checking Ink Tank Levels ..........................522 When to Replace Ink Tanks ......................... 523 Ink Tanks Ink Tanks When purchasing ink tanks, make sure a J is printed on the label, along with the following [W is printed on the label, along with the following Ink Tank serial numbers.
Page 519 Replacing Ink Tanks Make sure the printer is ready for Ink Tank replacement You can replace ink tanks if the Display Screen advises you to check the amount of ink left or replace ink tanks. If a message requests you to replace an Ink Tank, press the OK button. In this case, you can skip the step Access the menu for ink tank replacement.
Page 520 Replacing Ink Tanks iPF760 Remove the Ink Tank Open the Ink Tank Cover and check the ink lamps. Ink lamps flash when there is little ink left. Press the tip of the Ink Tank Lock Lever of the color for replace- ment horizontally and pull the Ink Tank Lock Lever up to open it.
Page 521 Replacing Ink Tanks Install the ink tanks Before opening the pouch, gently agitate the Ink Tank once or twice. Agitate the ink in the Ink Tank by slowly rotating the Ink Tank upside-down and right side up repeatedly. •...
Page 522: Checking Ink Tank Levels
Checking Ink Tank Levels iPF760 Push the Ink Tank Lock Lever closed until it clicks into place. Make sure the Ink Lamp is lit in red. • If the Ink Lamp is not lit, reload the tank. Note Close the Ink Tank Cover.
Page 523: When To Replace Ink Tanks
When to Replace Ink Tanks The remaining ink levels shown on the Display Screen correspond to the inks identified by the Color Label on the bottom of the Display Screen. These symbols may be displayed above the ink level: ! if ink is low, × if no ink is left, and ? if you have deactivated ink level detection.
Page 524: Printheads
Printhead iPF760 Printheads Printheads Printhead ..............................524 Checking for Nozzle Clogging ........................524 Cleaning the Printhead ..........................525 Replacing the Printhead ..........................526 Printhead Printhead A replacement Printhead. • Printhead PF-04 • For instructions on replacing the Printhead, see "Replacing the Printhead."...
Page 525: Cleaning The Printhead
Clean the Printhead. (See "Cleaning the Printhead.") →P.525 Print a test pattern to check the nozzles. • If you repeat these steps several times but the horizontal lines are still faint or incomplete, contact your Canon dealer. Note Cleaning the Printhead Cleaning the Printhead If printing is faint, cleaning the Printhead may improve results.
Page 526: Replacing The Printhead
If the printing quality does not improve even after one or two cycles of Head Cleaning B from the printer menu • If the Display Screen indicates "Open top cover and replace the printhead." • If your Canon dealer has advised you to replace the Printhead Compatible printheads For information on compatible printheads, see "Printhead." →P.524 Precautions when handling the Printhead Take the following precautions when handling the Printhead.
Page 527 Replacing the Printhead On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab ( • If the Tab Selection screen is not displayed, press the Menu button. Note Press the OK button.
Page 528 Replacing the Printhead iPF760 If the Printhead Fixer Cover or Printhead Fixer Lever is dirty, use a damp cloth that you have wrung out completely to wipe it clean. • Do not touch the Linear Scale (a) or Carriage Shaft (b).
Page 529 Replacing the Printhead Pull up the Printhead Fixer Cover to open it completely. Remove the Printhead and press the OK button. • Dispose of the used Printhead in accordance with local regulations. Note Holding the new Printhead by the grips (a), remove it from the pouch.
Page 530 Replacing the Printhead iPF760 While firmly holding the Printhead you have removed, use your other hand to remove the orange Protective Part (a). Squeeze the grips (c) of Protective Part (b) and pull it down to remove it. • The inside surface of the Protective Part (a) and Protective Part (b) is coated with ink to protect the nozzles. Be careful not to touch these surfaces when removing the caps.
Page 531 Replacing the Printhead Push the Printhead Fixer Lever toward the back of the printer until it clicks. Close the Top Cover. Ink now fills the system. It takes about seven minutes to complete. • Never remove an Ink Tank while the system is filling with ink.
Page 532: Maintenance Cartridge
Maintenance Cartridge iPF760 Maintenance Cartridge Maintenance Cartridge Maintenance Cartridge ..........................532 Replacing the Maintenance Cartridge ......................532 Checking the Remaining Maintenance Cartridge Capacity ................ 536 When to Replace the Maintenance Cartridge ....................536 Maintenance Cartridge Maintenance Cartridge A replacement Maintenance Cartridge.
Page 533 Replacing the Maintenance Cartridge If a message is displayed requesting Maintenance Cartridge replacement, you can skip the step Access the menu for Maintenance Cartridge replacement. Follow the instructions in Replace the Maintenance Cartridge. • Do not replace the Maintenance Cartridge during initialization immediately after turning on the printer, during Printhead cleaning, or when ink is being absorbed.
Page 534 Replacing the Maintenance Cartridge iPF760 • Never touch the metal contacts (a). This may damage the Maintenance Cartridge. Important At this point, open the Maintenance Cartridge Cover. Hold the used Maintenance Cartridge by the grip (a) with one hand and put your other hand under the Mainte- nance Cartridge to hold it firmly on the bottom, keeping it level as you pull it out.
Page 535 Caution • In accordance with active and ongoing environmental programs, Canon supports recycling of used maintenance cartridges. Follow the instructions provided with the new Maintenance Cartridge that describe how to process Note the used Maintenance Cartridge.
Page 536: Checking The Remaining Maintenance Cartridge Capacity
Checking the Remaining Maintenance Cartridge Capacity iPF760 Press the OK button. The printer now initializes the Maintenance Cartridge. Checking the Remaining Maintenance Cartridge Capacity Checking the Remaining Maintenance Cartridge Capacity The Maintenance Cartridge absorbs excess ink from borderless printing, printhead cleaning, and other processes.
Page 537 When to Replace the Maintenance Cartridge Check the remaining Maintenance Cartridge capacity before this maintenance and replace the Maintenance Car- tridge if necessary. If a message for the Maintenance Cartridge replacement is shown on the Display Screen When the Maintenance Cartridge is full, the Message Lamp flashes and a message to replace the Maintenance Cartridge is shown on the Display Screen.
Page 538: Cleaning The Printer
Cleaning the Printer Exterior iPF760 Cleaning the Printer Cleaning the Printer Cleaning the Printer Exterior ........................538 Cleaning Inside the Top Cover ........................538 Cleaning the Printer Exterior Cleaning the Printer Exterior Clean the printer regularly to maintain better printing quality and help prevent problems.
Page 539 Cleaning Inside the Top Cover Open the Top Cover. If paper dust has accumulated in the Vacuum holes (a) on the Platen or in the Borderless Printing Ink Grooves (b), use the Cleaning Brush (c), provided with the printer, to wipe it away.
Page 540 Cleaning Inside the Top Cover iPF760 Using a damp cloth that you have wrung out completely, wipe inside the Top Cover to clean it. Wipe away any ink residue on the Platen as a whole (a), the Paper Retainer (b), Borderless Printing Ink Grooves (c), and Ejection Guide (d).
Page 541 Cleaning Inside the Top Cover • When cleaning between the Platen and Ejection Guide, use a damp cloth that you have wrung out completely Note to wipe over the Output Tray and along grooves. Close the Top Cover. User's Guide...
Page 542: Other Maintenance
Refer to the Setup Guide for details on packing the printer and installing it after transfer. • Avoid tilting the printer excessively in transit. This may cause ink in the printer to leak and cause stains. If it is necessary to tilt the printer in transit, contact your Canon dealer. Important •...
Page 543 Preparing to Transfer the Printer Remove the Ink Tank Open the Ink Tank Cover. Pressing the tip of the Ink Tank Lock Lever horizontally, lift the Ink Tank Lock Lever to release the lock. Holding the ink tanks by the grips, remove them.
Page 544 Preparing to Transfer the Printer iPF760 Push all ink tank lock levers closed until they click into place. Close the Ink Tank Cover. At this point, ink is drawn out from inside the tubes. • Do not remove the Maintenance Cartridge during this process.
Page 545: Updating The Firmware
The firmware version is displayed. Updating the Firmware To obtain the latest firmware, visit the Canon website. If the firmware available online is newer than the installed firmware, update the printer firmware. For details on downloading and updating the firmware, visit the Canon web- site.
Page 546: Consumables
Consumables Consumables Ink Tanks ..............................518 Printhead ..............................524 Maintenance Cartridge ..........................532 User's Guide...
Page 547: Troubleshooting
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables Troubleshooting Frequently Asked Questions ............ 548 Problems Regarding Paper ............550 Printing does not start ..............
Page 548: Frequently Asked Questions
Frequently Asked Questions iPF760 Frequently Asked Questions Frequently Asked Questions Frequently Asked Questions Frequently Asked Questions This section presents frequently asked questions and answers. To view more detailed explanations, click the hy- perlinks in the answer column. Question Answer How do I print on a roll? When printing on rolls, after loading the roll, specify the paper type and length, both on the Control Panel and in the printer driver.
Page 549 Frequently Asked Questions Question Answer How do I modify how colors You can adjust colors as desired in the printer driver before printing. are printed? " ⇒" Adjusting the Color in the Printer Driver →P.50 How do I use printer driver...
Page 550: Problems Regarding Paper
Clearing Jammed Paper (Paper Feed Slot) iPF760 Problems Regarding Paper Problems Regarding Paper Clearing Jammed Paper (Paper Feed Slot) ....................550 Clearing Jammed Roll Paper ........................552 Clearing a Jammed Sheet ..........................554 Roll paper cannot be inserted into the paper feed slot ................556 Cannot load sheets ............................
Page 551 Clearing Jammed Paper (Paper Feed Slot) Fold an A4 sheet lengthwise four times and insert it through the gap of the Paper Feed Slot. Push the scrap out toward the Platen. Remove the scrap when it is pushed out onto the Platen.
Page 552: Clearing Jammed Roll Paper
Clearing Jammed Roll Paper iPF760 Clearing Jammed Roll Paper Clearing Jammed Roll Paper If paper from a roll becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel. Remove the jammed paper as follows. Open the Roll Cover. Use a commercially available cutter or the like to cut the paper of the loaded roll.
Page 553 Clearing Jammed Roll Paper Close the Top Cover. • Do not move the Carriage over jammed paper. This may damage the Printhead. • Do not touch the Linear Scale (a) or Carriage Shaft (b). Important This may stain your hands and damage the printer.
Page 554: Clearing A Jammed Sheet
Clearing a Jammed Sheet iPF760 • If the paper is jammed by the Ejection Guide Remove the jammed paper from the Output Tray. After removing the paper, make sure there are no oth- er scraps of paper in the printer.
Page 555 Clearing a Jammed Sheet Remove the jammed paper. • If paper is jammed inside the Top Cover Open the Top Cover and move the Carriage to the left or right side manually, away from the jam. Clear any jammed paper from inside the Top Cover.
Page 556: Roll Paper Cannot Be Inserted Into The Paper Feed Slot
Roll paper cannot be inserted into the paper feed slot iPF760 • If the paper is jammed by the Paper Feed Slot Remove the jammed paper from the Paper Feed Slot. After removing the paper, make sure there are no oth- er scraps of paper in the printer.
Page 557: Cannot Load Sheets
Cannot load sheets Cannot load sheets Cannot load sheets Cause Corrective Action The paper source selection is incorrect. Press the Load button and select the paper source. Paper is not cut neatly Paper is not cut neatly Cause Corrective Action The paper is bent or curled at the cut position.
Page 558: Printing Does Not Start
The Data lamp on the Control Panel does not light up iPF760 Printing does not start Printing does not start The Data lamp on the Control Panel does not light up ................558 The printer does not respond even if print jobs are sent ................558 Ink Filling..
Page 559: The Printer Stops During A Print Job
In the Control Panel, set Auto Rotate to Off and print again. HP RTL commands when Auto Rotate is On in (See "Menu Settings.") →P.448 the Control Panel menu. The printer is damaged. Contact your Canon dealer for assistance. User's Guide...
Page 560: Problems With The Printing Quality
Printing is faint iPF760 Problems with the printing quality Problems with the printing quality Printing is faint .............................. 560 Paper rubs against the Printhead ........................ 560 The edges of the paper are dirty ......................... 561 The surface of the paper is dirty ........................562 The back side of the paper is dirty ......................
Page 561: The Edges Of The Paper Are Dirty
The edges of the paper are dirty Cause Corrective Action Paper has been loaded incorrectly, caus- Reload the paper. ing it to wrinkle. (See "Loading Rolls in the Printer.") →P.399 (See "Loading Sheets in the Printer.") →P.417 The Printhead is set too low in the Con- In the Control Panel menu, set Head Height to Automatic.
Page 562: The Surface Of The Paper Is Dirty
The surface of the paper is dirty iPF760 The surface of the paper is dirty The surface of the paper is dirty Cause Corrective Action The Paper Retainer is soiled. Clean the Paper Retainer. (See "Cleaning Inside the Top Cover.") →P.538...
Page 563: Colors In Printed Images Are Uneven
Colors in printed images are uneven Cause Corrective Action Printing does not proceed smoothly be- Exit other applications and cancel other print jobs. cause print jobs are interrupted during transmission. In the Control Panel menu, Adj. Priority is Setting Adj. Priority to Print Quality in the Control Panel menu and adjusting the feed set to Print Length.
Page 564: Image Edges Are Blurred Or White Banding Occurs
Image edges are blurred or white banding occurs iPF760 Cause Corrective Action The type of paper specified in the printer Press the Stop button and stop printing. driver does not match the type loaded in Change the type of paper in the printer driver and try printing again.
Page 565: Documents Are Printed In Monochrome
Documents are printed in monochrome Cause Corrective Action In the Control Panel menu, Width Detection is set to Off. Set Width Detection to On in the Control Panel menu. Documents are printed in monochrome Documents are printed in monochrome...
Page 566: Cannot Print Over A Network
Cannot connect the printer to the network iPF760 Cannot print over a network Cannot print over a network Cannot connect the printer to the network ....................566 Cannot print over a TCP/IP network ......................566 Cannot print over a NetWare network ......................566 Cannot print over AppleTalk or Bonjour networks ..................
Page 567: Cannot Print Over Appletalk Or Bonjour Networks
Cannot print over AppleTalk or Bonjour networks Cause Corrective Action The NetWare server and If data transmission to a printer on another subnet fails, deactivate NCP burst mode in that printer's services are not configured network protocol settings. correctly.
Page 568: Installation Problems
The following instructions are for Windows XP. The method of removing printer drivers varies depending on the version of Windows. Note From the Windows start menu, select Programs > Canon Printer Uninstaller > imagePROGRAF Printer Driver Uninstaller to display the Delete Printer window. Select the printer in the list and click Delete.
Page 569 Removing Installed Printer Drivers • The following instructions are for Windows XP. The method of removing printer drivers varies depending on the version of Windows. Note From the Windows start menu, select Programs > imagePROGRAF Device Setup Utility > Uninstaller (imagePROGRAF Device Setup Utility) to start the wizard.
Page 570: Hp-Gl/2 Problems
With HP-GL/2, printing is misaligned iPF760 HP-GL/2 problems HP-GL/2 problems With HP-GL/2, printing is misaligned ......................570 Lines or images are missing in printed HP-GL/2 jobs................. 570 Lines are printed too thick or thin in HP-GL/2 print jobs ................570 HP-GL/2 jobs are printed in monochrome (or color) ..................
Page 571: Hp-Gl/2 Jobs Are Printed At Maximum Size, Even If A Standard Size Is Specified
HP-GL/2 jobs are printed at maximum size, even if a standard size is specified HP-GL/2 jobs are printed at maximum size, even if a standard size is specified HP-GL/2 jobs are printed at maximum size, even if a standard size is specified...
Page 572: Other Problems
• After ink tank replacement. (Ink agitation takes about three and a half minutes.) In other cases, contact your Canon dealer. Messages advising to check the maintenance cartridge are not cleared Messages advising to check the maintenance cartridge are not cleared...
Page 573: Ink Level Detection
Printing with the ink level detection canceled may lead to printer damage and printing problems. Canon Inc. is not liable for any damage that may occur as a result of refilling ink.
Page 574 Ink Level Detection iPF760 After checking the message, press the ▶ button. Press ▲ or ▼ to select Yes, and then press the OK button. Check the message and press the ▶ button. Check the message and press the ▶ button.
Page 575 Ink Level Detection Press ▲ or ▼ to select Yes, and then press the OK button. Ink level detection is now released. User's Guide...
Page 576 User's Guide...
Page 577: Error Message
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables Troubleshooting Error Message Error Messages ................ 578 Messages regarding paper ............580 Messages regarding ink ............
Page 578: Error Messages
Error Messages Error Messages Borderless printng not possible........................586 Cannot adjust paper feed..........................590 Cannot adjust printhead..........................591 Cannot detect papr ............................585 Check printed document..........................590 Close Ink Tank Cover ........................... 588 Do not pull out ink tank..........................589 End of paper feed.
Page 579 This type of paper is not compatible with HP-GL/2..................594 Top cover is open............................595 Unable to detect ink level correctly......................588 Unknown file..............................596 Wrong ink tank............................. 589 Wrong maintenance cartridge........................593 Wrong printhead.
Page 580: Messages Regarding Paper
MediaType Mismatch iPF760 Messages regarding paper Messages regarding paper MediaType Mismatch ........................... 580 The paper is too small..........................580 The paper is too small..........................581 PaprWidth Mismatch ............................ 582 Paper size not detected..........................582 Insufficient paper for job ..........................583 This paper cannot be used.
Page 581: The Paper Is Too Small
The paper is too small. Cause Corrective Action When Detect Mismatch in the Control Panel menu is Adjust the paper size setting in the printer driver to match the size loaded in the set to Pause, paper smaller than the size specified in printer as follows.
Page 582: Paprwidth Mismatch
PaprWidth Mismatch iPF760 PaprWidth Mismatch PaprWidth Mismatch Cause Corrective Action When Detect Mismatch in the Control Panel menu is set to Press ▲ or ▼ to select Print, and then press the OK button to resume Pause or Warning, the width of the loaded roll does not printing.
Page 583: Insufficient Paper For Job
Insufficient paper for job Insufficient paper for job Insufficient paper for job Cause Corrective Action The printer has received a print job longer than the amount of roll paper left Press ▲ or ▼ to select Print, and then press the OK button when ManageRemainRoll in the Control Panel menu is On.
Page 584: Sheet Printing Is Selected
Sheet printing is selected. iPF760 Cause Corrective Action The roll is empty. Load the new roll. (See "Attaching the Roll Holder to Rolls.") →P.397 (See "Loading Rolls in the Printer.") →P.399 If no barcode was printed on the roll, specify the type of paper.
Page 585: Paper Is Crooked
Paper is crooked. "Manually rewind the roll all the way and press OK." Cause Corrective Action A paper jam occurred Rewind paper on the Roll Holder manually, all the way, and then press the OK button. when advancing the Load the paper.
Page 586: Paper Cutting Failed
For information about paper that is compatible with automatic cutting, see the Paper Reference Guide. (See Paper Reference Guide .) Push the Release Lever back and remove the paper. In other cases, the Cutter Unit Contact your Canon dealer for assistance. may be damaged. End of paper feed. End of paper feed. Cause Corrective Action You are pressing the ▲...
Page 587: Paper Position Not Suitable For Borderless Printing
Paper position not suitable for borderless printing. Cause Corrective Action The print job received specifies a type Select None when you have set Detect Mismatch on the control panel to Warning. or width of paper that is not compati- However, note that this error may cause paper jams and affect the printing quality.
Page 588: Messages Regarding Ink
Ink insufficient. iPF760 Messages regarding ink Messages regarding ink Ink insufficient.............................. 588 No ink left..............................588 Remaining level of the ink cannot be correctly detected................588 Unable to detect ink level correctly......................588 Close Ink Tank Cover ........................... 588 Ink tank is empty.
Page 589: Ink Tank Is Empty
Ink tank is empty. Ink tank is empty. Ink tank is empty. Cause Corrective Action There is no ink left in an ink tank. Open the Ink Tank Cover and replace the Ink Tank for which the Ink Lamp is flashing.
Page 590: Messages Regarding Printing Or Adjustment
Cannot adjust paper feed. iPF760 Messages regarding printing or adjustment Messages regarding printing or adjustment Cannot adjust paper feed..........................590 Check printed document..........................590 Cannot adjust paper feed. Cannot adjust paper feed. Cause Corrective Action The Printhead nozzles are clogged.
Page 591: Messages Regarding Printheads
Cannot adjust printhead. Messages regarding printheads Messages regarding printheads Cannot adjust printhead..........................591 Wrong printhead............................591 Printhead error ............................. 591 No printhead ..............................591 Execute printhead cleaning......................... 591 Cannot adjust printhead. Cannot adjust printhead. Cause Corrective Action The Printhead nozzles are clogged.
Page 592 Execute printhead cleaning. iPF760 Cause Corrective Action The Printhead noz- If the message is still displayed when printing, replace the Printhead. zles are clogged. (See "Replacing the Printhead.") →P.526 Press ▲ or ▼ to select Print, and then press the OK button to resume printing. However, note that this error may affect the printing quality.
Page 593: Messages Regarding The Maintenance Cartridge
Insert the maintenance cartridge. Messages regarding the maintenance cartridge Messages regarding the maintenance cartridge Insert the maintenance cartridge......................... 593 Wrong maintenance cartridge........................593 Maint. cart. The level is low .......................... 593 No Maintenance Cartridge capacity......................593 Maintenance cartridge full.
Page 594: Messages Regarding Hp-Gl/2
This type of paper is not compatible with HP-GL/2. iPF760 Messages regarding HP-GL/2 Messages regarding HP-GL/2 This type of paper is not compatible with HP-GL/2..................594 GL2: Wxxxx The memory is full. (xxxx is 0501, 0903, or 0904) ..............594 GL2: W0502 The parameter is out of range.
Page 595: Other Messages
Cause Corrective Action An error requiring service may have occurred. Write down the error code and message, turn off the printer, and contact your Canon deal- er for assistance. Hardware error. xxxxxxxx-xxxx (x represents a letter or number) Hardware error. xxxxxxxx-xxxx (x represents a letter or number)
Page 596: Prepare For Parts Replacement
You have uploaded firmware for a different model. Check the firmware version. Turn off the printer and wait a while before restor- ing power, and then resend the firmware. If the message is displayed again, contact your Canon dealer for assistance. Multi-sensor error Multi-sensor error...
Page 597: Specifications
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables Troubleshooting Error Message Specifications Printer Specifications ..............598 Appendix...
Page 598: Printer Specifications
Specifications iPF760 Printer Specifications Printer Specifications Specifications ............................... 598 Print Area ..............................600 Specifications Specifications • The following values may vary depending on the operating environment. Important Printer Power supply 100–120 V AC (50/60 Hz), 220–240 V AC (50/60 Hz)
Page 599 Internal port Specification IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX/Auto-Negotiation, IEEE 802.3ab1000Base-T/Auto-Negotiation, IEEE 802.3x Full Duplex Protocols IPX/SPX (Netware 4.2, 5.1, 6.0), SNMP (Canon-MIB compatible), TCP/IP(IPv4/ IPv6), AppleTalk, HTTP Ink Tank MBK Ink Tank ( Matte Black Ink, or Pigment ink...
Page 600: Print Area
Print Area iPF760 Print area Normal size For information on the recommended print area, see "Print Area." →P.600 Borderless printing ( *2 ) Printable area (rolls) 0 mm from the top, 0 from the bottom, and 0 mm from the left and right sides Supported width for borderless printing 36-in.
Page 601 Print Area Rolls • Printable Area A margin of 3 mm (0.12 in) on all sides is required. During borderless printing, the margin on all sides is 0 mm. For information on paper compatible with borderless printing, see the Paper Reference Guide. (See "Types of Paper.")
Page 602 User's Guide...
Page 603: Appendix
User's Guide Basic Printing Workflow Enhanced Printing Options Windows Software Mac OS X Software Handling Paper Control Panel Printer Parts Network Setting Adjustments for Better Print Quality Maintenance and Consumables Troubleshooting Error Message Specifications Appendix Safety Precautions ..............604 Manuals for this printer .............
Page 604: Safety Precautions
Safety Precautions iPF760 Safety Precautions Safety Precautions Safety Precautions ............................604 Legal Notices ............................... 606 Safety Precautions Safety Precautions Follow the warnings and precautions below to use the printer safely. Do not perform any operations or procedures other than as described in this manual. Doing so may result in unexpected accidents and can cause a fire or elec- trical shocks.
Page 605: In An Emergency
Safety Precautions In an Emergency • If the printer emits smoke or strange odors, continuing to use the printer may cause a fire or electrical shock. Switch the printer off immediately and remove the power plug from the power outlet. Contact the nearest service center.
Page 606: Legal Notices
Legal Notices Legal Notices FCC Regulations (U.S.A) Canon Large Format Printer iPF760 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 607 Included battery contains Perchlorate Material - special handling may apply. See http://www.dtsc.ca.gov/hazardouswaste/perchlorate/ for detail. Trademarks • Canon, the Canon logo, and imagePROGRAF are trademarks or registered trademarks of CANON INC. • Microsoft and Windows are trademarks of Microsoft Corporation, registered in the U.S. and other countries. •...
Page 608: Manuals For This Printer
Manuals for this printer iPF760 Manuals for this printer Manuals for this printer Manuals for this printer ..........................608 About This User Manual ..........................608 Manuals for this printer Manuals for this printer This printer has the following manuals. Name...
Page 609 About This User Manual Cross-reference in related manuals Example: See the Paper Reference Guide . Other cross-reference Example: See the printer driver help. • Figures and software screens • Figures in this user manual may be different from the actual appearance of the printer in some cases.
Page 610: How To Use This Manual
Searching Topics iPF760 How to use this manual How to use this manual Searching Topics ............................610 HTML Version of the Manual for Printing ...................... 611 Searching Topics Searching Topics You can find information in topics of this User Manual by searching for relevant terms.
Page 611: Html Version Of The Manual For Printing
HTML Version of the Manual for Printing To review multiple topics at once, select the check box of desired topics and click the Apply button. HTML Version of the Manual for Printing HTML Version of the Manual for Printing You can select a group of topics in the table of contents or individual topics in this manual for printing.
Page 612 HTML Version of the Manual for Printing iPF760 Click Access to the HTML for printing in the title area. The topics in Basic Printing Workflow are displayed together in HTML format, ready for printing. Clear the sections you will not print and click the Ap- ply button.
Page 613 HTML Version of the Manual for Printing Printing a group of individual topics in the manual When you access printable HTML versions from subtitles in the table of contents, you can specify a group of topics to print. Click a section title in the table of contents. Here, Ba- sic Printing Workflow is used as an example.
Page 614 HTML Version of the Manual for Printing iPF760 The topics in Printing Procedure are displayed to- gether in HTML format, ready for printing. Clear the topics you will not print and click the Apply button. Printing selected topics Print selected topics as follows.
Page 615 HTML Version of the Manual for Printing • Macintosh On a Macintosh computer, click anywhere in the explanation area except on a figure or a link while holding the Ctrl key. In the shortcut menu, click Print Frame to display the Print dialog box.
Page 616: Disposal Of The Product
WEEE Directive iPF760 Disposal of the product Disposal of the product WEEE Directive WEEE Directive User's Guide...
Page 617 WEEE Directive User's Guide...
Page 618 WEEE Directive iPF760 User's Guide...
Page 619 WEEE Directive User's Guide...
Page 620 WEEE Directive iPF760 User's Guide...
Page 621 WEEE Directive User's Guide...
Page 622 WEEE Directive iPF760 User's Guide...
Page 623 WEEE Directive User's Guide...
Page 624 WEEE Directive iPF760 User's Guide...
Page 625 Index Maintenance Cartridge ......532, 536, 593, 605 Menu Operations ..........438, 439 Accounting ........... 265, 266, 269, 272 Menu Structure ............442 Additional Settings Pane ..........308 Move Printer ..............542 Adjust Length .............. 513 Adjusting the Color in the Printer Driver ......50 Adjusting the Vacuum Strength ........
Page 626 When to Replace Ink Tanks ..........523 When to replace ............526...
