Display Description
D-CNT 17-36 Cumulative number of sheets of A4-equivalent paper equal to or
larger than 17 inches but smaller than 36 inches (data size)
D-CNT 17 Cumulative number of sheets of A4-equivalent paper smaller than
17 inches (data size)
- HEAD DOT CNT.1
Displays the counts of dots of individual colors of the currently installed print head.
- HEAD DOT CNT.2
Displays the cumulative count of dots of individual colors.
- PARTS CNT.
Displays the status of the consumable parts replacement counter.
g. SETTING
Allows you to make various settings.
Display
Pth ON/OFF
RTC DATE
yyyy/mm/dd
TIME hh:mm
- INITIALIZE
The DISPLAY histories, ADJUST settings, COUNTER values, and other parameters can be cleared
individually.
Display
WARNING
ERROR
ADJUST
W-INK
CARRIAGE
PURGE
INK CHECK
INK-USE CNT
CUTTER-CHG CNT Initialization of COUNTER > EXCHANGE > CUTTER EXC.
Description
Turns on/off the (Pth head pulse rank) control function.
Default: On
Set the RTC. The procedure is the same as in the user mode.
The initial value is 00:00, January 1, 2006.
* The display order of year, month, and day is defined in "Date Format".
Description
Initialization of DISPLAY > WARNING
Initialization of DISPLAY > ERROR
Initialization of value of fine band adjustment by user and initialization of scale
adjustment value
The automatically adjusted value is not initialized.
Initialization of COUNTER > PRINTER > W-INK
Initialization of COUNTER > CARRIAGE
Initialization of COUNTER > PURGE
* The refill ink usage history cannot be initialized.
Initialization of COUNTER > INK-USE2
Counting up of COUNTER > CLEAR
T-7-24
T-7-25
Chapter 7
Unit
sheets
sheets
7-17
