Canon imageprograf ipf700 Service Manual page 165

J601
Pin
Signal name
Number
40 H1-D-DATA-7-OD
41 H1-E-DATA-8-OD
42 /H1-F-HE-10
43 H1-F-DATA-11-EV
44 H1-E-DATA-8-EV
45 H1-D-DATA-6-EV
46 H1-C-DIA2
47 H1-C-DATA-5-EV
48 H1-B-DIA1
49 /H1-A-HE-0
50 H1-B-DATA-2-OD
51 H1-B-DATA-3-OD
52 H1-C-DATA-4-OD
53 GND
54 GND
55 GND
56 H1-F-DATA-11-OD
57 H1-E-DATA-9-EV
58 GND
59 H1-D-DATA-6-OD
60 /H1-C-HE-5
61 /H1-B-HE-3
62 H1-A-DIA1
63 H1-A-DATA-1-OD
64 GND
65 GND
66 GND
67 GND
68 H1-F-DATA-10-OD
69 H1-F-DIA1
70 /H1-D-HE-7
71 GND
72 H1_CLK
73 /H1_LT
74 H1-B-DATA-2-EV
75 H1-A-DATA-0-OD
76 GND
77 GND
78 GND
IN/OUT Function
OUT Odd head data signal 7(D)
OUT Odd head data signal 8(E)
OUT Head heat enable signal 10(F)
OUT Even head data signal 11(F)
OUT Even head data signal 8(E)
OUT Even head data signal 6(D)
IN Head DI sensor signal 2(C)
OUT Even head data signal 5(C)
IN Head DI sensor signal 1(B)
OUT Head heat enable signal 0(A)
OUT Odd head data signal 2(B)
OUT Odd head data signal 3(B)
OUT Odd head data signal 4(C)
- GND
- GND
- GND
OUT Odd head data signal 11(F)
OUT Even head data signal 9(E)
- GND
OUT Odd head data signal 6(D)
OUT Head heat enable signal 5(C)
OUT Head heat enable signal 3(B)
IN Head DI sensor signal 1(A)
OUT Odd head data signal 1(A)
- GND
- GND
- GND
- GND
OUT Odd head data signal 10(F)
IN Head DI sensor signal 1(F)
OUT Head heat enable signal 7(D)
- GND
OUT Head clock signal
OUT Head latch signal
OUT Even head data signal 2(B)
OUT Odd head data signal 0(A)
- GND
- GND
- GND
Chapter 6
6-39
