Chapter 6

6.1.4.12 03130031-260F Gap adjustment error

<Cause>
Gap reference surface error (This error occurs only in the service mode.)
<Probable fault location>
Multi sensor base
<Countermeasure>
1) Replace the multi sensor base.

6.1.4.13 03130031-2F13 A/D Converter external trigger output stopped

<Cause>
Defective main controller PCB
<Probable fault location>
Main controller PCB
<Countermeasure>
1) Turn off the printer, and then turn it off again.
2) Replace the main controller PCB.

6.1.4.14 03130031-2F14 ASIC Register cannot be written.

<Cause>
A main controller PCB firmware error occurred.
<Probable fault location>
Main controller PCB
<Countermeasure>
1) Turn off the printer, and then turn it off again.
2) Replace the main controller PCB.

6.1.4.15 03130031-2F16 Mist fan error

<Cause>
Mist fan rotation could not be detected during mist fan rotation.
<Probable fault location>
Mist fan or main controller PCB
<Countermeasure>
1) Replace the mist fan.
2) Cable continuity check
If continuity of the cable between the mist fan and the main controller PCB is abnormal, replace the cable.
3) Replace the main controller PCB

6.1.4.16 03130031-2F17 Suction fan error

<Cause>
When the suction fan was driven, the lock signal was detected for more than the specified time.
<Probable fault location>
Suction fan or main controller PCB
<Countermeasure>
6-10
