Canon imageprograf ipf700 Service Manual page 160

Chapter 6
J702
Pin
Signal name
Number
10 /H1-A-HE-0
11 H1-A-DATA-0-EV
12 H1-A-DATA-1-EV
13 /H1-A-HE-1
14 H1-B-DATA-2-EV
15 H1-B-DATA-3-EV
16 /H1-B-HE-3
17 H1-C-DATA-4-EV
18 /H1_LT
19 H1-C-DATA-5-EV
20 /H1-C-HE-5
21 H1-C-DATA-5-OD
22 H1_CLK
23 H1-D-DATA-7-OD
24 H1-D-DATA-6-OD
25 /H1-D-HE-6
26 H1-D-DATA-6-EV
27 H1-D-DATA-7-EV
28 /H1-D-HE-7
29 H1-E-DATA-8-EV
30 H1-E-DATA-9-EV
31 /H1-E-HE-9
32 H1-F-DATA-10-EV
33 H1-F-DATA-11-EV
34 /H1-F-HE-11
35 H1-F-DATA-11-OD
36 H1-F-DATA-10-OD
37 /H1-F-HE-10
38 H1-E-DATA-9-OD
39 H1-E-DATA-8-OD
40 /H1-E-HE-8
41 GND
42 H1_DSOUT1
43 H1_DSOUT2
44 H1-DLD_LICC2
45 H1-DATA-LICC2
46 H1-DASLK_LICC2
47 H1-DASH_LICC2
48 SNS5V
49 IO-ASIC_SDA
6-34
IN/OUT Function
OUT Head heat enable signal 0(A)
OUT Even head data signal 0(A)
OUT Even head data signal 1(A)
OUT Head heat enable signal 1(A)
OUT Even head data signal 2(B)
OUT Even head data signal 3(B)
OUT Head heat enable signal 3(B)
OUT Even head data signal 4(C)
OUT Head latch signal
OUT Even head data signal 5(C)
OUT Head heat enable signal 5(C)
OUT Odd head data signal 5(C)
OUT Head clock signal
OUT Odd head data signal 7(D)
OUT Odd head data signal 6(D)
OUT Head heat enable signal 6(D)
OUT Even head data signal 6(D)
OUT Even head data signal 7(D)
OUT Head heat enable signal 7(D)
OUT Even head data signal 8(E)
OUT Even head data signal 9(E)
OUT Head heat enable signal 9(E)
OUT Even head data signal 10(F)
OUT Even head data signal 11(F)
OUT Head heat enable signal 11(F)
OUT Odd head data signal 11(F)
OUT Odd head data signal 10(F)
OUT Head heat enable signal 10(F)
OUT Odd head data signal 9(E)
OUT Odd head data signal 8(E)
OUT Head heat enable signal 8(E)
- GND
IN Head temperature output signal 1
IN Head temperature output signal 2
OUT Head analogue switch latch signal
OUT Head analogue switch data signal
OUT Head analogue switch clock signal
OUT Head analogue switch A/D trigger signal
OUT Power supply (+5V)
IN/OUT Head ROM control signal (data)
