Canon imageprograf ipf700 Service Manual page 156

Chapter 6
J102
Pin
Signal name
Number
12 H1-E-DATA-8-OD_B
13 GND
14 H1-F-DATA-10-OD_B
15 GND
16 H1-E-DATA-9-OD_B
17 GND
18 /H1-F-HE-10_B
19 GND
20 H1-F-DATA-11-OD_B
21 GND
22 H1-F-HE-11_B
23 GND
24 H1-F-DATA-11-EV_B
25 GND
26 H1-F-DATA-10-EV_B
27 GND
28 H1-E-HE-9_B
29 GND
30 H1-E-DATA-9-EV_B
31 GND
32 VH_DIS
33 H1-DASLK_LICC2
34 H1-DLD_LICC2
35 H1-DATA_LICC2
36 PWLED2_ON
37 PWLED1_ON
38 PWLED3_ON
39 /H3V_ON_B
40 MLT_SENS_1IN
41 MLT_SENS_2IN
42 PWLED4_ON
43 GND
44 H1-B-DATA-2-OD_B
45 GND
46 H1-B-DATA-3-OD_B
47 GND
48 /H1-C-HE-4_B
49 GND
50 H1-C-DATA-4-OD_B
6-30
IN/OUT Function
IN Odd head data signal 8(E)
- GND
IN Odd head data signal 10(F)
- GND
IN Odd head data signal 9(E)
- GND
IN Head heat enable signal 10(F)
- GND
IN Odd head data signal 11(F)
- GND
IN Head heat enable signal 11(F)
- GND
IN Even head data signal 11(F)
- GND
IN Even head data signal 10(F)
- GND
IN Head heat enable signal 9(E)
- GND
IN Even head data signal 9(E)
- GND
IN VH selection signal
IN Head analogue switch clock signal
IN Head analogue switch latch signal
IN Head analogue switch data signal
IN Multi sensor LED2 drive signal
IN Multi sensor LED1 drive signal
IN Multi sensor LED3 drive signal
IN Power supply (+3V)
OUT Multi sensor signal 1
OUT Multi sensor signal 2
IN Multi sensor LED4 drive signal
- GND
IN Odd head data signal 2(B)
- GND
IN Odd head data signal 3(B)
- GND
IN Head heat enable signal 4(C)
- GND
IN Odd head data signal 4(C)
